Summary of Contents for Creative XP GlassCondor PRO

Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS Introduction ....................4 Product Overview ..................6-7 Power Supply ....................8 Changing the Modes ................9-11 Download ﬁles to the PC ...............12 Functions ....................13-16 Tips & Warnings ...................17-18 Warranty ....................19-20 Compelte Hunter Kit ...............22-30...
Page 4: Introduction
Introduction Thank you for purchasing the Creative XP® GlassCondor Night Vision Monocular PRO. This manual will help you optimize your viewing experience by explaining how to utilize the binoculars’ controls and features, and how to care for them. READ the instructions carefully before using your night vision monocular.
Page 5 AMERICAN OF ADVENTURE...
Page 6: Product Overview
Product Overview 1 - Objective focus knob 2 - Objective lens 3 - Infrared illuminator 4 - Battery compartment 5 - Operating zone 6 - USB 2.0 socket 7 - TF card socket 8 - Diopter ring 9 - Eyecup 10 - Ocular lens...
Page 7 Product Overview 13 14 15 11 - Menu Switch for IR illuminator light and adjustment of the screen brightness 12 - UP 13 - POWER/Function Check 14 – Switching Modes (photo shooting, video shooting, playback) 15 - DOWN...
Page 8: Power Supply
Power Supply Battery Installation The GlassCondor night vision monocular requires a 16340 Model lithium-ion battery (3.7V). Turn the battery cover counter-clockwise to unscrew the battery cover, insert the battery with negative electrodes on the bottom, and then tighten the battery cover clockwise. Please ensure the battery charges for at least 10 hours the ﬁrst time you use it to make it work better.
Page 9: Changing The Modes
Changing the Modes Scenery Observation In photo shooting mode, look at the screen from Eyecup #9. Adjust the diopter ring #8 to get the sharpest images. Adjust the objective focus knob #1 to change the focus based on the object's distance. The digital zoom turns on after pressing #12 and #15 –...
Page 10 Changing the Modes Changing the Modes The GlassCondor has 3 modes and you can switch between them by pressing the MODE (#14) button. Photo Mode For taking photos Video Mode For taking videos Playback Mode For viewing recorded ﬁles Announcements In any of the three modes, the menu will disappear if no action is taken within 3 seconds.
Page 11 Changing the Modes Video Mode In the photo shooting mode, press #14 shortly to get into the video shooting mode. Press "OK" (#13) to start the video recording (shown as "START"). The time showing on the left corner will turn into the timekeeping. Press "OK" (#13) to stop the video recording (shown as "STOP").
Page 12: Download Files To The Pc
Download Files to the PC How to download ﬁles to the PC? The monocular includes a USB 2.0 interface. Connect the monocular to the computer with the USB cable. The battery is charging when the monocular is connected to the computer. Press #13 for 3 seconds, choose from the function screen: Memory/PC camera/Video mode.
Page 13: Functions
Functions Brightness Adjustment In the photo shooting and video modes, press #11 for two seconds to enter the brightness adjustment menu (Picture 2) – the brightness level is the number after the word "SCREEN." The brightness levels range from 1 to 10, and you can change them by pressing #12 and #15.
Page 14 Functions Time Setting You must long-press #14 to start the main menu. By pressing #12 and #15, you can select the "Time Setting" option -> short press "OK" (#13) to enter -> switch between the year/month/day/hour/minute / second, with the "UP" and "DOWN"...
Page 15 Functions Basic Parameters Type Items Index Magniﬁcation Dimension of Objectives φ35mm Optical 7° x 5.25° Performance Ocular Adjustable Range ±0.5 Observing Distance (Low Light Environment) 2m~∞ Observing Distance (100% Dark Environment) 2m~500m Sensor Low Illumination HD 1 / 3 COMS Pixel 130W Digtial...
Page 16 Functions Conﬁguration Standard Basic Parameters Power Operating Voltage 3.7V DC Replaceable Battery Rechargeable lithium-ion battery - 16340 Model Charging Source 5.0V/1000mA Adapter Measurement(L*W*H) 178x72x78mm Other Weight 300g...
Page 17: Tips & Warnings
Tips & Warnings 1. Basic maintainance Keep the monocular in its soft case when not in use. The operating temperature ranges from -5°C ~ 40°C. To avoid wetness and rust, please store it in a dry environment. Avoid mechanical damage, humidity, and strong shocks. Avoid raindrops or heavy fog as far as possible.
Page 18 Tips & Warnings 5. Using the Infrared Illuminator Turn the infrared illuminator (auxiliary light) ON by pressing the IR button when using the monocular in complete darkness. You can adjust the brightness of the infrared illuminator depending on the objects' distance. A low-level illuminance transducer is featured as well.
Page 19: Warranty
Warranty Your CREATIVE XP product is warranted to be free of defects in materials and workmanship for one (1) year after the date of purchase. These warranties do not cover consumer caused damages such as misuse, abuse or repairs attempted by the consumer.
Page 20 CREATIVE XP product must be delivered in either its original carton or a similar package a ording an equal degree of protection. CREATIVE XP will not be responsible for any loss or damage incurred in connection with the return of this product. If defective, the product will be repaired or replaced at CREATIVE XP’s option, at no...
Page 22: Compelte Hunter Kit
THE COMPLETE HUNTER KIT...
