Channel Master CM-7100 Quick Start Manual

Hd/sd iptv set-top box

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM-7100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Channel Master CM-7100

  • Page 2: Table Of Contents

    Contents WARNING AND SAFETY INFORMATION ..2   INTRODUCTION ........... 6     HD IP S ....6   NTRODUCTION     Main Features ............6   ....7   ACKAGE ONTENTS AND CCESSORIES     Front Panel .............. 8  ...
  • Page 3: Warning And Safety Information

    Warning and Safety Information Please read this user’s manual before operating this product. The information contained in this document is subject to change without notice. Features or specifications may be different depending on the type of set-top box purchased. About our Company Thank you for selecting our HD IP Set-Top Box Product.
  • Page 4 Operational Environment Avoid high moisture conditions and keep away from all liquids or humidity. This product must not be exposed to dripping, splashing or high humidity. Do not use this product in any location where it may come in contact with any liquid or vapor. Product Care and Servicing Attempts to dismantle the product may be unsafe, may be detrimental to the life or performance of the product and will...
  • Page 5 surface that may become warm during use (such as on top of a VCR or A/V amplifier) and nothing should be placed on top of the HD IP Set-Top Box. Do not cover the HD IP Set-Top Box. Objects containing liquids, such as vases, flowerpots, etc. must not be placed on top of the product.
  • Page 6 Disclaimer The manufacturer makes no representations or warranties with respect to the contents herein and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to revise this publication and to make changes from time to time in the content and specifications herein without obligation of the manufacturer to notify any person of such revision or changes.
  • Page 7: Introduction

    Introduction 1. HD IP Set-Top Box Introduction The HD IP Set-Top Box is a digital system designed and built to receive interaction with the unlimited world of IP service provider viewing package content including TV channels, audio programs, music, games, and much more, all while enjoying real time access to the Internet at the touch of a button! With applications in the broadband environment, the HD IP Set-Top Box has multicast IPTV support (IGMP), VOD (video on demand), AOD (audio on demand),...
  • Page 8: Package Contents And Accessories

    2. Package Contents and Accessories The package includes the following items and accessories: HD IP Set-Top Box Unit Remote Control Unit Quick Start Guide Power Adapter Ethernet Cable 3.5mm jack to RCA Audio/Video Cable...
  • Page 9: Front Panel

    Front Panel USB port for external devices IR Receiver LED status light LED Definition Steady Red: The power is turned-on. Steady Green: The device has finished booting up and is ready for use. Blinking Red: System error. Blinking Green: Valid signal is received from remote control.
  • Page 10: Installation

    Installation 3. Turn on this product Follow the steps below to turn on this product. Connect the power input jack on the rear panel using the power adapter that came with this product. Plug the power adapter to a power outlet. Push the power button on the rear panel to turn on this device.
  • Page 11: Configuring Your Hd Ip Set-Top Box

    4. Configuring Your HD IP Set-Top Box The following section describes how to connect the HD IP Set-Top Box to your home entertainment TV system. Instructions and diagrams will show you how to setup and configure the HD IP Set-Top Box: TV and Network Connection TV and Home Network Connection Digital Stereo Audio System and TV Connection...
  • Page 12: Tv And Home Network Connection

    TV And Home Network Connection Internet Broadband Broadband Router/ Modem Router/ Modem HD IP Set Top Box HD IP Set Top Box Ethernet LAN Switch Ethernet Cable Audio & Video Cable: Audio & Video Cable: 1. HDMI cable 1. HDMI cable 2.
  • Page 13: Operating

    Operating 5. Remote Control Introduction Remote Control Keypad Description Your remote control is designed to control your HD IP Set-Top Box and your TV. Your IPTV service provider may program your remote control or provide you with a different remote control. If the remote control has not been programmed, please consult your service provider.
  • Page 14: Using Remote Control In Tv And Stb Modes

    Using Remote Control in TV and STB Modes The remote control operates in one of the two modes: TV Mode STB Mode A mode is selected by pressing the TV or STB mode selection button of the remote control. When pressed, the LED indicator on the remote control will blink to indicate the mode has been changed.
  • Page 15 Functions of the remote control in the TV mode: Function Button Description Symbol Power Power on/ off TV Power. Volume TV volume up and volume down. up/down Mute TV mute and un-mute. Input Cycles the TV through the available AV inputs. STB Mode Press the STB button on the remote control to use this remote control in the STB mode.
  • Page 16 Function Button Description Symbol Mute TV mute and un-mute. NOTE: This button functions the same in both the TV mode and the STB mode. Back Leave current menu and return to previous menu. Prev.CH Toggles between previous channel and current channel. Menu Displays the main menu.
  • Page 17: Appendix

    Appendix 6. Troubleshooting Guide Use this troubleshooting guide for easy solutions to correct common problems. If this troubleshooting guide does not solve a specific problem, contact your service provider. Symptom Solution The power button on the rear panel is Set-Top Box switched off.
  • Page 18 Symptom Solution The system The activation code is used to start the asked me for system which should have been configured an activation by your service provider. Please contact code your service provider for the code. There is no Be sure that the Mute button on the remote audio when control or the TV has not been activated.
  • Page 19 Symptom Solution There are Unless the stretch setting is enabled, Wide black bars on screen TVs will sometimes display 4:3 the right and programs with left and right black bars left sides of (some programs are broadcast in the screen (if ‘pillar-box’...
  • Page 20: Tv Brand Codes

    7. TV brand codes Use the following codes to pair the remote control with your TV. remote control introduction chapter detailed information. We recommend that you write down the brand code of your TV after you pair the remote control with your TV successfully: Abex 0081 Bell &...
  • Page 21 Color Tac 0267 Finlux 0136 Colortyme Fisher 0113, 0114, 0149, 0176, 0295 0117, 0168, 0175, 0195 Concerto Funai/Fullness 0100, 0113, 0114, 0176, 0295 0011, 0029, 0030, 0039, 0040, Contec/Cony 0042, 0136, 0148, 0177, 0342 0048, 0107, 0148, 0157, 0173, Fortress 0033 0177, 0192, 0201, 0342 Fujitsu 0033, 0136 Coronado 0178, 0179...
  • Page 22 Hitachi 0004, 0014, 0019, 0034, 0063, 0100, 0114, 0156, 0179, 0223, 0069, 0086, 0095, 0099, 0100, 0259, 0248, 0316(LCDTV) 0107, 0113, 0114, 0157, 0162, Lloytron 0178 0164, 0173, 0176, 0178, 0179, Loewe 0082 0184, 0188, 0201, 0203, 0204, Lodgenet 0063, 0180 0207, 0214, 0224, 0225, 0238, Logik 0063, 0177, 0180 0255, 0279, 0284, 0293, 0295,...
  • Page 23 PIVA 0349 0005, 0031, 0032, 0041, 0061, Polariod 0310(LCDTV) 0068, 0079, 0080, 0100, 0113, Polestar 0103 0114, 0160, 0175, 0176, 0187, Portland 0190, 0288, 0295, 0311(LCDTV) 0005, 0100, 0103, 0113, 0114, Nesco 0136 0176, 0178, 0179, 0188, 0190, NETTV 0260 0295 Newave Praxis 0211...
  • Page 24 Sampo Sony 0024, 0041, 0042, 0052, 0073, 0000, 0001, 0012, 0013, 0014, 0086, 0100, 0106, 0107, 0113, 0024, 0045, 0046, 0061, 0073, 0114, 0142, 0175, 0176, 0178, 0097, 0181, 0198, 0202, 0204, 0205, 0206, 0214, 0248, 0260, 0214, 0232, 0245, 0246, 0283, 0280, 0295, 0302(LCDTV), 0260, 0244(LCDTV) 0327...
  • Page 25 Teknika Victor 0067, 0081, 0165 0005, 0037, 0055, 0063, 0100, Videocon 0003, 0018 0103, 0113, 0114, 0132, 0136, Vidikron 0037 0157, 0160, 0167, 0171, 0176, Vidtech 0177, 0178, 0179, 0180, 0188, 0005, 0100, 0113, 0114, 0190, 0190, 0201, 0295, 0342 0295 Telecaption II View Sonic...
