- Page 1 WALL/CEILING MOUNT FOR CVE-SERIES SPEAKERS Instruction Manual (English)
-
Page 2: Table Of Contents
CERWIN-VEGA PROFESSIONAL Read all operating instructions and safety information in this manual before using the accessory. Failure to follow these safety instructions could result in personal injury or damage to the speaker or other property. Contents IMPORTANT SAFETY INSTRUCTIONS ............................3 Introduction .................................... -
Page 3: Important Safety Instructions
It is essential that this accessory is firmly secured to the wall/ceiling. Consult a qualified source for selection of proper installation fasteners. It is the user’s responsibility to ensure that this accessory is installed securely. Cerwin-Vega cannot be held responsible for damage caused by improper use of this accessory. -
Page 4: Introduction
CERWIN-VEGA PROFESSIONAL Introduction Congratulations! Welcome to the Cerwin-Vega family! You’ve joined a growing group of audio professionals who have turned to Cerwin-Vega for the most advanced audio reproduction systems available. All Cerwin-Vega products are thoroughly tested to ensure that they meet or exceed our performance specifications. Backed by the best service in the industry, Cerwin-Vega is dedicated to quality and reliability. -
Page 5: Example Use
CERWIN-VEGA PROFESSIONAL Example Use Ceiling Mount Wall Mount... -
Page 6: Supplied Parts And Hardware
CERWIN-VEGA PROFESSIONAL Supplied Parts and Hardware Before starting assembly, please inspect the contents to confirm that all of the items below are included and undamaged. If any parts are missing or damaged, contact Gibson Customer Service. Never use damaged parts. -
Page 7: Mounting Instructions
Step 1 – Remove the handles on the back of the speaker by using a 4mm hex wrench to loosen the screws. (Note: the CVE-10 does not have an upper handle; instead, remove the Cerwin-Vega plate as shown below.) CVE-12 and CVE-15... - Page 8 CERWIN-VEGA PROFESSIONAL Mounting Instructions (continued) Step 2 – Using the screws from Step 1, secure the Speaker Brackets (❸) to the locations from which the handles were removed. ❸...
- Page 9 CERWIN-VEGA PROFESSIONAL Mounting Instructions (continued) Step 3 – Use the screws (❹), washers (❺), and nuts (❻) to secure the Upper U-Channel (❶) and Lower U-Channel (❷) together. Make sure that the pieces are assembled in the position that fits your speaker.
- Page 10 CERWIN-VEGA PROFESSIONAL Mounting Instructions (continued) Step 4 – Drill holes in the wall or ceiling according to the hole pattern below. Install the U-channels using screws/anchors suitable for your installation. It is essential that this accessory is firmly secured to the wall/ceiling. Consult a qualified source for selection of proper...
- Page 11 CERWIN-VEGA PROFESSIONAL Mounting Instructions (continued) Step 5 – Secure the speaker onto the U-channels by installing the Thumbscrews (❼) through the top and bottom Speaker Brackets. ❼...
- Page 12 CERWIN-VEGA PROFESSIONAL Mounting Instructions (continued) Step 6 – Install a Thumbscrew (❼) though each of the Speaker Brackets to secure the speaker at the desired angle.
- Page 13 CERWIN-VEGA PROFESSIONAL Mounting Instructions (continued) Step 7 – It is recommended to use safety cables to attach the speaker to the mounting bracket. Safety cables can be attached to the extra holes in the U-channels and unused holes in the Speaker Brackets.
-
