proper Ethernet setup between the device and the PC having ModScan/ qModMaster Software.
2) Blinking Ethernet LEDs will indicate the communication between PC and the EDGE Modbus
Gateway
3) The Modbus Source address can be configured by the user from J1939 dashboard but the
purpose of Gateway is to only broadcast the 13 J1939 decoded parameters to following registers.
4) Following is the Register Mapping on Modbus TCP Holding Registers (0 to 12) for
corresponding 13 J1939 Parameters.
Sr.
J1939 Parameter
No.
1 Percent Load
2 Oil Pressure
3 Fuel Pressure
4 Battery Voltage
5 Boost Pressure
6 Inlet manifold Temperature
7 Coolant Temperature
8 Fuel Temperature
9 Fuel rate
10 Engine Speed
11 Auxiliary Temperature
12 Auxiliary Pressure
13 Engine Hours
f) If the Data is being received by the CAN bus when CAT Engine ECM is powered up, following
data or similar data can be seen:
Embedos Engineering LLP
Manual – J1939 Datalogger & Modbus TCP Gateway
PGN SPN
61443 92
65263 100
65263 94
65271 168
65270 102
65270 105
65262 110
65262 174
65266 183
61444 190
65164 441
65164 1387
65253 247
Modbus TCP Holding Register
0
1
2
3
4
5
6
7
8
9
10
11
12
