CARE & MAINTENANCE and WARRANTY - MAGNATRACK SYSTEMS
CARE & MAINTENANCE and WARRANTY
Fraser Shading Systems MagnaTrack Screen system is designed to protect and enhance your
outdoor dining area or living area, and create a usable space year‐round. The screen system can
be used for privacy, bug protection, solar, blowing winds (up to 120 KPH (75 MPH) in the full
deployed position), and to control the climate and wind flow.
OPERATION OF THE SCREENS
To LOWER the screen press the DOWN button on the remote and the screen will deploy to the
preset bottom limit:
*** Make sure no obstructions are under the screen during this process,
If the screen is lowered down on an object, stop the screen immediately
If the motor does not stop when object is under the screen during deployment, press the center
STOP button on the remote immediately and Remove object, then continue to lower the screen:
‐ To raise the screen press the UP button on the remote and the screen will retract to the
preset limit.
‐ You can stop the screen at any position during the raising or lowering of the screen by
pressing the STOP button.
*** If the screen does not fully deploy to the floor, or the weight bar is hanging uneven
please leave the screen in that position and contact your authorized dealer ASAP.
RESETTING/ADJUSTING LIMITS ON SIMU/SOMFY MOTOR
‐ To adjust the limits, you must let the screen raise or lower until the motor stops! (even
if it is not to the desired position)
‐ When the screen is retracted or lowered to the Preset limit you wish to adjust PRESS
AND HOLD, BOTH THE UP AND DOWN AT THE SAME TIME (FOR 7 to 10 SECONDS) UNTIL
THE MOTOR/WEIGHT BAR JOGS UP/DOWN.
‐ After the motor jogs you can raise or lower to the desired position.
‐ THEN, PRESS AND HOLD THE STOP BUTTON UNTILL THE MOTOR JOGS to encode the
new limit setting.
This will complete the programming process and change the limits.
MagnaTrack Systems
or the Obstacle detection feature in the motor will activate
and should raise back up to allow removal of object.
***Raising the screen could cause additional damage.
(NOTED ON REMOTE)
LICENSED FABRICATOR OF MAGNATRACK
200619
VERSION:
1
PAGE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Fraser MagnaTrack
- Page 1 CARE & MAINTENANCE and WARRANTY - MAGNATRACK SYSTEMS CARE & MAINTENANCE and WARRANTY MagnaTrack Systems Fraser Shading Systems MagnaTrack Screen system is designed to protect and enhance your outdoor dining area or living area, and create a usable space year‐round. The screen system can be used for privacy, bug protection, solar, blowing winds (up to 120 KPH (75 MPH) in the full deployed position), and to control the climate and wind flow. OPERATION OF THE SCREENS To LOWER the screen press the DOWN button on the remote and the screen will deploy to the preset bottom limit: *** Make sure no obstructions are under the screen during this process, If the screen is lowered down on an object, stop the screen immediately or the Obstacle detection feature in the motor will activate and should raise back up to allow removal of object. If the motor does not stop when object is under the screen during deployment, press the center STOP button on the remote immediately and Remove object, then continue to lower the screen: ‐ To raise the screen press the UP button on the remote and the screen will retract to the preset limit. ‐ You can stop the screen at any position during the raising or lowering of the screen by pressing the STOP button. *** If the screen does not fully deploy to the floor, or the weight bar is hanging uneven please leave the screen in that position and contact your authorized dealer ASAP. ***Raising the screen could cause additional damage. RESETTING/ADJUSTING LIMITS ON SIMU/SOMFY MOTOR (NOTED ON REMOTE) ‐ To adjust the limits, you must let the screen raise or lower until the motor stops! (even if it is not to the desired position) ‐ When the screen is retracted or lowered to the Preset limit you wish to adjust PRESS ...
- Page 2 CARE & MAINTENANCE and WARRANTY - MAGNATRACK SYSTEMS RESETTING OR ADJUSTING LIMITS WITH GAPOSA MOTOR (NOTED ON REMOTE) ‐ The top or bottom limit can be adjusted from any position of the weight bar. ‐ To adjust the TOP limit: Press and Hold‐ BOTH the (Program “FC” button on back RIGHT of remote, and the UP Button) at the same time for 3 to 5 seconds until motor jogs. Adjust to desired position. Then Press and hold the STOP button to encode new limit. ‐ To adjust the Bottom limit: Press and Hold‐ BOTH the (Program “FC” button on back RIGHT of remote, and the DOWN Button) at the same time for 3 to 5 seconds until motor jogs. Adjust to desired position. Then Press and hold the STOP button to encode new limit. ‐ If you do not complete the re‐programing process in 2 min or less or forget to press the STOP button to encode, the motor will revert to fail safe mode! If this happens and the motor only spins ¼ turn DOWN / ¼ turn UP, please contact your authorized dealer that installed the MagnaTrack system. WINDY CONDITIONS ‐ If you are trying to lower the screens in heavy winds the screen might hang up due to excessive strain on the interlock and side tracks. If this occurs, you might have to assist the screen down by pulling on the weight bar or pushing against the screen material during deployment. ‐ Another option while lowering the screen in heavy winds is to press the ...
- Page 3 CARE & MAINTENANCE and WARRANTY - MAGNATRACK SYSTEMS CARE & MAINTENANCE FOR CLEAR VINYL Recommended Products for Cleaning: IMAR Products. IMAR Strataglass Protective Polish, IMAR Strataglass Protective Cleaner, and mild soap (preferably) IMAR Yacht Soap Concentrate). Use of harsh cleaners like “Simple Green, Glass cleaners with Ammonia, and Orpine” will dull the shades quickly. Using any other product(s) void the factory warranty. 303 Clear Vinyl Protective Cleaner is also approved for cleaning of vinyl panels. 303 Clear Vinyl Protectant offers superior protection against the harmful effects of UV rays. This product is all you need to safely clean and protect against yellowing and cracking of vinyl, clear vinyl, leaving a non‐streaking finish. ‐ NEVER use a wash‐and‐wax product on vinyl panels. ‐ WARNING Use of Rain‐X, Pledge, or Plexus on your vinyl panels will appear to work for a short time but then dulls the surface and presents an “Orange Peel” effect. Do not use any of these products. ‐ Use of cleaners, polishes, scratch removers, or any other product made for regular, uncoated vinyl will damage your vinyl panels. Do not use these products. ‐ DO NOT HANDLE VINYL WITH SUNSCREEN ON YOUR HANDS! This will permanently cloud the vinyl where handled. GENERAL MAINTENANCE For the customer: We recommend using IMAR Strataglass protective Polish or 303 Clear Vinyl Protectant or cleaner every 1 to 2 months. Note: All new vinyl can easily get impressions. It is recommended new enclosures be left in place to the extent possible. Vinyl “seasons” over time and becomes less impressionable. Roll all curtains down and fasten in place nightly to keep perfect appearance. Cleaning: Apply the soapy water to the clear vinyl section of the curtain with special purpose washing mitt or soft cotton cloths. Thoroughly rinse the soapy solution with fresh water and completely dry the curtains with a high quality chamois. After washing the curtains, apply 303 or IMAR Strataglass Protective Polish sparingly with small, light circular motions using a soft cotton ...
- Page 4 CARE & MAINTENANCE and WARRANTY - MAGNATRACK SYSTEMS hardware can be done to remove excess dust and debris. This is also a good practice once per year and is recommended for long term operation. Warm water and common dish soap are recommended for cleaning and removal of any dirt, food particles, beverages or other non‐commercial type stains on the shade band. Please contact Fraser Shading or your window covering professional directly with any additional cleaning question or concerns. WARRANTY LIMITED LIFETIME WARRANTY Fraser Shading Systems, the manufacturer, guarantees the material and workmanship of its products to be of excellent quality. All Materials are carefully selected to withstand most weather elements and breakage under normal use. The warranty does not cover claims originated from faulty installations, hail, flood, fire, harmful chemicals and fumes, misuse, abuse, fading, chalking, oxidization, erosion of paint, acts of God, or causes beyond control of the manufacturer. This warranty is for the benefit of the original purchaser and is not transferable. The lifetime material warranty applies to aluminum components only. 5 YEAR WARRANTY Fraser Shading Systems warrants the electrical motors for a period of 5 years, commencing from the date of sale from Fraser Shading Systems, against failure under expected normal use. Warranty is void if the electrical motor is exposed to water, acts of God, or abnormal conditions, including faulty installation. 2 YEAR WARRANTY Fraser Shading Systems warrants the electronic components such as radio transmitters and receivers for a period of 2 year, commencing from the date of sale from Fraser Shading Systems against failure under expected normal use. Warranty is void if the electronic component is exposed to water, acts of God, or abnormal conditions. SCREEN & VINYL WARRANTY Fraser Shading Systems warrants fabrics supplied from Twitchell have a 10‐year limited warranty from the original date of purchase. The warranty covers defects of workmanship, materials, or excessive loss of strength in normal conditions, including sunlight, rot, mildew, or atmospheric chemicals that might render it unserviceable. Improper use, abuse, or use of harsh chemicals will void warranty. Fabrics not manufactured by Twitchell might have different warranties associated. Please see catalog or website for full details and warranty info. ...
- Page 5 CARE & MAINTENANCE and WARRANTY - MAGNATRACK SYSTEMS LIMITATIONS OF WARRANTIES Fraser Shading Systems is not responsible for indirect, punitive, special, incidental, or consequential damages or losses that anyone may suffer or incur in connection with this product or its use. Any warranties implied by law, including those of merchantability and fitness for the use or for particular purpose are limited to materials only in duration of 1 year express warranty hereunder. Some states do not allow limitations on how long a warranty lasts, therefore in those states the limitations are not applicable to the purchaser. This warranty does not cover screen mesh including incidental, misuse, or faulty installation damage. This warranty further does not cover installation costs, removal costs, service calls, and shipping costs of all materials covered in above limited warranties. RECOMMENDATIONS FOR BEST PERFORMANCE: ‐ The more frequently you use the system the better it will perform. ‐ When temperatures are below 10 C (50 F) (Especially when the system has Vinyl Windows) we recommend they are deployed and left down overnight (If applicable) or lower prior to the temperatures dropping below 10 C (50 F) (Especially when the to keep the dimensional stability of the panel and also to keep the vinyl from contracting or cracking. Warranty: Please refer to warranty card provided with invoice. Thank you for purchasing the #1 Motorized Screen Product “MagnaTrack” from Fraser Shading Systems and we hope our system will exceed your expectations! Sincerely, Kerry Nikolai CEO ‐ President Fraser Shading Systems 200619 LICENSED FABRICATOR OF MAGNATRACK...
