WIKING
width 8m, side height 4m
INstallatIoN INstructIoNs
Introduction
Thanks to the new tent, you have the freedom to plan many activities. It can be used during the event, as protection against
the sun, light, storage and for many other purposes. Please follow the instructions below. This will allow you to use our tent
longer.
Important
Before using the tent, please read the assembly instructions carefully and store it for future reference.
Security
The tent has not been tested for wind and snow loads unless there is a clear indication from the manufacturer. Therefore, these
charges are not covered by the warranty. Please observe the weather forecasts in order to secure the tent or disassemble it if
necessary.

Advertisement

loading
Need help?

Need help?

Do you have a question about the WIKING and is the answer not in the manual?

Questions and answers

Summary of Contents for ROT SERVICE WIKING

  • Page 1 WIKING width 8m, side height 4m INstallatIoN INstructIoNs Introduction Thanks to the new tent, you have the freedom to plan many activities. It can be used during the event, as protection against the sun, light, storage and for many other purposes. Please follow the instructions below. This will allow you to use our tent longer.

  • Page 2: Environmental Protection

    Warnings The tents are intended for temporary use and should be dismantled in case of unfavorable weather conditions. Position the tent at a suitable distance from water, gas and electric hoses, so as not to damage them. Please find out from local suppliers, where all the cables run, so as not to damage them when mounting the tent.
  • Page 3 coNtENt 8x12 8x20 8x12 8x20 Side arch Gable arch, 1122 mm 22 szt 34 szt 11 szt 17 szt 8x12 8x20 8x12 8x20 Roof pipe, 1545 mm Roof pipe with a hole, 1545 mm 22 szt 34 szt 22 szt 34 szt 8x12 8x20...
  • Page 4 coNtENt 8x12 8x20 8x12 8x20 Gate roof bracket, 2093 mm Gate brackets, 1948 mm 12 szt 12 szt 2 szt 2 szt 8x12 8x20 8x12 8x20 Gate roof bracket, 2090 mm Extraction pipe 2 szt 2 szt 20 szt 32 szt 8x12 8x20 8x12...
  • Page 5 coNtENt 8x12 8x20 8x12 8x20 Ratchet tensioner Belt with a drawstring 4 szt 4 szt 20 szt 32 szt 8x12 8x20 8x12 8x20 Tarpaulin Gates 1 szt 1 szt 2 szt 2 szt 8x12 8x20 8x12 8x20 Ground anchor Plastic cap 32 mm 26 szt 38 szt 26 szt...

  • Page 6: Installation Instructions

    INstallatIoN INstructIoNs Find a flat surface to pitch your tent. Unpack the cartons and make sure they contain all of the items listed. Before starting the assembly, wipe off light traces of oil from the structure pipes with a cloth. At lower temperatures we recommend warming the tent tarpaulin to room temperature.
  • Page 7 INstallatIoN INstructIoNs Connect the additional gate roof bracket (18) and (19) to the start sections (on both sides) and connect it in the middle with vertical reinforcement of the gate (7) with the top of the arch. Then, connect the arches with each other using the side pipes (10) and (11). Only 10 pipes are mounted in the front segment, all others are 11.
  • Page 8 INstallatIoN INstructIoNs Set up the tent from one side. Connect the side bends (1) with the legs (8) and (9). Use 4.5 ”screws (31) and wings nuts (32) for fixing. Strengthen the frame with side pipes (10) and (11). Attach the diagonal brackets (12) and (13) to the side legs.
  • Page 9 INstallatIoN INstructIoNs Anagolically to point 4, we proceed with the other side of the structure.
  • Page 10 INstallatIoN INstructIoNs Gates assembly. Remember to fix the fixing screws inside the tent so that their tips do not rub and tear the tarpaulin. Assemble the gate legs (14), (15) and (16) and connect them to the first arch using the gate connector (21).
  • Page 11 INstallatIoN INstructIoNs Setting the structure on the feet. Install the gate feet (25), corner feet (23) and other feet (24), first on one side, then on the other side of the structure. Use 4.5 ”screws (31) with nuts (32). Use the clamping pipe clamp (39) and dowels (40) to mount the frame to the ground. The feet are attached to the ground with an anchor (37), driven it next to the foot and connected with a pin (27).
  • Page 12 Install the gates (36) using the rubbers (26). Tighten the roof trim using a tensioner with ratchet (33). ROT SeRvICe | www.hurtnamiot.pl | ul. Wspólna 1 hala 1 | 45-837 Opole | NIP 7541926089 | tel. +48 510 182 520...
