INSTALLATION GUIDE
UHP EXTREME ANTENNA
ATTENTION:
Read this manual carefully before installation or
maintenance procedures, which must be made by trained
professionals. In all operations, you should use PPE's that
have been duly approved for this purpose.
Point-to-point antennas' line, with excellent shielding.
NAME
GAIN
FREQUENCY
UHPX-5800-35-12-DP
35 dBi
4.9 – 6.425 GHz
ALGcom Quality and Safety
WE HAVE A STRONG QUALITY POLICY
ALGcom.com.br
Rev01 – (09-Ago-22)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHPX-5800-35-12-DP and is the answer not in the manual?

Questions and answers

Summary of Contents for ALGcom UHPX-5800-35-12-DP

  • Page 1 In all operations, you should use PPE's that have been duly approved for this purpose. Point-to-point antennas' line, with excellent shielding. NAME GAIN FREQUENCY UHPX-5800-35-12-DP 35 dBi 4.9 – 6.425 GHz ALGcom Quality and Safety WE HAVE A STRONG QUALITY POLICY ALGcom.com.br Rev01 – (09-Ago-22)
  • Page 2 ANTI-ROLL BAR PIPE CLAMP M5 SCREW 1/2” SCREW M6 SCREW KIT CENTRAL MOUNTING HARDWARE 3/8’’ SCREW KIT M5 ALLEN SCREW KIT RADOME SHIELD TOOLS DESCRIPTION Wrench #19 Wrench #15 Allen Screwdriver #5 Allen Screwdriver #4 Phillips Screwdriver ALGcom.com.br Rev01 – (09-Ago-22)
  • Page 3 Reflector (A) and Central Mounting Hardware (L) with the M6 screw kit (K), including the lock washers. 2) Assemble the Mounting Hardware (B) in the Reflector (A) using the (M). 3/8” Screw Kit Grease ALGcom.com.br Rev01 – (09-Ago-22)
  • Page 4 INSTALLATION GUIDE 3) Mount the Feeder (C) with his flange, than fix it to the antenna, using his M6 screws. 4) Assemble the Radio Plate (D) in the antenna, using his 3 M5 screws. ALGcom.com.br Rev01 – (09-Ago-22)
  • Page 5 INSTALLATION GUIDE 5) Mount the Shields (P) in the antenna, using M5 screws (N). 6) Place the Radome (O) inside the Shield (P), then fix it with M5 screw kit (N). ALGcom.com.br Rev01 – (09-Ago-22)
  • Page 6 INSTALLATION GUIDE 7) Mount the antenna in the pole using V-bolt 3/8’’ (E). 8) To perform Azimuth and Elevation adjustment, just loosen or tighten the follow nuts. ALGcom.com.br Rev01 – (09-Ago-22)
  • Page 7 V-Bolt 1/2’’ (F) and pipe clamp (H). 10) It is essential that the link is aligned with the main lobe and not with the secondary lobes, so carry out several tests until you get the best link performance. ALGcom.com.br Rev01 – (09-Ago-22)
