- Page 1 IFS POE201-MS/4 4-Port PoE-af Injector User Manual P/N 1072580 • REV R00.04 • ISS 31JAN13...
- Page 2 Copyright © 2013 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. The IFS POE201-MS/4 4-Port PoE-af Injector and logo are Trademarks and patents trademarks of United Technologies.
-
Page 3: Table Of Contents
Product Features 1 Product Overview 3 LED Indicators 4 Hardware Installation 4 Before Installation 4 Injector Installation 4 Troubleshooting 6 Appendix A: Network Connection 7 RJ-45 Pin Assignments 7 Specifications 9 Contacting Technical Support 10 IFS POE201-MS/4 4-Port PoE-af Injector User Manual... -
Page 5: Package Contents
Product Features The IFS POE201-MS/4 is a 4-Port IEEE 802.3af Power over Ethernet injector hub complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3af standards. Equipped with 4 10/100Base-TX Fast Ethernet ports, the POE201-MS/4 supports full 48V DC power for any remote IEEE 802.3af powered device (PD) like... - Page 6 • Full power support (15.4W) on each POE port • Circuit protection prevents power interference between ports • LED indicators power input indication • Small Compact Design IFS POE201-MS/4 4-Port PoE-af Injector User Manual...
-
Page 7: Product Overview
Product Overview Figure 1 shows the front and side panels of the POE201-MS/4. Figure 1: POE201-MS/4 Front and Side Panels IFS POE201-MS/4 4-Port PoE-af Injector User Manual... -
Page 8: Led Indicators
The 10Mbps or 100Mbps speed, duplex mode from Data port of the POE201-MS/4 depends on which Ethernet device is attached. Injector Installation For installation locations where it's hard to find a power outlet, the POE201-MS/4 provides an easier way to power your IFS POE201-MS/4 4-Port PoE-af Injector User Manual... - Page 9 IEEE 802.3af devices installed 100 meters away. Figure 2: Connection Architecture According to the IEEE 802.3af standard, the POE201- Note: MS/4 will not inject power to the cable if it is not connected to IEEE 802.3af devices. IFS POE201-MS/4 4-Port PoE-af Injector User Manual...
-
Page 10: Troubleshooting
UTP, Category 5/5e, EIA568 cable within 100 meters. A cable with only 4-wire, short loop or over 100 meters, all will affect the power supply. Please check and assure the device that fully complied with IEEE 802.3af standard. IFS POE201-MS/4 4-Port PoE-af Injector User Manual... -
Page 11: Appendix A: Network Connection
There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of a straight cable and crossover cable connection: Figure A-1: Straight-Through and Crossover Cable IFS POE201-MS/4 4-Port PoE-af Injector User Manual... - Page 12 For energy savings and reducing the unnecessary power consumption, we strongly suggest that you remove the power connection for the device if this device is not intended to be active. IFS POE201-MS/4 4-Port PoE-af Injector User Manual...
-
Page 13: Specifications
Dimension (H x W x D) 26 x 70 x 97mm Weight 220g Emission FCC Class B, CE mark Standard Compliance IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3af Power over Ethernet IFS POE201-MS/4 4-Port PoE-af Injector User Manual... -
Page 14: Contacting Technical Support
Contact technical support if you encounter any difficulties during this installation. Please contact us by phone or go to www.interlogix.com/customer-support. Technical Support Europe, Middle East and Africa Select Contact Us at www.utcfssecurityproducts.eu North America +1 855.286.8889 techsupport@interlogix.com Australia techsupport@interlogix.au IFS POE201-MS/4 4-Port PoE-af Injector User Manual...
