oti 6500 TRIO

Specification

Version 1.5

Notice

This manual contains intellectual property including

but not limited to, trade secrets and know-how,

operation procedures and production procedures that

belong solely to oti.

Disclosure, use, and/or production of any part of the

above are strictly forbidden, except under a written

license from oti.

Confidential & Proprietary

Version 1.5

Table of Contents

Need help?

Do you have a question about the 6500 TRIO and is the answer not in the manual?

Questions and answers

Summary of Contents for oti 6500 TRIO

Page 1 6500 TRIO Specification Version 1.5 Notice This manual contains intellectual property including but not limited to, trade secrets and know-how, operation procedures and production procedures that belong solely to oti. Disclosure, use, and/or production of any part of the above are strictly forbidden, except under a written license from oti.
Page 2 Oti 6500 TRIO Specification Version 1.5 FCC Compliance FCC Compliance The 6500 reader complies with Part 15, of the FCC rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, 2. This device must accept any interference received, including interference that may cause undesired operation.
Page 3: Table Of Contents
Oti 6500 TRIO Specification Version 1.5 Table of Contents Table of Contents FCC COMPLIANCE ............................. B TABLE OF CONTENTS ..........................1 TABLE OF FIGURES ............................ 2 INTRODUCTION ..........................3 ..................4 ERTIFIED AND UPPORTED APPLICATIONS ........................5 UPPORTED TANDARDS BASIC OPERATION ..........................6 ..........................
Page 4: Table Of Figures
Table of Figures Figure ‎ 2 -1: 6500 TRIO – Front View ....................8 Figure ‎ 2 -2: 6500 TRIO Full and Partial Configuration ..............9 Figure ‎ 4 -1: 6500 TRIO with Pigtail Connector Cable ..............13 Figure ‎ 4 -2: Pigtail Connector Cable Wiring ..................14 Figure ‎...
Page 5: Introduction
Introduction 1 Introduction The 6500 TRIO reader is a modular payment device that can support up to three cashless payment interfaces in one small stylish enclosure. The reader is designed specifically for installation in vending machines to allow cashless payment with magnetic payment cards, as well as proximity, vicinity, and Contact EMV payment cards.
Page 6: Certified And Supported Applications
Oti 6500 TRIO Specification Version 1.5 Introduction 1.1 Certified and Supported applications The 6500 TRIO is certified and supports the following applications:  o Contact EMV L1 o Contact EMV L2 o Contactless EMV L1  VISA o VISA PayWave MSD...
Page 7: Supported Standards
Oti 6500 TRIO Specification Version 1.5 Introduction 1.2 Supported Standards The 6500 TRIO is compatible with the following standards:     RoHS compliance  ISO 9001: 2008  ISO/IEC 14443 Proximity Type A&B  ISO/IEC 15693 Vicinity ...
Page 8: Basic Operation
As stated in Chapter Figure ‎ 2 -1: 6500 TRIO – Front View ....................8 Figure ‎ 2 -2: 6500 TRIO Full and Partial Configuration ..............9 Figure ‎ 4 -1: 6500 TRIO with Pigtail Connector Cable ..............13 Figure ‎ 4 -2: Pigtail Connector Cable Wiring ..................14 Figure ‎...
Page 9: Magnetic Stripe
Oti 6500 TRIO Specification Version 1.5 Basic Operation Introduction, the 6500 TRIO reader contains three card interfaces:  Magnetic card swipe reader  Contactless reader  Contact reader 2.1 Magnetic Stripe When a valid magnetic payment card is swiped, the reader reads Track 1 and Track 2 data stored on the card’s magnetic stripe.
Page 10: Figure ‎ 2 -1: 6500 Trio - Front View
Card interface logos Contact Contactless Magnetic Contact card slot Contactless payment applications logos Buttons (Optional) Button Button Button * Overlay artwork can be customized to customer requirements Figure ‎ 2 -1: 6500 TRIO – Front View Confidential & Proprietary page 8...
Page 11: Figure ‎ 2 -2: 6500 Trio Full And Partial Configuration
Oti 6500 TRIO Specification Version 1.5 Basic Operation Figure ‎ 2 -2: 6500 TRIO Full and Partial Configuration Confidential & Proprietary page 9...
Page 12: Technical Specifications
 Flexible, software configurable,  2 x 16 character display certified intelligent reader solution  4 LED indicators  oti advanced Host – Reader TLV based  Multi-tone buzzer protocol  Up to 3 buttons (Optional)  Contactless transparent communication ...
Page 13: Product Technical Specifications
Oti 6500 TRIO Specification Version 1.5 Technical Specifications 3.2 Product Technical Specifications Table ‎ 3 -1: Performance/Electrical Specifications Feature Specification  RF Interface: RF Carrier Frequency 13.56 MHz RF Output 450mW ISO/IEC 14443 A&B and Mifare Full compliance ISO/IEC 15693 Optional ...
Page 14 It is highly recommended to check this issue with proper tools (e.g. oscilloscope) during the reader installation. For more details contact oti technical team via oti’s sales representatives. Confidential & Proprietary...
Page 15: Interface
Figure ‎ 4 -1: 6500 TRIO with Pigtail Connector Cable The 6500 TRIO has a 23.6” (60cm) pigtail connector cable terminated with a Molex MicroFit 43025_0600 6-pin female connector. The cable supplies DC power and RS232 serial communication to the reader.
Page 16: Pigtail Connector Cable Wiring
Oti 6500 TRIO Specification Version 1.5 Interface 4.2 Pigtail Connector Cable Wiring Saturn 6500 Pigtail Saturn 6500 MB MicroFit 43025-0600 Connector 28AWG Black Green TR* (TXD) White TR (RXD) SCREEN 23.6" (60cm) Figure ‎ 4 -2: Pigtail Connector Cable Wiring Molex MicroFit connector pin designation: ...
Page 17: Dimensions
Oti 6500 TRIO Specification Version 1.5 Dimensions 5 Dimensions 5.1 6500 TRIO Without contact reader 3.23" 1.46" (82mm) (37mm) 4.1665" Front Side (105.83mm) 3.54" (90mm) With contact reader Figure ‎ 5 -1: 6500 TRIO Dimensions Confidential & Proprietary page 15...
Page 18: Spacer
Oti 6500 TRIO Specification Version 1.5 Dimensions 5.2 Spacer The Spacer is used to elevate the 6500 TRIO from the mounting surface. Spacers can be stacked. Caution: Use the mounting screws provided with the spacer kit. Use of longer screws may damage the reader.
Page 19: Mounting Plate
Version 1.5 Dimensions 5.3 Mounting Plate The mounting plate is used for installation of the 6500 TRIO in bill acceptor cutout. The dimensions are shown in the figure below. Figure ‎ 5 -4: Mounting Plate Dimensions Figure ‎ 5 -5: Mounting Plate Picture Confidential &...
Page 20: Drilling Template
Oti 6500 TRIO Specification Version 1.5 Dimensions 5.4 Drilling Template The drilling template (illustrated in the figure below) is used to mark the position of the mounting holes and cable entry hole that need to be drilled into installations where there is no bill acceptor cutout.
Page 21: Installation
Version 1.5 Installation 6 Installation 6.1 Assembly in Bill Acceptor Cutout The 6500 TRIO is designed to fit into the bill acceptor cutout. If the vending machine has a bill acceptor cutout, please perform the following steps: Figure ‎ 5 1.
Page 22: Surface Mounting On Vending Machine ( Without Bill Acceptor Cutout )
Oti 6500 TRIO Specification Version 1.5 Installation 6.2 Surface Mounting on Vending Machine (without Bill Acceptor Cutout) If the vending machine doesn’t have a bill acceptor cutout: Figure ‎ 5 1. Take drilling template (see -6) supplied with kit and place it over the mounting location.
Page 23: Cradle
7.1 6500 TRIO for Attended Use The 6500 TRIO can be delivered ready for attended use configuration. While installed within its cradle, the 6500 TRIO can be used as a triple channel (3-in-1) countertop reader. The 6500 TRIO supports card associations operation profiles for both attended and unattended use.
Page 24: Cradle Structure
Version 1.5 Cradle 7.2 Cradle Structure The 6500 TRIO cradle is designed to be light and easy to install. The cradle consists of two physical parts as illustrated in the figure below. Figure ‎ 7 -2: Cradle parts Confidential & Proprietary...
Page 25: Figure ‎ 7 -3: Cradle Dimensions
Oti 6500 TRIO Specification Version 1.5 Cradle The cradle dimensions (164.10 mm x 112.11 mm) are relatively compact in order to minimize the counter space required for the reader. Figure ‎ 7 -3: Cradle Dimensions Confidential & Proprietary page 23...
Page 26: Contact Us
Oti 6500 TRIO Specification Version 1.5 Contact Us 8 Contact Us For oti America Technical Support (US and Canada):  Phone: +201-944-5200 (Ext. 140) 08:30 AM - 06:00 PM Eastern time Monday through Friday  Email: Support@otiamerica.com For oti Technical Support (International): ...
