SAVE THIS OWNER'S MANUAL FOR FUTURE REFERENCE
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE
YOU INSTALL AND USE YOUR NEW OUTDOOR GRIDDLE.
If this griddle is not properly installed, a house fire may result.
To reduce the risk of fire, follow the installation instructions.
CONTACT LOCAL AUTHORITIES WITH JURISDICTION (BUILDING DEPARTMENT or
FIRE OFFICIALS), ABOUT PERMITS REQUIRED, RESTRICTIONS AND INSTALLATION
INSPECTION IN YOUR AREA.
California Prop 65
WARNING:
This product can expose you to chemicals including
glass wool fiber and carbon monoxide which are known to the State of
California to cause cancer, birth defects or other reproductive harm. For
more information go to www.P65Warnings.ca.gov
For more information visit
www.hearthstoneoutdoor.com
Outdoor
Griddles
Brabura 40 (Model 830-3852)
Brabura 32 (Model 830-3052)
Brabura 22 (Model 830-2052)
OWNER'S MANUAL
Installation and
Operating Instructions
Brabura 40 (Model 830-3852)
Brabura 32 (Model 830-3052)
Brabura 22 (Model 830-2052)
Outdoor Griddles
Manual: 6400-41431
(BG223240 ED00)
R: 4/18/2022
Advertisement
Table of Contents
Summary of Contents for HearthStone Brabura 40
- Page 1 Outdoor Griddles Brabura 40 (Model 830-3852) Brabura 32 (Model 830-3052) Brabura 22 (Model 830-2052) OWNER’S MANUAL Installation and Operating Instructions SAVE THIS OWNER’S MANUAL FOR FUTURE REFERENCE PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE YOU INSTALL AND USE YOUR NEW OUTDOOR GRIDDLE.
-
Page 2: Table Of Contents
Installation - Built-in ..........................21 Care and Cleaning ..........................23 Conversion to Natural Gas ........................24 Conversion to Liquid Propane ......................30 Conversion Checklist..........................31 Troubleshooting ........................... 32 Installer Checklist ..........................33 Accessories ............................34 HearthStone Quality Home Heating Products, Inc. ®... -
Page 3: Introduction
Read and follow all warnings and instructions before assembling and using the appliance. Follow all warnings and instructions when using the appliance. Keep this manual for future reference. For support information on using your HearthStone Outdoor Griddle, go to www.hearthstoneoutdoor.com SAFETY AND WARNINGS DANGER... -
Page 4: Safety And Warnings
It is not intended to be installed in or on a boat. HearthStone Quality Home Heating Products, Inc. and BRABURA Griddle cannot be held responsible for any damage incurred to objects or people resulting from incorrect installation or use of the griddle. -
Page 5: Griddle Features
GRIDDLE FEATURES Enameled Cast Iron The enameled cast iron griddle has incredible heat retention properties that sears foods perfectly, distributes heat for even cooking. The enameled surface is durable, non-stick, and cleans up easily. High Quality Construction The chassis and lid are constructed from heavy duty 304 stainless steel for easy cleaning and corrosion resistance. - Page 6 20 lb. LP cylinder (Type 1). The LP tank is not included. The griddle system is leak tested. Independent Burners HearthStone Outdoor Griddles are equipped with a thermocouple and safety valve system which monitors each burner. This will turn the gas off if the burner is not lit.
-
Page 7: Specifications
SPECIFICATIONS Brabura 40 Brabura 32 Brabura 22 Model Number 830-3852 830-3052 830-2052 Number of Burners BTUs per Burner 9,000 9,000 9,000 Total Surface BTUs/hr 36,000 27,000 18,000 Griddle Area 648 sq.in. 508 sq.in. 333 sq.in. Griddle Surface Dimension 37’’ x 17 1/2’’... -
Page 8: Griddle Dimensions
613mm 4 3/4" 1024mm 120mm 19 11/16" 500mm 8 1/4" 7 3/16" 210mm 182mm 8 1/4" 210mm Front Side 40" 23 15/16" 1016mm 609mm 37 15/16" 18 1/2" 963mm 470mm HearthStone Quality Home Heating Products, Inc. ® 4 3/4" 120mm... -
Page 9: Product Assembly
PRODUCT ASSEMBLY Packing list: Lid with parts and hardware for the handle and hinges, see below Enameled cast iron griddle Enameled Cast Iron Griddle Griddle chassis, fully assembled NG conversion kit Chassis (orifice and conversion label) Some assembly is required to complete your griddle. - Page 10 3. Capture the opposite end of the handle with the left end cap and attach it to the lid with 2 M6 screws 4. Remove the 2 lid brackets from the griddle chassis by removing 2 M4 screws from each bracket. HearthStone Quality Home Heating Products, Inc. ®...
- Page 11 5. Attach the hinge brackets to the lid as shown. The components should be stacked in the following order from the outside in: M6 flat head screw - bearing - lid - washer - lid bracket - acorn nut. Attach the 2 rubber bumpers by pushing them into the holes on the lid as shown. 6.
- Page 12 Note: Be sure to place the griddle in the proper direction, so the backsplash is at the back of the appliance and the grease drain at the front. CORRECT INCORRECT HearthStone Quality Home Heating Products, Inc. ®...
-
Page 13: Battery Installation And Replacement
BATTERY INSTALLATION AND REPLACEMENT Batteries are required to power 2 separate systems in your griddle, burner ignition and LED knob lighting. Your Griddle is delivered with 5 AA (1.5V) batteries to power these systems. Ignition The piezoelectric unit requires 1 AA battery to provide continuous spark ignition to each burner. LED Knob Lighting The LED knob lights require 4 AA batteries installed in the battery holder located on the bottom of the griddle chassis in the front corner. -
Page 14: Gas Connections
3. SUIVRE TOUTES LES MISES EN GARDE ET LES INSTRUCTIONS LORS DE L’UTILISATION DE L’APPAREIL. 4. SI VOUS N’AVEZ PAS TOUTES LES INSTRUCTIONS OU LES PIÈCES, COMMUNIQUEZ AVEC VOTRE FOURNISSEUR. 7.0” W.C MODEL: 830-3852 SERIAL NUMBER: G4022xxxx HearthStone Quality Home Heating Products, Inc. ®... - Page 15 GAS CONNECTIONS LP Connection The Griddle is factory set for LP gas. It comes equipped with an LP hose/regulator assembly for connection to a standard 20 lb. LP cylinder (Type 1). The LP tank is not included. The griddle system is leak tested. Do not remove the Regulator/Hose assembly from the product during cart installation.
-
Page 16: Leak Testing
Advice: Before each use of the Griddle, clean and inspect the hose. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to the appliance being put into operation. The replacement hose assembly must be: LP regulator hose assembly 11" W.C. HearthStone Quality Home Heating Products, Inc. ®... -
Page 17: Lighting Instructions
LIGHTING INSTRUCTIONS HearthStone Outdoor Griddles are equipped with a thermocouple and safety valve system which monitors the burner. This will turn the gas off if the burner is not lit. 1. Open the lid and remove any cooking utensils. Ensure the grease tray is in place and all the knobs are on the OFF position. -
Page 18: Manual Lighting Instructions
3. Once the burner is lit, adjust the heat by turning the knob to the desired high/low position. 4. To shut the Griddle off, turn the cylinder valve to the OFF position, then turn all the control knobs on the appliance clockwise to the OFF position. HearthStone Quality Home Heating Products, Inc. ®... -
Page 19: Installation
INSTALLATION HearthStone Outdoor Griddles must be located outdoors only. As with any gas appliance, harmful carbon monoxide is produced during the combustion process that should not be allowed to accumulate in a confined space. Also, since hot air rises above the Griddle while in operation, covered locations should be avoided. -
Page 20: Installation - Countertop
The enclosure should have ventilation holes to prevent gas build-up in the event of a leak. HearthStone recommends installing the manual shut-off valve in a location readily accessible by the customer, so that gas to the appliance can be shut off in an emergency situation. However, the appliance must not be modified in any way to accommodate such placement. -
Page 21: Installation - Built-In
The enclosure should have ventilation holes to prevent gas build-up in the event of a leak. HearthStone recommends installing the manual shut-off valve in a location readily accessible by the customer, so that gas to the appliance can be shut off in an emergency situation. However, the appliance must not be modified in any way to accommodate such placement. - Page 22 Build-in Liners To install the Griddle into a enclosure constructed of combustible materials, use only the HearthStone Outdoor Build-in Liner appropriate for the Griddle model. Our Build-in Liners have been specifically designed and tested for this purpose.
-
Page 23: Care And Cleaning
3. Use a microfiber pad to polish the enameled cast iron cooking plate until it shines. If your Griddle will be not used for a long time, it is recommended to store it in a dry place and protect it with a HearthStone Outdoor fabric cover. Stainless steel chassis cleaning Always use the mildest cleaning method first. -
Page 24: Conversion To Natural Gas
NG burner orifices (1.30) are included with your Griddle. You should have an NG orifice for each burner, x2 (Brabura 22), x3 (Brabura 32), x4 (Brabura 40). An NG conversion label is also included and should be filled out and affixed to the Griddle when converted. - Page 25 CONVERSION TO NATURAL GAS CAUTION Read and follow all safety statements, assembly instructions, and use and care directions before attempting to assemble and cook. WARNING FIRE, EXPLOSION, AND CARBON-MONOXIDE HAZARD If the information in these instructions is not followed exactly, a fire, explosion, or production of carbon monoxide may result causing property damage, personal injury, or loss of life.
- Page 26 2. Ensure that the LP tank is closed. 3. Disconnect the LP regulator hose assembly from the LP tank. 4. The enameled cast iron griddle will need to be removed to access the burners. * Example image: Brabura 40 Griddle HearthStone Quality Home Heating Products, Inc. ®...
- Page 27 CONVERSION TO NATURAL GAS 5. Unscrew the 2 M4 retaining screws from the burner. 6. Remove the burner. * Example image: Brabura 40 Griddle Outdoor Griddles (Models 830-3852, 830-3052, 830-2052)
- Page 28 CONVERSION TO NATURAL GAS 7. Unscrew the orifice (LP, 0.88). 8. Screw on the NG orifice, 1.30. * Example image: Brabura 40 Griddle HearthStone Quality Home Heating Products, Inc. ®...
- Page 29 CONVERSION TO NATURAL GAS 9. Replace the burner. 10. Screw in the 2 retaining M4 screws to secure the burner. * Example image: Brabura 40 Griddle Outdoor Griddles (Models 830-3852, 830-3052, 830-2052)
-
Page 30: Conversion To Liquid Propane
To do so, follow the steps for conversion to liquid propane and change the orifice for each burner to the LP orifice, 0.88. ORIFICE SIZES FOR LIQUID PROPANE (LP): 0.88 FOR NATURAL GAS (NG): 1.30 * Example image: Brabura 40 Griddle HearthStone Quality Home Heating Products, Inc. ®... -
Page 31: Conversion Checklist
CONVERSION CHECKLIST Verify the Natural Gas Connection ˆ Check that the air shutter and burner ports are clear ˆ Check that the location of the ignition electrode and thermocouple with respect to the burner is correct ˆ Check that the location of the burner and the nozzle is correct and make sure that the nozzle is inside of the burner ports ˆ... -
Page 32: Troubleshooting
Knob halos do not illuminate Faulty batteries Change the batteries Batteries in wrong direction Confirm direction of the batteries Bad grease flow Griddle positioned incorrectly Confirm griddle positioning Grease tray positioned incor- Confirm grease tray positioning rectly HearthStone Quality Home Heating Products, Inc. ®... -
Page 33: Installer Checklist
INSTALLER CHECKLIST Read the owner’s manual to verify that the Griddle has been correctly installed. Ensure that installation has been completed correctly before use. Clearances are correctly maintained to combustibles ˆ ˆ Proper enclosure ventilation has been verified ˆ All protective films have been removed for the metal surfaces The burners are set in the correct position ˆ... -
Page 34: Accessories
ACCESSORIES Use our full line of accessories to design your outdoor kitchen around your HearthStone Outdoor Griddle. Rolling Bases Extend your outdoor kitchen with a freestanding griddle, or roll the griddle wherever the gathering happens. All stainless steel construction. Locking caster wheels. - Page 35 Grease Tray Liners Disposable foil liners fit in the grease tray of all HearthStone Outdoor Griddle models. Sold in 5 pack bundles. 932-00300 Cooking Covers Use these tall covers to trap heat and steam around vegetables or meats while they cook. Cooking covers seal against the cooking surface to keep foods moist and delicious.
- Page 36 Take The Party Outside www.hearthstoneoutdoor.com Hearthstone Quality Home Heating Products, Inc. 317 Stafford Avenue, Morrisville Vermont 05661 USA...
