H14012BR
V1.0
Vintage Five-layer Shelf > Manual
Thank you for purchasing Aoxun products. Please contact us if you have di culty with assembly or
need replacement parts. Aoxun customer service is here to assist you.
Email: cx4amz@hotmail.com
Please attach your User Name or Order ID so that we can assist you better.
EN
WARNING
The product must be assembled by adult before use.
Serious or fatal injury may occur from unexpected assembly or use.
1. During the assembly process, keep all parts away from babies or children.
2. Always securely x this product to the wall. Make sure the wall area to be drilled is free from hidden
electrical wires, water and gas pipes.
3. Use of tip-over restraints may only reduce, but not eliminate the risk of tip-over.
4. Unless specially designed to accommodate, do not set heavy objects on top of this product.
5. Place the heaviest items on the lowest shelf.
6. Never allow children to climb or bang on drawers, doors or shelves.
- 1 -
