Dadant M00370 Manual

Assembly
Operation
Maintenance
Replacement Parts
ASSEMBLY
1. Remove from carton and completely unpack.
2. Turn tank upside down and insert legs, with casters attached, into leg brackets.
3. Turn upright on casters.
4. F or adapting drain to plastic tubing(1-1½ '' tubing) remove the tape from the drain adapter assembly
(No. 5-215) and hand tighten nut on to drain fitting.
5. If cappings baskets(M00371) are to be used, place one pair of the baskets in the tank bottom so that the
basket runners allow honey to flow to the drain. Clip the baskets together with clip(No. 371-03) and slide
the baskets to the end of the tank, away from the drain.
6. If uncapping into baskets, place cross bar (No. 370-03) on top of tank as follows:
-Remove wing nut and washer from one end.
-Opposing washer is placed under tank lip.
-Replace washer and nut removed and position the cross bar for uncapping and tighten wing nuts.
7. Uncap with the end bar resting on the lag screw.
M00370 CAPPINGS TANK
