- Page 1 Promise to Perform Industries, Inc. T-SERIES GANTRY CRANE Assembly and Maintenance Instruction Manual ISO 9001:2015 Registered Manual 103-0001 Effective Date: September 2022...
- Page 2 15. Before moving the gantry under load, remove any obstacles and ensure that the load is not attached to the floor. 16. Spanco Gantry Cranes are designed to be moved manually. Do not push or pull the gantry with a lift truck or other vehicle.
- Page 3 26. Do not allow the hoist trolley to strike the end stops or gantry supports at any time. 27. The system must be tied down if exposed to winds exceeding 30 miles per hour. Spanco considers it an unsafe practice to operate cranes in winds over 15 miles per hour.
-
Page 4: System Applications
SYSTEM APPLICATIONS The Spanco system is used for material handling applications. This material handling system is labeled with a maximum rated capacity and is designated for Class C service as defined by the CMAA; follow all limitations as noted on system labels. -
Page 5: Table Of Contents
LABELING ..................................18 INSPECTION CHECKLISTS ............................19-20 Before Each Use Inspection Checklist ..........................19 Annual Inspection Checklist............................20 PRODUCT WARRANTY COVERAGE ..........................23 ABOUT SPANCO ............................. BACK COVER Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 1 ® 1-800-869-2080 | Rigid Lifelines... -
Page 6: Assembly Instructions
DO NOT REMOVE OR DISCONNECT THIS CABLE) 6 ) Four Casters 7 ) All Beam, Leg, and Caster Hardware and Hardware Kits 8 ) Any optional components, such as Height Adjustment Kit and Gantry Cart Kit. T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 2 Spanco ®... -
Page 7: Attaching The Caster Brakes To The Caster Assemblies
Reapply the axle nut at this time. Using a 3/4-inch wrench and 3/4-inch socket and ratchet, securely tighten the caster nut. Repeat steps c) through i) to install the remaining caster brakes. Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 3 ®... -
Page 8: Attaching The Swivel Locks To The Caster Assemblies
Per Detail “A,” insert a hex bolt (20) through each of the aligned holes in the caster frame and the caster assembly so that the bolts extend from the caster assembly’s top plate. T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 4 Spanco... -
Page 9: Attaching The Hanger Assemblies To The Beam
37, 38 Hex Bolt Locknut 37, 38 Push/Pull Pin with Linch Pin End Stop Angles Hex Bolt Lock Washer NOTE: 5/8-inch locknuts (26) should be torqued to 108 foot-pounds. Hex Nut Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 5 ®... -
Page 10: Attaching The Support Legs To The Beam
Brace Leg Main Leg Hanger Assembly 31, 32, 33 Brace Leg Hanger Assembly Hex Head Bolt Lock Washer 28, 29, 30 Hex Nut Hex Head Bolt Lock Washer Hex Nut T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 6 Spanco ®... -
Page 11: Attaching The Caster Frame Assemblies To The Support Legs
(12). h ) Repeat steps e) through g) to attach the other end of the caster frame assembly to the support leg. Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 7... -
Page 12: Final Assembly
Figure 2. The second push/pull pin must be in place prior to making any lift. Repeat steps c) through e) to adjust the remaining support legs. T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 8 Spanco... -
Page 13: With Height Adjustment Kit
) Per Figure 4 on page 10, wrap the shorter cable lanyard with a loop and snap hook located at the top of the height adjustment kit around the upper main leg and insert the shorter cable into the attached clip. Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 9... -
Page 14: Optional Accessories
Gantry. The gantry cart kits sits on top of the caster frames and uses the same hardware to attach as the leg assembly. To adjust the carts length, remove the push/pull pin and adjust to desired length. Reinsert the push/pull pin and secure with the linch pin attached. T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 10 Spanco ®... -
Page 15: Tagline Assembly
Fasten V-groove track to the floor using 3/8-inch lag bolts and suitable anchors. (For track supplied by Spanco, use a bolt in each hole. Otherwise, space bolts approximately three feet apart on each side of the track in a staggered arrangement.) Use shims or grouting as required to keep the track level and alignment pins at joints to keep the track true. -
Page 16: Runway Alignment Tolerance For V-Groove Track
A=3/16” in any (2 Runway) (L+A) (L-A) support span Rail to Rail E=1/4” between Elevation adjacent rails Nom. Tread Line C=1/4” in any Straightness support span D=1/4” in any Elevation support span T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 12 Spanco ®... -
Page 17: Maintenance And Load Test
Applications involving vacuums, magnets, or other high-impact lifters are considered severe usage and require special design considerations. Contact Spanco for special design pricing. Consult Spanco for usage other than Class C and all instances of high cycle rates or high-impact applications such as high- speed air or electric hoists, vacuum lifters, or magnets. -
Page 18: Correct Configuration For T-Series Gantry
CORRECT CONFIGURATIONS FOR T-SERIES GANTRY Spanco T-Series Gantry Cranes can be used in different crane configurations. The figures below illustrate the configurations for a T-Series Gantry Crane considered stable in lifting and transporting loads when all requirements for operation are met. -
Page 19: Disassembly
Brace Leg Hanger Assembly I-Beam Hanger Weldment Push/Pull Pin with Linch Pin 28, 29, 30 Hex Head Bolt Lock Washer Hex Nut Hex Head Bolt Lock Washer Hex Nut End Stop Angles Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 15 ®... -
Page 20: Removing The Caster Frames
) Remove the caster frames from underneath the support legs. Detail “D” ITEM DESCRIPTION Lower Main Leg Lower Main Leg Bottom Bracket Hex Bolt Caster Frame Sleeve Lock Washer 10, 11, 12 Caster Frame Hex Nut Assembly T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 16 Spanco ®... -
Page 21: Removing The Hanger Assemblies
The caster frame assemblies do not need to be disassembled further, but may be further disassembled if desired. Detail “B” ITEM DESCRIPTION Beam Main Leg Hanger Assembly Brace Leg Hanger Assembly I-Beam Hanger Weldment Push/Pull Pin with Linch Pin End Stop Angles Counterweight Lug Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 17 ®... -
Page 22: Labeling
The letters correspond to the accompanying labels. All labeling must be legible and attached to the system. If at any time these labels are lost, stolen, removed, or become illegible, contact Spanco. Labels can be ordered by part number as listed below. -
Page 23: Before Each Use Inspection Checklist
6. Ensure that the caster brakes make contact with the caster material for maximum effectiveness. ©2022. All Rights Reserved. All specifications and product designs subject to change without prior notice. Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 19 ®... -
Page 24: Inspection Checklists
14. Check the electrical apparatus, if supplied, for any deterioration of the controller contactors, limit switches, and push button stations. 15. Check system for unauthorized modifications. Only Spanco can authorize modifications. Remove system from service if it is modified in anyway. - Page 25 Promise to Perform Industries, Inc. Notes Spanco.com • 1-800-869-2080 • Spanco T-Series Gantry Crane 21 ®...
- Page 26 T-SERIES GANTRY CRANE MANUAL Promise to Perform Industries, Inc. Notes T-Series Gantry Crane • 1-800-869-2080 • Spanco.com 22 Spanco ®...
-
Page 27: Product Warranty Coverage
Only applies to the wearable wheels on workstation bride crane end trucks and hoist trolley Spanco warrants its manual workstation bridge crane, jib crane, and gantry crane products to be free from defects in material and workmanship for a period of ten (10) years or 20,000 hours, commencing on the date of shipment to the first retail purchaser. -
Page 28: About Spanco
Spanco production facilities are certified under the ISO 9001:2015 Quality Management System to provide superior quality products. Every welder at Spanco is AWS D1.1 certified to handle steel products in accordance with the rigorous requirements and lab testing established by the American Welding Society. Our aluminum welders are also AWS D1.2 certified to handle aluminum products. - Page 29 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SPANCO, Item Building Materials Description Detail "B" Detail "D" Quantity INC. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF SPANCO, INC. IS PROHIBITED. Beam (Beam Hanger Assemblies, End Stop Angles, (Caster Frame Assemblies Detail "A"...
- Page 30 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SPANCO, "D" "G" INC. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF SPANCO, INC. IS PROHIBITED. "F" "F" "B" "C" "A" "J" "E" "I" "I" "A"...
