unimom FORTE Instructions For Use page 2

Cleaning and sterilization
1. Remove valve head and membrane from the breast shield.
2. Clean and sterilize it in boiling water for 2~3 minutes.
3. Pull out the air tube carefully and clean it with washing agent.
4. Clean it at least once a week, but when breast milk gets inside, clean immediately.
NOTE : TO ELIMINATE CONDENSATION OR MILK IN THE AIR TUBE, WASH AND DRY IT
IMMEDIATELY. TO CLEAN MAIN BODY, WIPE MAIN BODY WITH A CLEAN
DAMP CLOTH.
WARNING : NEVER IMMERSE MAIN BODY IN WATER.
DO NOT SANITIZE THE KIT IN MICROVAVE OVEN.
Components
Accessory name
Breast shield 2EA
Bottle 2EA
Bottle cover 2EA
Single connector 1EA
Main body 1EA
Bottle stand 2EA
Air tube 2EA
Kit : A + B + C + G + H + I + J + K + L
How to store breast milk
It's best if you can directly feed your baby, If you can't, the storage would be better.
Up to 3 hours
Room temperature
Up to 1 day
Refrigerator
Up to 3 months
Freezer
NOTE : COOL BREAST MILK IN THE REFRIGERATOR FOR TWO HOURS BEFORE
FREEZING.
WARNING : LABEL REFRIGERATED BREAST MILK WITH THE DATE AND TIME
THE MILK WAS EXPRESSED. DO NOT MIX FRESH MILK WITH REFRIGERATED
MILK.
How to thaw
1. Place frozen milk in the refrigerator for several hours before use.
2. Before feeding, hold milk under warm running water until the milk is room
temperature.
3. Shake it well when the milk fat may separate.
WARNING : DO NOT THAW FROZEN MILK IN MICROWAVE OVEN.
DO NOT REFREEZE MILK ONCE IT HAS BEEN DEFROSTED.
How to transport and store
Clean all parts thoroughly and wipe main body with a clean damp cloth after each use.
NOTE : WHEN UNIT IS NOT TO BE USED FOR AN EXTENDED PERIOD, STORE CAREFULLY
IN A COOL, DRY PLACE.
Symbols
: Date of : Alternating
manufacture current
Accessory name
Cap 2EA
Disk 2EA
Nipple 2EA
Valve head 2EA
Membrane 2EA
Double connector 1EA
3
DO NOT
STORE MILK
IN HOT WEATHER.
: ON
SN
: Serial number
: OFF
5
How to assemble
1. Single pumping
1. Fit the membrane L into the 2. Push the valve head
valve head K. assembly into the bottom
of the breast shield A.
4. Hold the bottle assembly 5. Connect one end of the air
into the bottle stand F. tube G to the breast
shield assembly.
2. Double pumping
Follow the above until 5
6. Connect the
double
connector M to
the single
connector D.
Disposal
Use your local collection and return systems for old electronic equipment. If old
electronic equipment is not disposed of correctly, this can have harmful effects on the
environment and on public health.
Trouble shooting
Possible
Condition
Checks
Causes
Check if the fuse has
Fuse
become disconnected
Check if the switch is
Switch
turned on.
No
suction
Power cord Check if the power cord
is plugged
Check if the air tube is
Air tube
connected to the main body
Check if they are
Valve head
assembled to the breast
Membrane shield properly
Defective
Check the connection of
assembly
the kit.
Breast Check if there is a problem
Low
shield with the breast shield.
suction
Check if there is space
Membrane between valve head and
membrane.
Too high
Pain Check the suction level
suction
NOTE : WHEN THE MAIN BODY PRODUCES AN ABNOMAL NOISE OR WHEN THE
BREASTMILK IS OVERFLOWN INTO THE MAIN BODY, CONTACT THE
LOCATION WHERE YOU PURCHASED THE PRODUCT OR THE
MANUFACTURER. WHEN THE BREASTMILK IS OVERFLOWN ONLY TO THE
AIR TUBE, REMOVE IT FROM THE MAIN BODY AND CLEAN IT.
3. Screw the bottle B into the
breast shield assembly.
6. Connect the other end of
the air tube G to the single
connector D
7. Connect the
other end of the
air tube G to the
double
connector M.
4
Solutions
Replace the correct fuse
followed by specification.
If the pump does not function
when the switch is turned on,
please contact the location
where you purchased the
product or the manufacturer.
Plug into the outlet
See how to assemble and
connect the air tube properly
Disassemble and reassemble
them properly.
Disassemble and reassemble
them.
Purchase and replace the
breast shield.
Remove any foreign
substances
Start with low vacuum
Consult your lactation
consultant or physician.
6
