Polono PL60 Logistics Label Printer User Guide

Visit polono.com for more information

Warning

The print head can be very hot after printing. Do not touch the print head.
Do not allow the print head to be scratched or damaged in any way.
Do not use unprovided accessories.
Do not attempt any repairs on your own. Contact sales for assistance.
Keep away direct sunlight, water, dust, and other debris.
Unplug when idle for a long time.
Keep away from children.

Appearance and Components

Front view

Inside view

Note:
The above diagrams are to be used for reference only; parts and components may vary depending on your model.

Windows setup

Driver installation

1. Before installation, plug and power on the printer. Connect it to your computer or laptop.

2. Browse the U-disk for the windows driver file and click on it to install. You can also visit http://www.polono.com/contents/114/115.html to download the windows driver file.


3.


Set up

1. Go to "settings"-"device"-"Printers & scanners"-"PL60"-"manage"-"Printing preferences" to set up page size or other settings.

2.

3.

4.


Mac setup

Driver installation

Browse the U-disk for the windows driver file and click on it to install. You can also visit http://www.polono.com/contents/114/115.html to download the MAC driver file.

Page setup

Loading the Roll

Loading Folding Paper

1. Power on the printer and adjust the paper guides to fit the width of paper.

2. Insert the paper into the external paper roll inlet.

3. The paper will automatically feed into the printer.


Loading External Paper Roll

Note:

1. When the printer is powered on, the paper will automatically feed through the path.
2. The external paper roll holder needs to be aligned with the hooks at the bottom of the printer.
3. Whether label holder including depends on your order.

Clearing Paper Jams

1. Press the cover open levers and hold upwards.

2. Open the printer cover.

3. Take out the jammed paper, then clean up the print head and platen.

4. Reload new paper.


Note: Power off the printer when clearing a paper jam.

Power Connection

1. Connect the power cord to the power receptacle on the printer.
2. Connect the other end of power cord to the socket.


Note: Please refer to the PL60 User Manual for the tool and driver installation.

Cleaning and Maintenance

1. Power off the printer and unplug the power cord from both ends. Open the printer's top cover.
2. If the printer has just been used for printing, allow the print head to cool down for 2-3 minutes.
3. Clean the print head with alcohol using a dust-free cloth or while wearing rubber gloves.
4. Wait until the alcohol has completely dried.
5. Plug and power on the printer. Press and hold the feed button for 2-3 seconds to print a test page.

Specifications

Indicator status

FAQs

I installed the printer's driver. Why am I still unable to print?

The printer needs to be powered on and connected to the computer prior to installing the driver. Uninstall the driver and try reinstalling.

Why am I printing blank labels?

Check to make sure you are using thermal labels and that the labels are oriented correctly with the label facing upwards.

How do I calibrate the printer?

Press and hold the feed button until the indicator (blue) flashes 2 times. Release the feed button and the printer will begin calibrating.

How do I set or change?

Windows: Devices - Printers & Scanners - PLONO PL60 - Manage - Printing preferences. Additional settings can be found in the Advanced tab.
Mac: Launchpad - System Preferences - Printers & scanners - PL60 - Options & Supplies

Warranty

Polono offers an extensive warranty for all products that extends through 1YEAR delivery date. This warranty covers quality related issues and product defects.
If you are past the 30-day return period on Amazon, contact us directly via the "Contact seller" option on your Order Details. If the product is not working properly, we can send you a replacement product.
This warranty does not apply in case of abuse, mishandling, or unauthorized repair of the product.
If you have any question about this warranty or would like additional information, please contact us via the "Contact Seller" option or directly via e-mail at support@polono.com
Please keep the original box, packing materials and all documentation in the event that service is required.

Videos

Polono PL60 set up & print (video)

How to set up Polono PL60 on Windows (video)
