KOZIS FlexLamp PL5001 User Manual

EN
CAUTION –
RISK OF PERSONAL AND PROPERTY DAMAGE
■ Do not connect the product to a computer, as the high charging
current could damage the computer.
■ Do not use if there is visible damage to the product or the con-
nection.
■ Do not cover the product during operation, and ensure that
there is sufficient air circulation.
■ Protect the product from: impact, direct sunlight, sub-zero tem-
peratures.
■ Do not place any heavy objects on the product or its connec-
tion.
■ Lay the connection in such a way that it is not crushed or bent
and does not come into contact with hot surfaces.
■ Turn off and unplug the product immediately in case of damage
or malfunction.
■ Unplug the power adapter from the outlet before a storm.
■ Only use original accessories from the manufacturer so as not
to impair the functioning of the product and to prevent possible
damage.
■ To protect the surface, do not use corrosive or abrasive clean-
ers. Wipe the product with a damp cloth as required. Then dry
it off.

Product Overview

8
7
6
Customer Service / Importer:
QX Brands, Marietta GA 30068 USA
2020 QX LLC | All Rights Reserved.
www.qxbrands.com
Assembly Instructions on Next Page
1 Touch Swit ch
1
2 Lam p Head
2
3 LED Array
3
4 Lamp Post
5 Lamp Base
6 Charging Port
7 Flexible Neck
8 Indicator Light
4
5
FlexLamp
User Guide

Before First Use:

1. Remove any packaging films, stickers or transport
protections from the product. Never remove the type labels!
2. Assemble the FlexLamp according to intended usage (Floor Lamp, or
Desk Lamp), see next page for assembly instructions.
3. Charge the battery (see the chapter "Charging the battery").

Charging the Battery:

PLEASE NOTE!
■ Use a USB power adapter that has an output current at least
1A. Do not use a computer USB port to charge!
■ Make sure the power outlet the USB power adapter is
plugged into has been properly installed. The outlet should be
easily accessible, so that the charger can be quickly discon-
nected if need.
1. Connect the USB cable to the lamp's charging port (6) and
a USB power adapter.
2. Plug the USB power adapter into a power outlet. The
indicator light (8) will illuminate while charging.
The battery is fully charged when the indicator light shuts off.
3. After charging, unplug the USB power adapter from the outlet
and then the USB cable from the lamp's charging port (6).

Usage

1. Place the lamp on a dry, level surface.
2. Turn the lamp head (2) to the desired position.
3. Tap the Touch Switch (1) to operate the lamp:
Tap once: warm white light
Tap again: universal white light
Tap again: cool white light
Tap again: Off
4. To set the brightness, tap and hold the Touch Switch (1) while
the lamp is on. Release the switch when the desired brightness
is reached.
T echnical data
Model number:
Color temperature:
Brightness:
Ra:
Power Input:
Battery Capacity:
Charging time:
Operating time:
Power:

Disposal

TM
PL5001
2800K / 5200K / 6500K
Max. 330 lm
>85
DC 5V 1A
LiPo battery 3.7V 5000 mAh
Approx. 8 hours
Approx. 5 – 6 hours with one charge,
up to 20 hours depending on the
brightness level
5W
Please dispose of packaging materials in an
environmentally friendly way and take recyclables
to collection facilities.
This product is subject
Directive 2012/19/EU on
and Electronic Equipment (WEEE). Do not
dispose of the product with built-in battery as
normal household waste, but through
authorised waste disposal company in an
environmentally friendly way.
to European
Waste Electrical
an
Page 1/2
