- Page 2 Thank you for choosing ExacMe Brand trampoline. Safe use of a trampoline also requires adequate knowledge of technique, as well as what not to do. Please read this manual thoroughly for key points of safety. 1.Warning -------------------------------------------------------------------------------------- 2/3 2.Part List--------------------------------------------------------------------------------- ------4/5 3.Assembly -------------------------------------------------------------- 6/7/8/9/10/11/12/13...
- Page 5 Part List Part Part Part Name Part Image Letter Amount Long Frame Rail Short Frame Rail Left L-shaped Frame rail Right L-shaped Frame rail Leg Extension W-leg Frame Cover Cable Tie Bolt,washer,nut Allen Key Jumping Mat...
- Page 6 Part List Part Part Part Name Part Image Letter Amount Spring Spring Puller Upper Net Pole Lower Net Pole Pole Foam Tube(Black) Pole Cap(Black) Pole Sleeve Straight Top Rod Left L-shaped Top Rod Right L-shaped Top Rod Ladder Enclosure Net...
- Page 7 Top rail / Frame Step 1 There are total 4 L-shaped frames and 4 straight frames. Before assembly, put all the frames on the ground. Ensure that the sides of frames with spring holes face up. The square holes for the net pole are inside of the frames. There should be total 13 pcs spring hole on the wide side and 17 pcs spring hole on the long side once the frame is fully assembled.
- Page 8 W-leg and leg extension Step 2 Step 3 Leg and Top Frame tep 2...
- Page 9 Step 4 Jumping mat and Springs 1.Please firstly install 4 springs as the following picture. 2.For the rest springs,It is better at least 2 people to install from different side with the spring puller. Notice ● Do not assemble the spring one by one which may cause deformation due to uneven force. ●...
- Page 10 Step 5 Spring Cover Attach the pad to the frames and the triangle rings of the jumping mat with cable ties. Step 6 Enclosure Set Step 5 Combine the upper and lower pole into a complete pole PROBLEM: Rectangular Dent on the bottom pole The rectangular dent on the bottom is designed as that way, which will make the net poles more stable and safer, and not wobble.
- Page 11 Slip the pole to black sleeve Assembly all the poles to the frames Enclosure Net Step 7 Step 5 Surrounding Steel Rods Assembly 1.Please find the parts below...
- Page 12 2. The START POINT is aligned with the door entrance of the net.Just identify the entrance and start assembly here by Clockwise. zipper 3.How to assembly? ● Slip a rod #S and a rod #T into the START POINT of the net webbing. Then connect as the following pictures show. ●...
- Page 13 PROBLEM Cannot connect the last 2 steel rods? Check each connection and ensure all are properly screwed and locked. ● For the last 2 rods, it is better 2-3 people to do it. ● Making adjusting of the top sleeves. ●...
- Page 14 Ladder Step 7 Step 5 DISASSEMBLY To disassemble, please follow the trampoline and enclosure net combination assembly steps in reverse order. Do not attempt to disassemble any trampoline fame parts before the springs and jumping mat have been completely removed.
