SPARKELEC Smart Home - Zigbee Touch Smart Switches Series
All products manufactured by Sparkelec Pty Ltd are AS/NZS safety standards
tested, approved & certified by independent organisations
•
Zigbee Automatic networking technology - no manual code matching, simple system debugging
·
App Control -
Control switches from anywhere with your smart phone
Search "Sparkelec Smart Home" on the Google Play Store or Apple Store
Alternatively download the Android APK Straight from our website
•
Voice Control - Works perfectly with Amazon Alexa and Google Home
·
Timing - Set scheduled/countdown timers to turn on/off at specified time
•
Share Control - Control your smart home together with your family
•
Smart Scene - You can set the switch & GPOs easily to achieve the desired scene mode
•
With red and blue LED indicator - Very distinguished (BLUE Indicator Always On& Red with Activated)
•
Easy to install - L and N wire control
•
Status Indication: (Neutral required, 3 wire design)
•
Switches Support 2 Way or 3 Way intermediate switching
SPARKELEC Zigbee Touch Switches (Off White & Midnight Black)
SWS1T-ZGB WHITE
SWS2T-ZGB WHITE
SWS1T-ZGB BLACK
SWS2T-ZGB BLACK
SWS3T-ZGB WHITE
SWS4T-ZGB WHITE
SWS3T-ZGB BLACK
SWS4T-ZGB BLACK
N
A
84MM
Specifications
Dimensions: 120mm W x 72 H x 37 D
Operating voltage: 110V-240V/50-60HZ
Resistive Max. load: 600W
Inductive Max. load 300W (LED Lighting)
Address: 3/52 – 54 Parramatta Rd
Croydon NSW 2132
Phone: (02) 9745 1302
Email: sales@sparkelec.com.au
SWS5T-ZGB WHITE
SWS6T-ZGB WHITE
SWS5T-ZGB BLACK
SWS6T-ZGB BLACK
Frequency: Zigbee 2.4G
Wireless Fidelity: Zigbee/IEEE 802.15.4
Advertisement
Table of Contents
Summary of Contents for SPARKELEC Zigbee Touch Smart Switches Series
- Page 1 · App Control - Control switches from anywhere with your smart phone Search “Sparkelec Smart Home” on the Google Play Store or Apple Store Alternatively download the Android APK Straight from our website • Voice Control - Works perfectly with Amazon Alexa and Google Home ·...
- Page 2 Wireless Fidelity: Zigbee/IEEE 802.15.4 Size: 480mm x 480mm x 100MM The Sparkelec smart home gateway is the centre of control for our smart home Zigbee device. Users can design and implement smart application scenarios by adding devices to the hub.
- Page 3 Installation & Warranty Statement All products must be installed by a licensed electrician. Power must be off before installation Do not modify any parts of our product. Warranty: This warranty covers defects in manufacturing that arise from the correct use of the device. It’s limited to defects in materials or workmanship and does not cover damage caused by abuse, misuse, unauthorised modification power surge damage or extreme heat or cold or corrosive environments.
- Page 4 Afer Product installation: Download Our App via Google Play or Apple Store (SCAN QR CODE) Download Our App via Google Play or Apple Store - Search “Sparkelec Smart Home” or Download Android APK via our website. App Communication – ZIGBEE HUB 1.
- Page 5 “button of the switch or power point for 5 seconds. The” “button’s backlight will start flashing. Then release finger and open the ”Sparkelec Smart Home” App On top right-hand corner Select ”+", then choose ”add”, choose “Switch (zigbee)”, select "next" and then select "gateway"...
- Page 6 Setting up 2 way or 3 way switching: Search for “Associated Devices” under "device information" Choose ' A ssociated Devices’ Add Associated device Then exit learing mode. Learning mode will exit if you have (no operations) after 1 min...
