Summary of Contents for cphnano SpectroLink USB650
- Page 1 U se r M a nua l SpectroLink D ig it ize your UV-Vi s wor kfl ow cphnano.com Hørmarken 2, 3520 Farum, Denmark. Tel: +45 36 99 27 46 sales@cphnano.com...
-
Page 2: Table Of Contents
1. Disclaimer 2. Safety information Handling Repair & service Powering your device Radio frequency interference Medical device interference Child safety 3. Disposal and recycling information 4. Warranty 5. Welcome to SpectroLink™ 6. What is in the box 7. Prerequisites 7.1 App for setting up WiFi on SpectroLink™ WiFi setup 8. -
Page 3: Disclaimer
1. Disclaimer The information in this document is subject to change without notice and does not represent a commitment on the part of Copenhagen Nanosystems ApS. “SpectroLink™”, “SpectroWorks™” and associated logos are trademarks of Copenhagen Nanosystems ApS. All other trademarks are the property of their respective owners and use of them does not imply any affiliation with or endorsement by them. -
Page 4: Safety Information
Contact customer service and do not use your device if it isn’t working properly or has been damaged. For online help and support, visit spectrolink.cphnano. com. To reach an expert, visit https://knowledge.cphnano.com/en/pages/sup- port-for-spectrolink. -
Page 5: Radio Frequency Interference
Using a damaged cable or power adapter can cause fire, electric shock, injury, or damage to your device or other property. When powering the device make sure the power adapter is plugged into a socket near the device and is easily accessible. -
Page 6: Disposal And Recycling Information
3. Disposal and recycling information The WEEE symbol above means that according to local laws and regulations, your product should be disposed of separately from household waste. When this product reaches its end of life, take it to a colle- ction point designated by local authorities for safe disposal or recycling. -
Page 7: What Is In The Box
7. Prerequisites • Your SpectroLink™ along with its box contents. • A currently supported spectrophotometer with USB connectivity. • Check yours at https://spectrolink.cphnano.com/ supported-spectrophoto meters - We also have a guide for setting good parameters before measurements for each supported spectrophotometer (more on this later). -
Page 8: App For Setting Up Wifi On Spectrolink
To set up WiFi, an app needs to be installed on an Android or iOS based device. Get it here or via the QR code below: https://spectrolink.cphnano.com/setup The WiFi setup is as follows: Install the WiFi connect tool, BerryLan, on an Android or iOS based device from the Google Play or App Store. -
Page 9: Ethernet Setup
2. The app immediately starts searching for your SpectroLink™. It should appear as CPHNANO after around 50s from powering it on. Tap on it and proceed. 3. On the next view, the app asks you to choose an access point. Select the one you would like to connect with your SpectroLink™. -
Page 10: Access Spectrolink™ In Spectroworks
Access SpectroLink™ in SpectroWorks™ Now you can access our online software SpectroWorks.com to start measuring, analyzing and reporting results. 1. From SpectroWorks.com, click “Log-in” to access your SpectroWorks™ account. Here you canenter your login credentials or create an account. 2. You will either enter the last accessed project with the list of finished or ongoing workflows, or be directed to the project overview, where you can select a project or create a new one. - Page 11 3. In the tab menu on the top left, click on the “SpectroLink” tab to see the SpectroLink™ grid view. Each SpectroLink™ contains a unique device code that is located on the bottom of the unit. This code is used to link your SpectroLink™ to your SpectroWorks™...
-
Page 12: Using Your Spectrolink™ Device
9. Using your SpectroLink™ device 9.1. Creating a new project To create a new project, click “New”. A results modal appears. Name your project and select the type of results you’d like to see for the measure- ments. This can always be changed later. Notice that the type of results depends on the cuvette type used. -
Page 13: The Spectrolink™ Dashboard
9.2. The SpectroLink™ dashboard From the grid view, click on your SpectroLink™. It will appear with the de- fault name: “My SpectroLink™”. The SpectroLink™ dashboard will either show you a frozen view if your spectrophotometer is not connected or the normal view to control it, if it is connected. -
Page 14: Scanning Spectrophotometer
If you are using your SpectroLink™ for the first time with your spectrophotome- ter, it is recommended to check the parameters and set the required baseline etc. depending on your spectrophotometer type before you proceed to do mea- surement flows. 9.2.2. -
Page 15: Diode Array Spectrophotometer
9.2.3. Diode array spectrophotometer For a diode array type spectrophotometer, you will typically find these pa- rameters and controls in the dashboard: • Lamp control (ON/OFF) • Integration time (ms) • No. of scans • Setting the light source spectrum •... -
Page 16: Network Discovery
9.4. Network discovery For certain use cases you may want your SpectroLink™ to be visible for all SpectroWorks™ users on the same network. They can in this case see and access the SpectroLink™ without registering its device code. Assuming you are on a secure network you can enable “Network discovery” from the Properties screen in the SpectroLink™... -
Page 17: Software Updates
9.6. Software updates To provide the best service and support, we are constantly working on ca- pabilities of your SpectroLink™ by providing software updates over the air. Depending on the update type, these updates can extend the functionality of your SpectroLink™ by extending the range of supported spectrophoto- meters, while providing bug fixes and other overall improvements to the product. -
Page 18: Tutorial
Once you’ve set the parameters of your choice for your spectrophotometer, we can now try our first sample measurement. Please visit our knowledge base for information, tutorials and FAQs on Spe- ctroWorks and our other products via https://knowledge.cphnano.com/en/ pages. 10.1. Setup spectrophotometer for measurement... -
Page 19: Basic Measurement
10.2. Basic measurement 1. Go to the “Create” tab located in the top left. 2. Get hold of a basic cuvette or just use any NanoCuvette™ for testing. This example uses a NanoCuvette™ One. 3. Use a sample of your choice and place the cuvette in the clear path (whe re the light path does not go through the crystal) in your spectrophotome ter. - Page 20 6. Your SpectroLink™ will now communicate with your Spectrophotometer to ask for a spectrum, your instrument performs the measurement and du ring the measurement the canvas will get plotted with the attenuance spectrum. 7. Once the capture has completed, proceed by clicking “Finish” in the bottom right corner.
