Summary of Contents for GOOROO CONTROLLERS LIO BOX
- Page 1 USER MANUAL V 10/21...
- Page 2 It is synchronized in real time with Ableton and displays the current Ableton mode, the playing status, connection status as well as the playing track. The LIO BOX also allows you to create and save setlists within the box, and thus rearrange the list without having to modify the Ableton session.
- Page 3 Bouton/Pad FW – Fast Forward , change next track Bouton/Pad PAUSE – Pause and resume playing / STOP Encoder with selection – Menu navigation / select and launch the next track USB2 B connector MIDI OUT jack 3,5 mm connector Copyright © 2021 GOOROO CONTROLLERS. Tous droits réservés...
-
Page 4: Ecran D'accueil
Playing track duration / selected next track duration Actual Ableton mode (Arrangement / Session) Actual LIOBOX mode (All track / Setlist). Connection statut Main / Spare. Error indicator. Track position in the set / setlist Copyright © 2021 GOOROO CONTROLLERS. Tous droits réservés... - Page 5 9 – COMPUTER STATE CONNECTION 9 – 1. Scripts 9 – 2. MAIN computer 9 – 3. SPARE computer 10 - TROUBLESHOOTING 11 – CONTRAT DE LICENSE 12 – DECLARATION DE CONFORMITE Copyright © 2021 GOOROO CONTROLLERS. Tous droits réservés...
- Page 6 The script is a small file allowing the exchange of data between Ableton and the LIO BOX. "Lio box Ablt10" for the Ableton 9-10 versions and the "Lio box Ablt11" script for the Ableton 11 version.
-
Page 7: Front Face
1 – 3. Cable choice recommandation As the LIO BOX is part of USB powered MIDI controllers, we recommend that you do not exceed the length of 1.5m for your USB2 cables. For the choice of cables, we recommend cables with the reference AWG24 X2 or / 2C, which corresponds to a power cable section of 0.5 mm... - Page 8 You can move around and play any track in your set. The LIO BOX analyzes the track names and inform you if two tracks (Scene / marker) have the same name and invites you to correct it.
-
Page 9: Display Modes
You have the possibility to change the display theme of the screen via the « THEME » The screen can be switched to DARK mode (on black background) for dark spaces and to DAY for sunny place. Copyright © 2021 GOOROO CONTROLLERS. Tous droits réservés... - Page 10 6 – THE TRACK NAMING PROTOCOL You can display on the screen of the LIO BOX, the information of BPM, tone and duration of the track. You just have to indicate them in the name of the track according to the following protocol: If you don’t want to indicate a value, you must leave the field empty and not put a ";...
- Page 11 8 – 3. Duration The duration of the title can be entered in the form "minute: seconds". You can also indicate the duration in seconds, the LIO BOX will convert the duration to the minute / second format. 9 – COMPUTER CONNECTION STATE 9 –...
-
Page 12: Troobleshooting
The name of a track in the setlist is displayed in red, check : • That the track was not deleted from the Ableton session. That you haven't changed the name, or the track info. • That you haven't moved a track. • Copyright © 2021 GOOROO CONTROLLERS. Tous droits réservés... -
Page 13: License Agreement
GOOROO CONTROLLERS has full ownership of the software embedded on the LIOBOX, as well as the scripts provided during purchase. The sale of the LIOBOX does not constitute a sale of the embedded software or the corresponding script.
