6571846COM
AQUARIUM STAND 55 GALLON
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B346571846COM01GO
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
Tough
You
Tube
Advertisement
Related Manuals for Ollie & Hutch 6571846COM
Summary of Contents for Ollie & Hutch 6571846COM
- Page 1 6571846COM AQUARIUM STAND 55 GALLON B346571846COM01GO Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 1.0 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not actual size BOTTOM LEFT PANEL T6571846010GO T6571846020GO T6571846030GO QTY: 1 PC QTY: 1 PC QTY: 1 PC APRON RIGHT PANEL SHELF PARTITION T6571846070GO T6571846040GO T6571846060GO T6571846050GO QTY: 2 PCS QTY: 1 PC QTY: 2 PCS QTY: 1 PC DOOR BACK PANEL LEG CENTER... - Page 5 Board Identification Not actual size ameriwoodhome.com Tube...
-
Page 6: Part List
Hardware Bag Reference number: COM0GO 6571846 Part List Actual Size Ø4.2 x 45mm Ø15 x 12mm Ø6 x 25mm Ø8 x 30mm ×22 ×30 ×22 ×12 CAM LOCK CAM BOLT WOOD DOWEL SCREW TGO2101 TGO2001 TGO2900 TGO1008 Ø3.5 x 14mm Ø3 x 15mm Ø3.5 x 12mm M4x19... - Page 7 STEP ×14 ×22 1.1 Cam bolt (2) into (A), (B) as illustrated. 1.2 Insert (3) into (B), (H), (G) and (J) as illustrated. ameriwoodhome.com Tube...
- Page 8 STEP ×8 ×8 2.1 Insert (3) into (C), (D) and (E) as illustrated. 2.2 Cam bolt (2) into (C), (D) as illustrated. ameriwoodhome.com Tube...
- Page 9 STEP Quick Assembly LOCK ×4 Proper orientation of CAM LOCK 3.1 Attach (J) x 2 into (B) with (1) as illustrated. FINISHED EDGE FINISHED EDGE ameriwoodhome.com Tube...
- Page 10 STEP ×2 4.1 Attach (E) into (B) with (4) as illustrated. ameriwoodhome.com Tube...
- Page 11 STEP Quick Assembly LOCK ×8 Proper orientation of CAM LOCK 5.1 Attach (C), (D) into (B), (J) with (1) as illustrated. ameriwoodhome.com Tube...
- Page 12 STEP ×10 ×4 ×2 6.1 Attach (H), (G) into (A) with (4) as illustrated. 6.2 Attach (10) into (H) with (7) as illustrated. FINISHED EDGE FINISHED EDGE ameriwoodhome.com Tube...
- Page 13 STEP Quick Assembly LOCK Proper orientation of CAM LOCK ×10 ×6 7.1 Attach (A) into (J) x 2, (C), (D) and (E) with (1) as illustrated. 7.2 Attach (K) into (B) as illustrated. ameriwoodhome.com Tube...
- Page 14 STEP ×8 ×16 ×8 ×4 ×8 8.1 Insert (F) with (11) as illustrated. 8.2 Attach (12) into (I) x 4 with (5) as illustrated. 8.3 Attach (12) into (I) x 4 with (8) as illustrated. ameriwoodhome.com Tube...
- Page 15 STEP ×32 ×4 ×8 9.1 Attach (I) x 4 into (C), (D) with (5) as illustrated. 9.2 Attach (13) into (I) x 4 with (6) as illustrated. 9.3 Adjust the foot (K) before use. leveler ameriwoodhome.com Tube...
- Page 16 STEP To adjust the vertical height. Loosen the four screws "A" on bolt hinges. Two of them are usually in slotted holes which allows you to adjust up of down by a few mm. then tighten back up. Para ajustar la altura vertical Afloje los cuatro tornillos "A"...
- Page 17 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 18 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
- Page 19 de l'aide. ameriwoodhome.com Tube...
- Page 20 (B) Bas (9) VIS (10) VIS (11) VIS (12) (13) (14) (15) (16) Page 7 Page 8 Page 14 ameriwoodhome.com Tube...
- Page 21 5 Étoiles Merci ameriwoodhome.com Tube...
- Page 22 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 23 Español Página 4: Identificación de la Junta No es la talla actual (A) Parte superior (B) Fondo (C) Panel izquierdo (D) Panel derecho (E) Dividir (F) Estante (G) Patán (H) Bloque de madera (I) Panel posterior (10) (J) Delantal (11) (K) Centro de la pierna (12) (13)
