Summary of Contents for DONKERVOORT D8 GTO 2018
- Page 1 D8 GTO QUICK START GUIDE NO COMPROMISE...
-
Page 2: Table Of Contents
YOUR GTO welcome to the Donkervoort family and congratulations on owning a Donkervoort! We wish you a lot of driving pleasure and we hope you will enjoy the Donkervoort experience on the whole. This booklet is a quick start guide to provide you with all the necessary - DRIVING basic - information about your car and how to use it. - Page 4 6 POINT HARNESS The 6 point harnesses can only be locked into the central locking Your Donkervoort can be equipped with an optional racing ABS Unlock the car using the lower button on the key Turn the key to the left unit when the long part of the locking unit is facing downwards.
-
Page 5: Display
DIGITAL DISPLAY* TRACKMODE Both MXL2 and the optional MXS Pista Displays are equipped with a lap timer system. The Speed in Km/h (GPS speed) laptimer system uses GPS location to show your lap time. This laptimer can be accessed through the menu and data from the lap timer can be downloaded directly on your Trip odometer computer via the wifi network of the display. -
Page 6: Steering Wheel
STEERING WHEEL REMOVING THE STEERING WHEEL Push the ring at the back of the steering wheel towards the back of the car B = Override Bleep feature While keeping the ring pushed in, pull the steering wheel towards the seat Horn Remove the commands connector by unscrewing the connector P = Pass / High beam flash... - Page 7 SUSPENSION SETUP Counter clockwise Clockwise Setting starting position N° of clicks Rebound Faster rebound Slower rebound Fully turned clockwise PRELOAD / RIDE HEIGHT High speed compression Softer Harder Fully turned counter clockwise Low speed compression Softer Harder Fully turned counter clockwise HIGH SPEED COMPRESSION 4th adjustment / Softer curve...
- Page 8 TRACTION CONTROL (TC) SPORT MODE Flip up the Sport switch to activate the Sport mode. When the Sport mode is activated a green led light will burn above the command. The sport Position 0: The TC is disabled mode activates the three following features: Position 1: This position is the one is called Track-Dry-Slicks, this configuration is programmed to provide the best results for the power and the traction when driving on track in dry conditions.
-
Page 9: Engine Bay
ENGINE BAY To remove the bonnet, first release the four closures you can find on the corners of the hood. Release these closures by pressing the buttons and then lift the back of the hood and slide the front metal lip out of the nosecone. - Page 10 INTERIOR Kill switch First lift the red protection, then flip up the switch to connect the battery Launch / Sport Adjusts the throttle for perfect launches starts (5 launches covered by the warranty), activates the sport mode including different features - See page 15 Hazard Flip this button to signal a danger Fog light switch...
-
Page 11: Roof Installation
PLASTIC LIP TENSION BAR Donkervoort cars come equipped with a fabric roof as standard. This roof can be folded to be placed in the trunk of the car. When installed correctly, the roof can be used at all speeds. Please note that the light weight of the car and the absence of electronic assistances make rain driving more demanding for the driver. -
Page 12: Doors
DOORS FUSES GTO-RS To open the door from the outside, slide your finger under the metal handle located at the end of the door and lift it. Then pull the door towards you until it is fully open. Be careful not to push the door upwards too strong as this can damage the fixations FUSE BOX A FUSE BOX B of the dampers. - Page 15 1800 3800 DIMENSIONS All data in millimeters. The dimensions shown are average values. They are valid for the Donkervoort GTO RS in basic equipment and in unloaded condition. 2350 1846...
- Page 16 YouTube channel where you will right camber link. in the engine compartment. In the trunk, the find videos about your Donkervoort and how to chassis number is located on the right shock use it. In this part you can namely find an expla- (See green point on the picture) ...
- Page 17 All texts, photos and other data in this publication are the copyright of Donkervoort Automobielen B.V. Any reproduction, duplication or other use of this material is prohibited without the prior written consent of Donkervoort Automobielen B.V. Photography: G.F. Williams, feinschliff.com, Donkervoort Automobielen B.V., Design: feinschliff.com, © Donkervoort Automobielen B.V. & GmbH 2018 DONKERVOORT AUTOMOBIELEN B.V.
