Witch v1 Rev. May22 - ASSEMBLY GUIDE
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in
our workshops. The order in which the components are placed on the board is meant to make assembly as
easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before
starting. If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
You will be soldering both boards at the same time. Keeping them in the panel together, until stated to split
them, might help you through the build. Check the last pages of the Build for PCB pics to help you identify
components.
OPEN BAG A
RESISTORS
It's strongly recommended to measure the resistors with a multimeter. Color code might be hard to read
with blue background.
Qty
Value
Code
10
100Ω
Brown, black, black, black, brown
14
560Ω
Green, blue, black, black, brown.
8
1k
Brown, black, black, brown, brown
8
100k
Brown, black, black, orange, brown
6
5k1
Green, brown, black, brown, brown
6
10k
Brown, black, black, red, brown
4
33k
Orange, orange, black, red, brown
4
51k
Green, brown, black, red, brown.
4
1M
Brown, black, black, yellow, brown
2
22Ω
Red, red, black, gold, brown.
2
2k
Red, black, black, brown, brown.
DIODES
Solder the diodes observing their polarity. The black or white line on the diode must match with the white
line on the diode symbol on the PCB silkscreen.
Qty Value
8
BAT85/48
1
1N4007
Name on PCB
D1, D2, D3, D4, D5, D6, D7, D8
D9
Name on PCB
R9, R12, R13, R16, R22, R36, R41, R47, R52,
R57
R20, R21, R25, R27, R28, R29, R30, R33, R48,
R49, R59, R64, R65, R67
R19, R23, R24, R32, R34, R35, R43, R58
R1, R2, R53, R55, R61, R62, R63, R66
R8, R17, R39, R40, R42, R46
R26, R31, R44, R45, R50, R51
R10, R11, R14, R15
R4, R5, R6, R7
R54, R56, R60, R68
R3, R38
R18, R37
1
