LOW MOUNT SPA COVERLIFT
PLEASE READ CAREFULLY BEFORE INSTALLATION
!! CAUTION !!
Please read all instructions and
precautions in this installation
sheet before using this equipment.
Save this installation sheet for
future reference. Use this Spa
Coverlift only as described in this
installation sheet. Inspect and
tighten all parts regularly, replace
any worn or missing parts
immediately.
Installation Sheet
IMPORTANT!!
(Spa and Spa Cover Not Included)
!! WARNING !!
Adult assembly required. This
package contains small parts
which are a choking hazard. Keep
children away from bags and parts
until assembled. Dispose of
packaging with care.
Mfg#3200103
Pg. 1, Rev. 2, 4/21/14
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Freeflow Spas Cover Lifter Low Mount
- Page 1 LOW MOUNT SPA COVERLIFT Installation Sheet IMPORTANT!! PLEASE READ CAREFULLY BEFORE INSTALLATION (Spa and Spa Cover Not Included) !! CAUTION !! !! WARNING !! Please read all instructions and Adult assembly required. This precautions in this installation package contains small parts sheet before using this equipment.
- Page 2 !!! WARNING !!! PLEASE READ !!! WARNING !!! DO NOT attach or incorporate electrical appliances or accessories into or onto The Spa Coverlift as an electrical hazard could be created, resulting in injury or death. DO NOT lean, sit, stand on or play around The Spa Coverlift that could cause a loss of balance resulting in injury.
- Page 3 SET-UP AND ASSEMBLY: Place all parts in a cleared area and remove the packing materials from the spa shell; do no dispose of the packing materials until assembly is completed and the spa is in operation. Assembly requires two people and the spa needs to empty so the Foot Pedals can be positioned underneath the spa. Foot Pedals should be placed under the spa just past the radius corner equally on both sides.
- Page 4 Step 4: Thread Bolt Nut to Pivot Arm Bolts A (Fig 4-1) secure tightly and place Nut caps to both nuts. Thread Lock Nut onto Pivot Arm Bolts B (Fig 4-2) and secure tightly and cover nut with Nut Caps (Fig 4-3). Slide the long end of the cover support arm into either side of the Coupler piece and then slide the short end of the Cover Support Arm into the top of the Side Pivot Arms (Fig 4-4).
