iSmartEV P01 User Manual
Copyright Information
Copyright © 2021 by SHENZHEN SMARTSAFE TECH CO.,LTD. All rights
reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission of
SMARTSAFE.
Neither SMARTSAFE nor its affiliates shall be liable to the purchaser of this unit
or third parties for damages, losses, costs, or expenses incurred by purchaser or
third parties as a result of: Accident, misuse, or abuse of this unit, or
unauthorized modifications, repairs, or alterations to this unit, or failure to strictly
comply with SMARTSAFE operating and maintenance instructions. SMARTSAFE
shall not be liable for any damages or problems arising from the use of any
options or any consumable products other than those designated as Original
SMARTSAFE Products or SMARTSAFE Approved Products by SMARTSAFE.
All information, specifications and illustrations in this manual are based on the
latest information available at the time of printing. SMARTSAFE reserves the
right to make changes at any time without prior written or oral notice.
Trademark Information
SMARTSAFE is a registered trademark of SHENZHEN SMARTSAFE TECH
CO.,LTD. in China and other countries. All other SMARTSAFE trademarks,
service marks, domain names, logos, and company names referred to in this
manual are either trademarks, registered trademarks, service marks, domain
names, logos, company names of SMARTSAFE or are otherwise the property of
SMARTSAFE or its affiliates. In countries where any of the SMARTSAFE
trademarks, service marks, domain names, logos and company names are not
registered, SMARTSAFE claims other rights associated with unregistered
trademarks, service marks, domain names, logos, and company names. Other
products or company names referred to in this manual may be trademarks of
their respective owners. You may not use any trademark, service mark, domain
name, logo, or company name of SMARTSAFE or any third party without
permission from the owner of the applicable trademark, service mark, domain
name, logo, or company name. You may contact SMARTSAFE by visiting the
website at www.newsmartsafe.com, or writing to SHENZHEN SMARTSAFE
TECH CO.,LTD., 3310, Building 11, Tianan Cloud Park, Bantian Street,
Longgang District, Shenzhen, Guangdong, China, to request written permission
to use Materials on this manual for purposes or for all other questions relating to
this manual.
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iSmartEV P01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smartsafe Tech iSmartEV P01

  • Page 1 P01 User Manual Copyright Information Copyright © 2021 by SHENZHEN SMARTSAFE TECH CO.,LTD. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of SMARTSAFE.
  • Page 2 P01 User Manual To avoid personal injury, property damage, or accidental damage to the product, please read all the information in this chapter before using the product. Operation Specification For New Energy Vehicle Safety Maintenance 1. Identification of high voltage components: The orange wiring harnesses of the vehicle are all high voltage wires.
  • Page 3 P01 User Manual 6. High voltage debugging must be carried out under the premise of good low voltage debugging, so as to determine whether the battery has leakage. If there is leakage, it should be checked in time, and high voltage debugging cannot be carried out.
  • Page 4 P01 User Manual responsible for any damage or loss caused by the use of other chargers not designated by the Company. 10. Keep the testing equipment dry and clean, away from gasoline, water and grease. When necessary, clean the surface of the equipment with a clean cloth coated with a mild detergent.
  • Page 5: Table Of Contents

    Table of Contents 1. Packing List ....................1 2. Product Introduction ................6 2.1 Overview ....................6 2.2 iSmartEV P01 Tablet ................6 2.3 iSmartEV BOX Detection box ..............8 2.4 Technical parameters ................8 3. Initial Use ....................10 3.1 Charge the Tablet ................10 3.2 Turn On/Off ..................
  • Page 6 P01 User Manual 11.5 Battery Maintenance System Reset ...........41 11.6 ABS Bleeding ..................42 11.7 Throttle learning ................. 42 11.8 Tire Pressure Monitor System Reset ..........42 11.9 Diesel Particulate Filter (DPF) regeneration ........43 11.10 Gearbox Matching ................43 11.11 Gear Learning ..................
  • Page 7 P01 User Manual 13.1 Remote diagnosis request ..............49 13.2 Assist others remotely ................50 13.3 Contact list ..................51 14. Personal center ..................53 14.1 My connector ..................53 14.2 Connector activation ................53 14.3 Firmware fix ..................53 14.4 Personal information ................
  • Page 9: Packing List

    P01 User Manual 1. Packing List Each machine has the same general accessories, but the product configuration is different for different markets. For details, please consult the local dealer or refer to the packing list delivered randomly with the product.
  • Page 10 P01 User Manual USB Cable (Type-C) USB Cable (Type-B) Power Adapter (12V 5A) Password Envelop Quick Use Guide User Manual Packing List Special Connector for Battery Pack Name Q'TY Reference Picture Special connector for battery pack TL-100R...
  • Page 11 P01 User Manual Special connector for battery pack TL-101R Special connector for battery pack TL-102R Special connector for battery pack TL-104Y Special connector for battery pack TL-105R Special connector for battery pack TL-106R Special connector for battery pack...
  • Page 12 P01 User Manual Special connector for battery pack TL-113Y Special connector for battery pack TL-114Y Special connector for battery pack TL-126R Special connector for battery pack TL-130R Battery Pack Jumper and Adapter Cable Name Q'TY Reference Picture Battery pack jumper...
  • Page 13 P01 User Manual Adapter Cable 4 Adapter Cable 5 Adapter Cable 6 Adapter Cable 7 Adapter Cable 8 Adapter Cable 9...
  • Page 14: Product Introduction

    P01 User Manual 2. Product Introduction 2.1 Overview iSmartEV P01 New energy vehicle battery pack detector is a professional comprehensive testing equipment for new energy vehicles developed by SmartSafe Company. The equipment supports new energy vehicle testing and vehicle battery pack testing functions, and has integrated professional measurement tools such as oscilloscope, multimeter, insulation testing, current clamp etc.
  • Page 15 P01 User Manual Name and Description 10.1-inch touch screen Front facing camera Power indicator light: Red during charging and green after fully charged. Handle Volume - Volume+ Power button/screen lock button • Press the button for about 3 seconds to start the machine when the power is off.
  • Page 16: Ismartev Box Detection Box

    P01 User Manual modules. Flash light Rear camera Holder Loudspeaker 2.3 iSmartEV BOX Detection box The device is a Vehicle Communication Interface (VCI) device, which is used to connect the vehicle diagnosis seat or battery pack low-voltage signal communication interface for data collection, and then send the data to the host for analysis.
  • Page 17 P01 User Manual Item Specification Parameters Operation System Android 7.1 8-core processor,2.0GHz Internal Storage Storage 128GB 10.1 inch,1920 * 1200 resolution touch screen Display Screen Front Facing Camera 8 million pixels Rear Camera 13 million pixels Wi-Fi 2.4GHz/5GHz Wi-Fi...
  • Page 18: Initial Use

    Please follow the following steps to charge the iSmartEV P01 tablet: 1. Connect one end of the charging cable to the USB port on the charger and the other end to the Type-C port on the host, and connect the charger to the power socket.
  • Page 19: Registration And Upgrade

    P01 User Manual 3.4 Registration and Upgrade During the first use, the user needs to follow the following operations: Register an Account VCI connector Activation Complete Registration Software Download Note: Before registration, ensure that the network connection to the host is normal and stable.
  • Page 20 P01 User Manual In the figure above, fill in the registration information in turn (the item with * is required). After the account information is filled in, click [Register], and the system will enter the interface of connector activation.
  • Page 21 P01 User Manual Click [Confirm] to enter the software upgrade interface. On the software upgrade page, click [One-click Upgrade] to start downloading. After the download is complete, the system will automatically install the software. Note: During the upgrade, ensure that the network connection is normal. In addition, due to the large number of software, it may take a long time (depending on the network speed).
  • Page 22: Getting Started

    P01 User Manual 4. Getting Started 4.1 Main interface and bottom navigation bar 4.1.1 Main interface The main interface of iSmartEV P01 mainly includes the following functions modules: Items Description Battery Pack This function is used for deep system detection of the vehicle Detection battery pack.
  • Page 23: Communication Settings

    P01 User Manual This module works with the new energy current clamp Current (optional) for AC/DC current test and DC voltage test. For Clamp details, refer to the user manual enclosed with the new energy current clamp. This module works with the specified ADAS calibration tool...
  • Page 24 P01 User Manual 4.2.1 Wi-Fi communication The host will prompt the user to register and activate the VCI connector during the first use. Once the activation is complete, the host will automatically match with the VCI connector and establishes a Wi-Fi connection. At this time the VCI...
  • Page 25: Battery Pack Detection

    Operating the battery pack without protection can cause a serious electric shock. 1. Start the iSmartEV P01 and click [Battery pack detection] on the main interface. 2. Select the vehicle brand or battery pack brand(You can find it quickly through...
  • Page 26 P01 User Manual 3. Select the vehicle model and year. 4. Select the connection method of battery pack. Note: For cars that support fast charging port detection, the "Fast Charging port detection" interface will be displayed after the connection mode is selected as [Fast Charging port Detection].
  • Page 27 P01 User Manual Connect special connectors for battery packs Connect the iSmartEV BOX detection BOX and the low-voltage signal communication interface of the battery pack respectively with the battery pack special connector to test the vehicle battery pack.
  • Page 28 P01 User Manual 5. After the connection is complete, the device automatically reads and displays the detailed data of the battery pack. Users can determine the abnormal status of the battery pack based on the detection data. Description for screen buttons: Click to return to the main interface.
  • Page 29 P01 User Manual state and module data in the battery pack, which is Information】 convenient for the maintenance personnel to quickly determine the fault point. Used to read the fault code in the current battery pack 【Fault Code BMS system.
  • Page 30: Quick Charging Port Detection

    P01 User Manual 6. Quick Charging Port Detection The function module must be equipped with iSmartEV FC01 new energy vehicle battery pack detection gun (optional), and the battery pack can be quickly detected through the DC quick charging port of new energy vehicle, so as to help the maintenance personnel quickly determine the battery pack fault.
  • Page 31 P01 User Manual 4. Select the serial number of the current detection gun for connection. Note: 1) When testing again, the system will automatically connect the detection gun. 2) If you need to switch the detection gun, please close the previously connected device and search for the connection again.
  • Page 32 P01 User Manual 6. Click [Save] to save the quick test report on the host. 7. Click [Share] to generate the two-dimensional code, and scan the two- dimensional code to share the report.
  • Page 33: Vehicle Detection

    P01 User Manual 7. Vehicle Detection This function is mainly used for vehicle detection. Users can use "intelligent detection" to quickly identify vehicle information and enter the system for vehicle detection, or manually select models and systems for detection.
  • Page 34 P01 User Manual 2. Click the vehicle brand to be tested to enter the model version information interface (for example: BYD). Screen button description: Click to view the current vehicle models that can be 【Vehicle models that tested can be tested】...
  • Page 35 P01 User Manual 4. Select the test options you want to perform. Note: Different models will have different systems and common special functions, users can choose the required options for testing . 7.2.1 Quick test This feature is used to quickly detect the vehicle and output the vehicle health report directly (this will only be displayed if the vehicle testing software supports this function).
  • Page 36 P01 User Manual the fault codes of other systems. To view details about the fault code, click Click to enter the system and choose to perform other 【 】 functions. Please refer to Chapter 7.2.2 for details. Click to select the report before maintenance. By...
  • Page 37 P01 User Manual diagnostic scan (if no comparison is required, you can select "Diagnostic Scan"). The device has the report comparison function, so you need to select a correct report type when saving reports. By comparison, maintenance technicians can clearly understand whether the fault codes found before diagnosis have been completely cleared after maintenance.
  • Page 38 P01 User Manual displayed. "ECM", for example. Note: The test menu may be different for different models. Version information This function is used to read the ECU version information of the current vehicle. Read fault code This function is used to read the fault code existing in the current car ECU, and help maintenance personnel quickly understand the cause of vehicle failure.
  • Page 39 P01 User Manual If the button is highlighted, the frame is frozen. The freezing frame function is to record the values of some 【Freeze frame】 specific data streams at the moment when the car breaks down for verification.
  • Page 40 P01 User Manual Screen button description: Select all data stream options on the current page. 【Current page】 Select all data stream options. 【Select all】 【Cancel selection】 Click to cancel all the selected data stream options. Confirm the current operation.
