- Page 1 Mambo Flix DIGITAL MEDIA PLAYER USER’S MANUAL...
-
Page 2: Table Of Contents
Contents Precautions·························································································································································2 Characteristics····················································································································································4 Basic Operation··················································································································································5 System Menu ·····················································································································································6 Listen to Music ··················································································································································9 Music Settings····················································································································································9 Watch Videos ···················································································································································11 Voice REC ·······················································································································································12 Resources Manager ··········································································································································13 Picture Browse·················································································································································13 FM Tuner (not available in all models) ············································································································14 E-Book·····························································································································································15 Game Function·················································································································································16 SD Card ···························································································································································16 USB Disk·························································································································································17 Transfer and Play Video File ····························································································································18 Upgrade Player Driver ·····································································································································20 Troubleshooting ···············································································································································22... -
Page 3: Precautions
Precautions This manual contains important safety precautions and usage instructions. Please read all the information carefully before you use the device in order to avoid any unexpected accidents. Do not put the player in the condition of high temperature, humidity or dust. Do not put the player in high temperature place (over 40℃), especially not in the cars with window closed in summer. - Page 4 Do not use the player when driving or walking in order to avoid traffic accidents. Please charge in the following conditions: Battery electricity icon displays no electricity. Further power on the player when the system is powered off automatically, but it powers off soon. No response with the pressing keys.
-
Page 5: Characteristics
Characteristics 2.2-inch 260K full-color TFT display (320X240) Multi music formats as MP3, WMA and WAV, good timber and real audio frequency display MPEG-4 video format play, full-screen play display, exterior-sound speaker play High-definition JPEG picture browse function Built-in hi-fi 8 Ohm speaker Microphone record and line-in record Energy-saving setting, brightness adjustable, customized power off time Good timber, support 3D EQ surrounding effect, customized EQ... -
Page 6: Basic Operation
Basic Operation Power On/Off Power On: Push the power switch to ON position, long press interface and enter the working mode before the Normal Power Off. Power Off: a. In Play state: short press b. In other modes: press for 3 seconds to power off. c. - Page 7 Volume Control Press VOL switch to volume adjust, then press Leftwards or rightwards. Battery This player uses built-in lithium batteries of high capacity. Full The usable time of battery power varies according to different volume, type of playing file and pressing operation.
-
Page 8: System Menu
System Menu Main Interface After entering the Main Interface, select your desired option among [Music ]/[Video ]/ [FM ]/ [Photo]/[Text]/[Record]/[Navigation]/[Game]/[Setting] circularly by pushing leftwards or rightwards, and short press the "MENU" key to enter the option menu, long press [MENU] key to exit the submenu and return to Main Interface . - Page 9 Firmware Upgrading Close the dialog box in this menu. The player asks you whether to upgrade the firmware. It will exit if no firmware upgrading. Default Set In this menu, close the dialog box. To confirm whether to resume the defaulted value, select “Yes” or “No”.
-
Page 10: Listen To Music
Listen to Music Play/Stop/Pause In Music Play menu, connect the earphone with player, select the desired song file by pushing leftwards or rightwards key. Short press "MENU" key to begin the playing; then short press the music playing, the interface displays real audio frequency. The player only supports the Lyric Synchronous Display that the file shares the same name as LRC file of MP3 format, e.g., music file is named as “Angel.mp3”, the LRC file must be named as “Angel.Irc”. - Page 11 Repeat Mode Once Stop after playing all the songs in each directory Repeat 1 Repeat playing a single song. Folder once Play all the songs in the folder. Folder repeat Repeatedly play all the songs in the folder. All once Play randomly the songs in the current folder.
-
Page 12: Watch Videos
Watch Videos While under the video playing menu, press " " to stop the video playing. Long press "MENU" to exit. Long press "rightwards" to fast forward playing. Long press "leftwards" to backward playing. Press "MENU" to return to the file list; then press VOL to enter the browser. There are flash memory and miniSD card directories. -
Page 13: Voice Rec
Voice REC Voice REC In Main Interface, enter Record mode, and press PLAY key to start/pause recording, Long press [MENU] key to save the record and exit the REC mode. REC Setup In Stop state of REC mode, long press [MENU] key to exit the Main interface, and enter [Record] option. Adjust the settings among [REC Quality]/[REC Volume]. -
Page 14: Resources Manager
Resources Manager Resources Manager Resources manager allows you to browse the contents of your player more easily. Note: Delete File In Resources Manager, you can select music or video files, long press VOL key to display delete Dialog box, select “Yes” to delete and “No” to cancel. After the selection, short press "MENU" key to implement the selected option. -
Page 15: Fm Tuner (Not Available In All Models)
FM Tuner (feature not available in all models) Enter FM menu. Press Mode key to select: Manu, Auto, Mem, Pres, Del Manu(al): Press "MENU" Key to confirm, press leftwards or rightwards to change the frequent manually, long press" MENU"to exit. Auto: Press "MENU"... -
Page 16: E-Book
FM record : When you listen the FM music, Long press VOL key & press PLAY key to record and pause selecting, long press MENU key to store the Music as file and exit FM record mode. Note: In FM mode, the earphone is used as an antenna. Please keep the earphone is connected well. E-Book Download TXT File Connect the player to computer, select the desired file to download and save the file as TXT format in portable... -
Page 17: Game Function
Game Function Built-in Intellectual Game: In System Menu, press MENU key and enter Game mode. Select “QVGA_Game “ Folder, and short press key to enter Game selection Interface. Select & press key to enter Game. Press leftwards & rightwards together start/confirm game selections. Press key pause/quit game. -
Page 18: Usb Disk
USB Disk USB Display Mode The player has a high-speed USB2.0 port with the transmission speed of 5M/S, and is a standard USB disk, supports the systems including Windows98 (it needs to install the driver), and Windows2K and later (no driver necessary), Mac OS 10.3 and over, Linux Redhat 8.0 and over. -
Page 19: Transfer And Play Video File
This player can convert the WMV, RM, AVI, VOB or DAT into AVI video format via the video convert software included in the utilities directory on the player. Connect the player to your computer in USB disk mode and browse to the Mambo Flix > Utilities folder. Run the installer and follow these instructions: 1. Launch “AV Converter.exe”:... - Page 20 Convert and Play Video File 3. Select and set your desired parameters Select your desired video/audio file and AVI video file format to be generated. Click [Start to Convert] button, then begin to convert to AVI file. 4. The successfully converted AVI video file can be played in MP4 player. During the operation, enter Video Play menu, select the corresponding file, short press [MODE] key to play in video, long press to exit (the Video Play interface refers to the Screen Description).
-
Page 21: Upgrade Player Driver
Upgrade Player Driver The player can be upgraded or its driver repaired via the tool software in the attached disk. 1. Before upgrading via the computer, insert the drive disk into the CD-ROM of computer. Then, connect the MP4 player with computer (it requires you to press and hold the MENU key), till it appears the program Installation Interface. - Page 22 5. Connect the player to PC via USB cable (press and hold the MENU key before the On-line operation), then click [Burnt Firmware] until the Auto Upgrading is completed. Note: Firmware upgrade is to improve and optimize the performance of the player. The normal operation of the player would not be affected even if the firmware is not upgraded.
-
Page 23: Troubleshooting
Troubleshooting If the player can not be played normally, please check as follows: Troubles The player cannot be turned on The player has stopped working It can not be played It can not upload/download the file or the disk can not be found in computer The player cannot record Words on display are deformed The player can not be used normally... -
Page 24: Specifications
Items Dimensions Weight TFT colored display Language support Data transmission speed Supportable file format Supportable video format Max. output power Storage media Power supply Usable time of battery Working temperature Supporting operating system Accessories Specifications 80×47×12mm (W*H*D) About 46g 260K real colored display, Diagram (320*240) Multiple languages High speed USB2.0 (5M Byte/s) Music: MP3, WMA, WMV, ASF, WAV...
