Summary of Contents for SIP-ATA SIP-GW2
-
Page 1: Table Of Contents
Table of Contents 1. WELCOME ………………………………………………1 User Manual 2. INSTALLATION ..............1 3. WHAT IS INCLUDED IN THE PACKAGE…………….3 SIP-GW2 3.1 SAFETY COMPLIANCES ........….3 SIP Analog Telephone Adaptor 4. PRODUCT OVERVIEW …………………………………4 4.1 KEY FEATURES ..........…….….4 4.2 HARDWARE SPECIFICATION ......…..5 5. BASIC OPERATIONS …………………………………...6 5.1 Make Phone Calls ..........……….. -
Page 2: Welcome
1. Welcome 5.3.5 Call Forwarding ..........………..10 5.3.6 3-Way Conference Call ........………..11 Thanks for your choice. SIP-GW2 is an all-in-one VoIP 5.3.7 IP Dialing………………………………………………12 integrated access device that features super audio quality, rich 6. Configuration Guide ........………….13 functions. It is fully compatible with SIP industry standard and 6.1 Get Familiar with Key Pad and Tone Prompt .. -
Page 3: Sip-Gw2
3.1 Safety Compliances 0.2s Flash The SIP-GW2 is compliant with various safety standards including FCC/CE. The SIP-GW2 should only operate with the Interconnection Diagram of the SIP-GW2: universal power adaptor provided in the package. Warning: Please do not attempt to use a different power adaptor. -
Page 4: Product Overview
17) Compact, lightweight Universal Power adapter. concealment technology to ensure super audio quality. 4.2 Hardware Specification 7) Support various voice codes including G.711U, G.711A, Model SIP-GW2 G.729A. LAN interface 1XRJ45 10/100M Base-T 8) Support Caller ID/Name display or block. WAN interface 1XRJ45 10/100M Base-T 9) Support call waiting and call forwarding. -
Page 5: Basic Operations
Note: Other functions available during the call are call-hold, 1) When SIP-GW2 is out of power, the RJ11 line jack will call-wait, call-transfer, and call-forward (section 5.3). act as a pass through jack. The user will be able to use the same 5.1.2 Make PSTN Calls... -
Page 6: Answer Phone Calls
Pick up the analog phone, if LED “SIP” light, Press “**” When STATUS is ready (LED “STATUS” light), pick up or “#” to switch to PSTN line. the analog phone, press “*69” to call out the latest call-in LED “PSTN” light, and get a PSTN line dial tone, dial the numbers. -
Page 7: Blind Transfer
Disable call waiting temporarily To enable “Unconditional Call Forward”, dial “*72” and get the dial tone. Dial the forward number and press # then When STATUS is ready (LED “STATUS” light), pick up hang up. the analog phone, press “*70” to temporary disable call waiting, To disable “Unconditional Call Forward”, dial “*73#”... -
Page 8: Ip Dialing
1. A presses FLASH on the analog phone, or Hook Flash port is not mentioned, the default SIP port of 5060 is used. to get a dial tone. Some valid IP dial call examples are: 2. Dial C’s number, and press #(or wait for 4 seconds). *4712345**172*25*20*178*5060# 3. -
Page 9: Setup Ip Address For Wan
6.2 Configuring SIP-GW2 with Web Browser 6.1.6 Setup DNS for WAN SIP-GW2 ATA has an embedded Web server that will *#*#05 – Pick up the analog phone, press “*#*#05”, and respond to HTTP GET/POST requests. It also has embedded... -
Page 10: Access The Web Configuration Menu
The WAN port is set to obtain IP address automatically from factory 6.2.2 End User Configuration Once this request is entered and sent from a Web browser, the SIP-GW2 will respond with a login screen, Input user ID and password, default is User ID: user The page above displays the current information of SIP-GW2. -
Page 11: Basic Setting
SIP-GW2 will access Internet by WAN Port. If you place SIP-GW2 behind DSL modem, you need to input PPP user ID and password, and SIP-GW2 can act as a router for other PC Internet access. Press “Confirm” to save your settings in memory, press “Cancel”... - Page 12 2) LAN Port Settings The SIP-GW2 provides one LAN Port for next PC, and PC can access Internet by SIP-GW2. If you hope the next PC have the same subnet with LAN port, select “Act as a Gateway for PC”; if you hope the next PC have the same subnet with WAN port, select “Act as a Bridge for PC”.
-
Page 13: Advance Setting
a. Bridge: Enable to connect the LAN to the WAN (bridge the two connections). This is available in Bridge Mode only. Default is “Disabled”. b. IGMP: IGMP (Internet Group Management Protocol) relay/proxy specification and environment, default is Disabled. IGMP is available in all modes and all Now your settings have been saved and activated. - Page 14 DNS Proxy Enable/Disable: When the DNS Proxy is solve the scenario where the ISP only recognizes one MAC “Disabled”, the LAN port does not process the DNS query Address. Default is “Disabled”. message. For the DHCP requests from local PCs, the DHCP MAC Address: When MAC Spoofing is enabled, copy the server will set the user-configured DNS server as the DNS ISP-recognized MAC address here.
- Page 15 negotiation, the peer of the PPP connection will indicate User Name: Enter the PPP user name (provided by the ISP). its MRU and will accept any value up to that size. The The User Name can be up to 127 characters. actual MTU of the PPP connection will be set to the Note: You cannot have two different user accounts with the smaller of the two (MTU and the peer’s MRU).
- Page 16 that TCP will send in a single, unfragmented IP packet. Timeout or manual disconnect), the Automatic Reconnect will not reconnect the session. This box is The LAN client and the WAN host will indicate their unchecked by default. MSS during the TCP connection handshake. Press “Confirm”...
- Page 17 Explorer to access these pages). You can change this DHCP address pool the range from 10.0.0.3 to to another private IP address and subnet mask, such as 10.0.0.14. 192.168.1.2 and 255.255.255.0. • User Defined: When User Defined is selected, the b.
- Page 18 DHCP address pool. Press “Confirm” to save your settings in memory, press “Cancel” to cancel the change before saving. 3) Save Settings and Reboot It is the same as Basic Setting, you can read page21 for detail. SIP-GW2 V2.0 2005-11-18...
