matev GmbH
Nürnberger Str. 50
90579 Langenzenn, Germany
T +49 9101 9087 -0
F +49 9101 9087 -20
info@matev.eu
www.matev.eu
Original Operating Manual
Carefully read this manual all the way through before using the machine.
Snow Blower
SBL - M 12-40 QH – JD Quick Hitch
SBL - M 12 – 40C
SBL - M 14 – 40C
Version 12/2017
Advertisement
Chapters
Table of Contents
Related Manuals for matev SBL-M 12-40C
Summary of Contents for matev SBL-M 12-40C
- Page 1 GmbH Nürnberger Str. 50 90579 Langenzenn, Germany T +49 9101 9087 -0 F +49 9101 9087 -20 info@matev.eu www.matev.eu Original Operating Manual Snow Blower SBL - M 12-40 QH – JD Quick Hitch SBL - M 12 – 40C SBL - M 14 –...
-
Page 2: Table Of Contents
Table of contents About this operating manual ..................3 Safety ......................... 4 Intended use ....................... 4 Qualifications of personnel ..................4 General safetynotices ....................5 Special safety notices ....................6 Basic rules ........................7 Task and use ......................7 Delivery and transport ....................7 Installation ......................... -
Page 3: About This Operating Manual
About this operating manual About this operating manual Dear customer! Thank you for purchasing this snow blower, we appreciate your trust. Prior to using this implement for the first time, read this operating manual carefully and conscientiously all the way through. Keep this operating manual where it is easily accessible. -
Page 4: Safety
Safety Safety Note Must be read!!! Guidelines and instructions with which you must comply, are summarized in this section. Personnel who install, operate and maintain the snow blower, must have read and understood this operating manual. Intended use The implement is used exclusively in winter service for clearing snow on roads, lanes, walking paths, plazas, and industrial areas. -
Page 5: General Safetynotices
Safety General safetynotices In this section general safety notices are explained that are used in the subsequent sections. Comply with these safety notices to ensure safe operation and to save work time and costs. In addition to the instructions in this operating manual, also comply with the generally valid safety and accident prevention regulations! Young persons under the age of 16 are not allowed to operate the implement! ... -
Page 6: Special Safety Notices
Safety Special safety notices The safety instructions specified in this section are also affixed as stickers on the implements. Attention! Ensure that the engine PTO shaft is at a standstill. Only use cloths, water soap for cleaning. Do not use any solvents, diesel fuel or gasoline. -
Page 7: Basic Rules
Delivery and transport Basic rules Each time before starting up, check the machine for operational reliability!!! Cleaning tasks, e.g. with a high-pressure cleaner, should be executed in such a manner that the water jet is not held directly on bearing parts and turned parts (shaft seals, lubricating nipples, etc.) Otherwise, check the moving parts for ease of movement, regrease if necessary! ... -
Page 8: Installation
Installation Installation Danger! Switch off the tractor and remove the ignition key before mounting or dismounting the implements. Note! Enter the vehicle chassis number of the snow blower in section 7.4 of this operating manual. The rear axle of the vehicle is offloaded depending on the weight of the equipment. To avoid loss of adhesion, the weight on the off-loaded axle must be at least 25% of the empty weight of the vehicle. -
Page 9: Mount Snow Blower Sbl - M 12-40 C And Sbl - M 12-40 C On Tractor
Installation 5.1.2 Mount snow blower SBL - M 12-40 C and SBL - M 12-40 C on tractor Depending on tractor size and type and size of the coupling support, the attachment triangle on the snow blower is fastened with screws. The height of attachment must be selected depending on the tractor size. -
Page 10: Installation Of The Universal Joint Shaft
Installation Installation of the universal joint shaft The transmission of force between tractor and snow blower occurs mechanically via a universal joint shaft. Depending on tractor type the supplied universal joint shaft may be too long. Execute the steps described below to shorten the universal joint shaft. Only use the universal joint shaft provided by the manufacturer. -
Page 11: Mounting The Universal Joint Shaft
Installation Fig. 8: Saw off the profile tube Fig.9: Deburr the sawn edges Repeat steps described steps on the other half of the universal joint shaft. Deburr the sawn edges. Grease the profile tube. Fig. 10: Grease the profile tube. 10. -
Page 12: Operation
Operation Operation Working with the snow blower Attention! The vehicle behavior, steering and brake capacity are influenced through the attached equipment Attention! The snow blower can be damaged. Before each use, check to ensure proper adjustment of the support skids. ... -
Page 13: Adjusting The Work Height Of The Machine
Maintenance Adjusting the work height of the machine Note! Adjust the support skids of the machine in such a manner that in working position the snow blower glides just barely above the ground. Watch out for uneven terrain, projecting edges and objects, such as manhole covers and shaft covers, to prevent machine damage. -
Page 14: Maintenance
Maintenance Attention! Properly reattach all protective devices that have been dismounted after executing the maintenance tasks. Note! After the first 20 hours of operation check all screw and bolt connections. Subject the implement to regular maintenance. Use multi-purpose grease to lubricate the moving parts. Maintenance At regular intervals, and always at the beginning and end of the season, the moving parts of the implement must be greased or oiled. -
Page 15: Safety Screw
Maintenance 7.2.2 Safety screw Both augurs have a safety screw (D). To prevent transport of heavy material, through which the equipment can be damaged, the safety screw breaks at a specific load. We recommend always keeping several replacement screws of the following dimensions with you when operating the implement. -
Page 16: Gearbox
Maintenance 7.2.4 Gearbox Fig. 15: Gearbox Every 400 work hours the oil must be changed at operating temperature. To do this, remove the two plugs located below and on the filler neck B top up with oil type VANGUARD HCZ 80W90 –API GL3 up to position (C). (Changing the oil for the first time is recommended after 80-100 hours). -
Page 17: Lubricating The Universal Joint Shaft
Maintenance 7.2.5 Lubricating the universal joint shaft The universal joint shaft must be greased. Fig. 17: Universal joint shaft Faults Fault: Possible cause / rectification: Snow is no longer thrown out smoothly Snow adhering on the blades or the rotor: Switch off the machine and use the provided wooden rod to remove the snow Check all moving parts for ease of movement –... -
Page 18: Repair
Take the parts to the collection points for residual waste, special waste, or recycle them depending on material. matev GmbH does not provide any disposal services. Guarantee The General Terms & Conditions of matev GmbH provide information on the guarantee conditions. matev GmbH Nürnberger Str. 50... -
Page 19: Technical Data, Implements And Optional Equipment
Technical data, implements and optional equipment Technical data, implements and optional equipment SBL - M 12 – 40C (QH) SBL - M 14 – 40C Working width 1200 mm 1400 mm Weight, approximate 156 kg (165 kg) 240 kg Min./max. power 20/40 HP 28/55 HP Working width... -
Page 20: List Of Illustrations
List of illustrations List of illustrations Fig. 1: Attachment point ..........................7 Fig. 2: Attach SBL - M 12-40 QU Fig. 3: Attach SBL - M 12-40 QU ............8 Fig. 4: Attachment of the snow blower ......................9 Fig. 5: Adjusting the snow blower ........................9 Fig. -
Page 21: Ec Declaration Of Conformity
EC Declaration of Conformity for a machine to confirm compliance with the Machinery Directive 2006/42/EC and with the statutory regulations issued for the implementation of the Machinery Directive. The manufacturer matev GmbH Nürnberger Str.50 90579 Langenzenn SBL - M 12 – 40 QH – JD Quick Hitch that the machine SBL - M 12 –...
