- Page 1 INSTALLATION & MAINTENANCE MANUAL OL01B / OL01P...
- Page 2 GENERAL INSTRUCTIONS These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following products: OL01B / OL01P SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations.
- Page 3 (BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician • Please isolate mains prior to installation or maintenance • Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the circuit cable, fuse or circuit breaker •...
- Page 4 When the concrete is set, fix the base plate to the threaded rods using the spring w • provided (see Fig. 2) Fig. 2 • Remove the baseplate from the luminaire by loosening the screws on the sides • When the concrete is set, fix the baseplate to the threaded rods using the spring washers and nuts provided (see Fig.
- Page 5 • Tighten the compression gland ensuring a tight seal is made • Refit the luminaire to the baseplate and tighten • Remove the top of the luminaire by loosening the two Allen screws on the sides and insert a suitable E27 lamp (max. 20W) •...
- Page 6 ML Accessories does not accept responsibility for any installation costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the right to alter product specification without prior notice.
