Summary of Contents for Linkstyle Smart Air Pump
- Page 1 Smart Air Pump Full User Guide v0.8...
-
Page 2: Product Contents
Product Contents 1 x Smart air pump 1 x Flexible hose (Schrader valve head) 1 x Presta valve adapter 1 x Ball pump needle 1 x Swim ring valve adapter 1 x USB-C charging cable... - Page 3 Operations Charging Connect the air pump to a USB power source using the included USB-C charging cable. It is recommended to use a 5V / 2A adapter to charge the pump. Charging Indicator Green light: 60% to 100% charged Yellow light: 30% to 60% charged Red light: 0% to 30% charged Power On Pull out the air hose and the pump will turn on...
- Page 4 Button Operations U: Unit/light button Short press to toggle between display units: PSI, BAR, KPA, and kg/cm2 Press and hold to turn flashlight on and off M: Mode button Press to toggle between Car, Motorcycle, Bicycle, Ball, and Custom modes Power Button: Short press to start or stop inflation Press and hold for 5 seconds to enter Bluetooth...
- Page 5 Start Inflation Short press the Power button to start inflation. The Measured Pressure portion of the display will show the current air pressure as it changes. The air pump will generate noise and heat during inflation. Avoid prolonged contact with hose and hose joints with your hand. Stop Inflation When measured pressure reaches the preset pressure, the pump will stop inflation automatically.
- Page 6 Measuring Pressure After turning the air pump on, connect it to the object to be measured and the Measured Pressure portion of the display will show the measured pressure. Resetting the Device If the measured pressure is not zeroed when the air pump is on and not connected to an object, press and hold the + and - buttons together for 3 seconds to reset the device.
-
Page 7: Smart Functions
Scan the QR code below to download and install the Linkstyle app. Register a new account on the app if you do not have one. *Alternatively, you can also search for “Linkstyle” on the Apple App Store or Google Play Store to find the app. - Page 8 Add Air Pump to App From the "Devices" page of the Linkstyle app, click the "Add" button to add a new device. Press and hold the Power button on the air pump for 5 seconds until the LED lights start flashing.
- Page 9 Notes & Specifications Note: This device has been cleaned from the factory. When difference in altitude or sensor tolerance causes measured pressure to not show zero, cleaning the air pump can improve pressure measurement accuracy. Attention: Do not leave device unattended while in use. Keep away from combustibles and explosives.
- Page 10 Product Specifications Maximum Inflation Pressure: 150PSI No-Load Flow: 20L/M Charging Temperature: -10 C to 60 C Working Temperature: 0 C to 60 C Battery Capacity: 2000 mAh, 3.7V, 14.8WH Charging Input: 5V/2A USB Output: 5V/1.5A Charging Time: 2 to 3 hours...
- Page 11 Apple and Apple logos are trademarks of Apple, Inc., registered in the U.S. and other countries. App Store is a service mark of Apple, Inc. Amazon, Alexa, and all related logos are trademarks of Amazon.com Inc. or its affiliates. Google and Google Play are trademarks of Google LLC. Other third-party brands and names are the property of their respective owners.
Need help?
Do you have a question about the Smart Air Pump and is the answer not in the manual?
Questions and answers
Won't charge after I plugged it into USB or 110 outlet.
The Linkstyle Smart Air Pump may not charge when plugged into USB or a 110V outlet due to the following reasons:
1. Incorrect Adapter – The pump requires a 5V / 2A adapter. A lower-power adapter may not provide enough current.
2. Faulty USB-C Cable – The included USB-C charging cable may be damaged or not properly connected. Try using another compatible cable.
3. Bad Power Source – The USB power source or 110V adapter may not be functioning correctly. Test with a different power source or outlet.
4. Battery Issue – If the pump’s battery is completely drained or faulty, it may not charge properly.
5. Connection Issue – Ensure the USB-C connector is fully inserted into the pump’s charging port.
If none of these resolve the issue, the pump may have a hardware defect.
