Summary of Contents for Elefine EF-DM601
- Page 1 EF-DM601 Intelligent Thermal Imaging Thermometer Operation Manual (V1.5) 2020-12...
- Page 2 Statement: 1.The company reserves the right to modify any information in this document at any time. This manual will be updated from time to time, updated content will be added in the new version of the manual without notice. 2. This manual may contain technical inaccuracies or typographical errors. 3.
-
Page 3: Table Of Contents
Version Modification Modification Date V1.3 2020.06.02 Revision V1.4 2020.09.07 Revision V1.5 2020.12.15 Revision2.9 Catalog 1.Outline............................ 5 1.1Characteristics........................ 6 1.2Composition........................7 1.3 Monitor configuration requirements................7 2.Structure and Installation Instructions................7 2.1 Instrument Appearance....................7 2.2.Installation Notes......................8 2.2.1 Shield Installation...................... 8 2.2.2 Line connection......................8... - Page 4 1. HDMI interface: display device access (if the display does not have an HDMI interface, you need to prepare HDMI to VGI or other adapter cables)....9 2. Network port: only needed for platform version............9 3. Power interface: connect 5.5V DC power supply...........9 4.
-
Page 5: Outline
1.Outline EF-DM601 series product is a set of "Intelligent Thermal Imaging Thermometer" carefully developed by our company. according to years of research and development experience and customers' actual needs and market requirements. It can quickly check and alarm people with fever symptoms in the crowd, accurately display the highest temperature value. -
Page 6: Characteristics
1.1Characteristics 1.Non-contact full range human body temperature measurement: Uncooled full real-time, high sensitivity thermal imaging, remote non-contact temperature measurement of human body surface temperature. 2.High frame rate of temperature measurement: Frame rate up to 15Hz, close to real-time imaging through naked eye observation. 3.Temperature measurement accuracy: ±... -
Page 7: Composition
13.Deep learning face recognition algorithm: It can be deployed with independent intellectual property rights dynamic face recognition algorithm to achieve dynamic, high-speed, multi face detection, capture and recognition, and realize fine management of personnels. 1.2 Composition EF-DM601 Series Configuration List: Accessory Name Quantity Unit Remark... -
Page 8: Installation Notes
2.2.Installation Notes 2.2.1 Shield Installation Step 1. Open the tripod packing box and take out the tripod and tripod accessories. 2.2.2 Line connection... -
Page 9: Hdmi Interface: Display Device Access (If The Display Does Not Have An Hdmi Interface, You Need To Prepare Hdmi To Vgi Or Other Adapter Cables)
1. HDMI interface: display device access (if the display does not have an HDMI interface, you need to prepare HDMI to VGI or other adapter cables). only needed for platform version. 2. Network port: 3. Power interface: connect 5.5V DC power supply. 4. -
Page 10: Front-End Software Interface
3.2 Front-end Software Interface The main interface is divided into temperature measurement areas and image display areas: 1. Visible light real-time video display area 2. Real time video display area of infrared thermal imaging 3. Snapshot of normal temperature personnel 4. - Page 11 If the face frame of the thermal imaging screen is not in the middle of the face, you need to calibrate the face deviation, as shown in the figure below, there are 6 temperature measurement positions, from near to far, select the same position frame to adjust left and right.
-
Page 12: Black Body Position Setting(Factory Setting Completed)
1. Select a person with normal body temperature as the temperature calibration model. 2. The model shall stand in front of the temperature measuring line, show him/herself in the center of the infrared display area. 3. Right click to pop up the setting window and select the “IR Position Correction” option. 4. -
Page 13: Alarm Parameter Setting
3.6 Alarm parameter setting The default alarm temperature is 37.3°, if you need to change the setting-alarm parameter setting adjustment. -
Page 14: Refresh Time Setting
This setting is changed according to the site environment If the background of thermal imaging is not high temperature, select normal mode; For example, when the background of thermal imaging is high, select a high temperature environment; (forehead temperature mode, the outside has little influence on temperature measurement, generally placed in an outdoor environment, or the camera is facing a high temperature background such as outdoor) If the temperature measured on site has a large deviation from the temperature measured... -
Page 15: Audio Output Settings
3.9 Audio output settings The camera can be connected to an external speaker, select "3.5mm" Select "HDMI" to directly output to TV or monitor; This option is an audio output interface. If the output cable is HDMI-HDMI cable, you can choose HDMI output. -
Page 16: Platform Connection Settings (Please Contact Technical Staff If Necessary)
3.10 Platform connection settings (please contact technical staff if necessary) The all-in-one machine is connected to the "Suspected Fever Screening and Tracking System", and multiple all-in-one machines can be connected to the platform, which has the effect of data summary display For example: fill in the platform (installation software computer) IP (192.168.1.100) address and the IP (192.168.1.101) address port parameters of the all-in-one machine, click connect, if the connection is successful, the button will turn gray. -
Page 17: Mode Selection Setting
3.12 Mode selection setting Intelligent capture mode: continuous capture, high temperature alert sound. Security check door mode: Normal is one person passing through the security check door. High temperature alarm prompt and normal temperature prompt can be set. -
Page 18: Face Detection Display Setting
3.13 Face detection display setting Visible light area display: display human body temperature on the visible light camera(The capture area cannot be modified） Infrared area display: display human body temperature in infrared area 3.14 Prompt sound setting According to different needs, set the unreasonable temperature prompt sound. Generally, the temperature is normal and not broadcast, only people with abnormal body temperature are broadcast. -
Page 19: Temperature Display Setting
3.15 Temperature display setting Celsius and Fahrenheit are displayed on the software interface. 3.16 Population statistics setting Statistics of people with normal body temperature and abnormal body temperature... -
Page 20: System Language Seting
3.17 System language setting The system language can be modified according to the needs of the system, and currently supports simplified Chinese, English, traditional Chinese, and Polish. 3.18 System version description Show the version number of your current hardware and provide it to the technicians to upgrade accordingly... -
Page 21: System Firmware Upgrade
3.19 system firmware upgrade According to the provided upgrade file, find the corresponding file location and upgrade the program. -
Page 22: Photos Of Normal And High Temperature Personnel
4.Photos of normal and high temperature personnel 1 、 Left-click the "AI face recognition dual-light temperature detection" in the upper left corner of the software, double-click "Savepic", Alarm is a high temperature alarm photo, and "capture" is a normal temperature photo. 2、The picture will generate a big folder every day, which will generate separate folders for different temperature measurement personnel;... -
Page 23: Precautions For Use
6.Precautions for use 1. After the temperature measuring device is turned on, there is about 5-10 minutes of warm-up time. 2. The system software is generally installed at the factory, and it can be turned on when used on site. Do not modify the internal files, otherwise the software will not run.
