- Page 1 USER MANUAL: INSTALLATION AND USE & CARE Models: BCCH**18*, BCPH4818*, BCRH**18* 197300 Rev 1...
-
Page 2: Date Of Purchase
Please take a few moments now to fill in the information below for your future reference in the event you require parts or service. DATE OF PURCHASE: DEALER’S NAME: DEALER’S ADDRESS: DATE OF INSTALLATION: INSTALLER’S NAME: INSTALLER’S ADDRESS: MODEL NUMBER: SERIAL NUMBER: (877) 842-3269... - Page 3 Table of Contents INSTALLATION INSTRUCTIONS: Handling and Unpacking Installation of Ducting & Electrical Specifications Removing Liner from Hood Shell Installing the Blowers Mounting Hood Shell to Wall and Reinstalling Liner USE AND CARE INSTRUCTIONS: Operating the Push Button Controls Cleaning Instructions Warranty bigchill.com...
-
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS IMPORTANT 1. This appliance was designed for ease of installation and operation. However, we recommend that you read all sections of this manual before you begin installation. 2. Do not remove permanently affixed labels, warnings or data plates from your appliance. This may void the manufacturer’s warranty and/or hinder effective servicing and maintenance. - Page 5 INSTALLATION INSTRUCTIONS WARNING • If a fire should occur, do not turn on hood to evacuate smoke. Turn off hood. • Do not use to exhaust hazardous, flammable or explosive materials. • Clean baffle filters often, since accumulated grease can be a fire hazard and affect the performance of your ventilation hood.
- Page 6 INSTALLATION INSTRUCTIONS CAUTION To reduce the risk of fire and electric shock, install this ventilation unit only with manufacturer approved blowers. Your ventilation hood is designed to work specifically with the integral blower requested. Site Preparation: Selecting the Appropriate Height for Installation In selecting the proper height to mount the hood, take into consideration the stature of the person or persons who will be cooking.
- Page 7 INSTALLATION INSTRUCTIONS Installation of Ducting for Proper Operation: WARNING To reduce the risk of fire, electric shock or injury, observe the following: • Use only metal ductwork. Do not use flexible or corrugated duct. Proper installation of ducting is extremely important for optimal performance of your ventilation system. It is a basic requirement that the kitchen is provided with an air intake to ensure good air circulation and, therefore, proper operation of the hood.
- Page 8 INSTALLATION INSTRUCTIONS Step 1: Read all instructions thoroughly before beginning installation. Please review all steps before beginning – for some installations, the order of assembly may be altered. Step 2: Remove ventilation hood liner from outer shell. (Figures A through F) – save all components and fasteners as they will be used to reinstall the liner after the hood shell is mounted to the wall.
- Page 9 INSTALLATION INSTRUCTIONS Step 3: Install / Set discharge orientation for blower (if not already configured as needed for your application). Duct connection detail: 6” round at discharge. Recommended duct size: 6” min., 8” max. Figure A: Figure B: Set Discharge Direction, Attach Blower Connect Plate Internally Unscrew blower plate and set to top or rear Re-install all mounting screws inside of liner.
- Page 10 INSTALLATION INSTRUCTIONS Step 4. Mount the Outer Hood Shell to the Wall 1. The bottom of the hood should be 30” minimum to 36” maximum above the countertop for efficient operation. The hood should be centered over the cooking surface. 2.
- Page 11 INSTALLATION INSTRUCTIONS Step 5. Re-install Liner into Outer Shell WARNING a. to outlet Turn off power at the service panel prior to wiring the blower. 1. Connect Electrical Supply (see Electrical Specifications on page 7) a. Route power cord from liner to outlet location and plug in.
-
Page 12: Control Panel
USE & CARE INSTRUCTIONS Control Panel Blower Timer Light Controls Controls Additional Controls: Blower Controls: E – Timer A – Blower power on, power off, low speed Pressing button during blower operation will B – Blower middle speed cause blower to run for 15 minutes at its current C –... -
Page 13: Baffle Filters
USE & CARE INSTRUCTIONS Baffle Filters IMPORTANT The function of the baffle filters is the absorption of grease particles that form during cooking. Do not operate ventilation hood without filters in hood. Baffle filters should be examined periodically to assure that the surfaces and parts are clean. - Page 14 USE & CARE INSTRUCTIONS WARNING Turn off power at the service panel prior to cleaning the hood. For cleaning the hood, it is recommended to use a soft cloth and a solution of warm soapy water. It is important that the soap does not contain granules that could scratch the surface. Follow the direction of the metal grain with the cloth.
- Page 15 “subject to inspection” at the time of delivery. The terms of this warranty provide for repair of the product only. If the product cannot be repaired, Big Chill, at its sole discretion, will Limitations of Coverage determine whether to exchange the product.
