Summary of Contents for Post PR21.56
- Page 1 OPERATOR MANUAL DRUM CONDITIONER WITH MOBILE CART POST MATERIAL HANDLING SERIAL NUMBER PR21.56 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com...
-
Page 2: Table Of Contents
TENSION THE LIFT CHAIN....................14 APPROVAL DRAWING ......................15 ELECTRICAL SCHEMATIC – PAGE 1 OF 2 ................. 16 ELECTRICAL SCHEMATIC – PAGE 2 OF 2 ................. 17 WARRANTY ..........................20 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 3: Introduction
INTRODUCTION This manual provides operating, maintenance and service information regarding the Post Material Handling Portable Drum Conditioner. Keep this manual available to management, operator and maintenance personnel who are responsible for the equipment’s operation and maintenance. It is essential to read, understand and follow the recommendations of this manual before operating or servicing this equipment. -
Page 4: Drum Conditioner Operation (Using Control Panel)
When the drum is lifted above the MAX DROP DISTANCE in inches the arms are locked. “The drum is locked – lower the lift X.X inches to release the drum” is displayed on the MAIN SCREEN. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 5: Manual Operation (Using Control Panel)
FWD and REV positions of the INVERT selector switch. 5. The green RESET button on the pendant is equivalent to the blue RESET button on the control panel. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 6: Accessing Machine Settings (Hmi)
4. Press the CRUSH DISTANCE button. Enter the desired crush distance of the drum (below the measured diameter) in inches. 5. Press the CRUSH HOLD TIME button. Enter the crush hold time in seconds. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 7: Adjusting Pressure Settings (Hmi)
Then press ENABLE MANUAL PRESSURE SETTING to apply this pressure in PSI to the drum conditioning arms. This setting will automatically be turned off after 20 minutes. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 8: Maintenance Screen (Hmi)
9. Press the PANEL VIEW SCREEN CONFIGURATION button to access the HMIs configuration menu and perform functions such as screen calibration. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 9: Maintenance Reminder Screen (Hmi)
CLEARNANCE DISTANCES DURING CYCLE section. The arms open by the amounts shown after different steps in the cycle. MEASURING WIDTH is the amount the arms open before measuring drum diameter. This should be POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 10: Emergency Stop
GENERAL CLEARANCE applies after the measurement step. POST CRUSH CLEARANCE applies when the arms are crushing the drum for the specified number of crushes. Enter a negative number to keep the arms very tight on the drum. -
Page 11: Removing The Slot Cover
2. Loosen the slot cover tensioner bolts on each side of the compressor. 3. Remove the 4 screws on each end cap. 4. Feed the slot cover through the compressor carriage. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 12: Checking Chain Tension
Remove the slot cover as described earlier. Check the chain tension on the underside of the carriage. The chain tension sensor has a light that should be illuminated when the chain is properly tensioned. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 13: Tension The Lift Chain
Check the lower portion of the chain, below the lift carriage, for tension. If the chain is loose, tighten the chain tensioning double nuts. Do not over tighten. If the chain cannot be tensioned any more, replace the chain. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 14: Tension The Lift Chain
Check the lower portion of the chain, below the lift carriage, for tension. If the chain is loose, tighten the chain tensioning double nuts. Do not over tighten. If the chain cannot be tensioned any more, replace the chain. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 15: Approval Drawing
APPROVAL DRAWING POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 16: Electrical Schematic - Page 1 Of 5
ELECTRICAL SCHEMATIC – PAGE 1 OF 5 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... -
Page 17: Electrical Schematic
ELECTRICAL SCHEMATIC – PAGE 2 OF 5 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com... - Page 18 ELECTRICAL SCHEMATIC – PAGE 3 OF 5 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com...
- Page 19 ELECTRICAL SCHEMATIC – PAGE 4 OF 5 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com...
- Page 20 ELECTRICAL SCHEMATIC – PAGE 5 OF 5 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com...
-
Page 21: Warranty
Expendable items or normally wearing parts such as bearings, seals, gaskets, diaphragms, slot cover, silencers, hoses, etc. are specifically excluded from this warranty. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 (845) 200-3355 www.posthoist.com...
