- Page 2 Thank you for purchasing our products, before you use the unit, please read the instructions. Precautions 1. Please don't expose the unit in humid, dusty, steam, lampblack and other related severe environment. 2. Please use soft cloth to clean the unit, and don't use diluent or any other chemical cleaner. 3.
- Page 3 Main Functions Main Configuration Forward Collision Warning Screen : 6.86 Inch IPS Screen 1280*RGB* 480 Lane Departure Warning CPU : Quad-Core ARM Cortex A7 @1.3GHz Pedestrian Detection Warning RAM/ROM : 1GB /16GB Front Car Start Alarm GPU : Mali 400 MP2 Reverse Panoramic View Front camera : OV2718 1080P 140 Degrees 1080P HD Dual Driving Record...
- Page 4 Product Appearance & Description 1.Screen 2. Power Button 3. Mic 4. GPS Antenna 5. TF Slot 6. Rear Camera Port 7. Power 8. Front Camera...
- Page 5 Basic Operation 1. Turn on/off The device will start automatically when the power supply is connected. When the system is in dormant state, you can wake up the system by pressing the "power" button. When the power supply is disconnected, the system automatically pops up the "sleep/power off"...
- Page 6 Main Interface Homepage The homepage shows the main functions and related information: Time, Date, Recorder status, GPS status, WiFi, Speed. Clicking any function’s image can bring you to certain interface.
- Page 7 Main Functions Front Camera Interface: Click on the center of the main interface will enter the recorder interface Note : Insert TF card, the system will automatically start the front and rear recorders. In order to prevent accidental damage of im p o r t a n t vi d e o da t a , pl e a s e ba c k u p i m p o r t a n t v i d e o f i l e s i n t i m e .
- Page 8 Back Camera Interface: Click on to switch to the reverse camera Back camera : 1080P HD camera support 180 degrees wide angle. Press the to adjust the display area of the reverse camera.
- Page 9 GPS Navigation: Click on the “Maps” to switch to navigation The unit is pre-installed with Google Map. You can choose other map apps for android to install according to your needs. Installation Method 1: App store download Installation Method 2: Download the software in TF card directory: / SEOS, insert TF card into the unit, find the directory “...
- Page 10 After installation, the default navigation software can be selected by pressing the navigation options in the main interface for a long time. Note: The unit does not guarantee all android s o f t w a r e c a n b e i n s t a l l e d a n d r u n successfully.
- Page 11 Music Click on the "Music" of the main interface to enter the music application to display more music information, or to perform more operations. Shortcut keys: previous song, pause/play, next song Note: The default player can only play local music. You can download other music apps for online music, but the shortcut keys are invalid.
- Page 12 ADAS------FCW: Forward Collision Warning The camera sensor provides an imminent collision warning. By calculating the distance of the vehicle in front and taking into account the relative speed of the vehicle, the system concludes the time at which the collision may occur and provides a warning s o u n d “...
- Page 13 ADAS------LDW : Lane Departure Warning The lane departure warning system is a horizontal monitoring system that monitors the vehicle's position in the current lane and reminds driver to avoid accidental lane drift. The system uses a camera to monitor the lane markings of the road ahead, and when the system detects a deviation from the lane, the system provides a warning sound...
- Page 14 ADAS------PDW: Pedestrian Detection Warning The front camera can detect pedestrians in real time as they pass through the vehicle. The system identifies the distance and relative speed between the vehicle and the object, and issues a warning sound “beep beep...” when it reaches a critical point.
- Page 15 ADAS------Front Car Start Alarm When waiting for a stop on the road (such as at a traffic light), the system will alarm “Jingle...” sound when the camera detects the front vehicle starts moving.
- Page 16 AHD : Reverse Panoramic View When the vehicle is reversing, the 180 degree wide-angle rear camera will collect the surrounding image data and synthesize a panoramic stereo image around the vehicle, which fully solves the problem of the parking blind zone, so as to achieve the purpose of assisting the driver to park easily.
- Page 17 • System Setting: Click on the “setting” in main interface to switch to system settings...
- Page 18 • ADAS Setting: Click on the in camera interface to switch to ADAS settings...
- Page 19 Preview Setting :...
- Page 20 Image Calibration:...
- Page 21 End Processes Long press to enter the process interface. Slide each process to end the process, Click on the to end all processes. Note: Ending all processes will cause the recorder to stop working, Please turn on the recorder in time. * Don’t install other software without permission, Other software may lead to abnormal work or system failure.
- Page 24 Installation Steps 1. Installation location The unit must be placed in the center of the vehicle dashboard. Please determine the location of the dash board where the unit to be placed, use dry cloth to clean the dash board, make sure the dash board don’t have dust, grease to guarantee the 3M glue effect.
- Page 25 2. 3M Glue and Base Installation Tear the 3M adhesive and paste it on the dash board, fix the base on the 3M adhesive well. Make the unit perpendicular to the base, rotate the unit 90 degrees clockwise to get it fixed.
- Page 26 3.Insert TF Card 4.Cable Connection...
- Page 27 5.Put the extension line along the windshield edge in the corresponding position of the vehicle. 6.Insert the cigarette lighter into the cigarette lighter socket. 7.Install the reverse camera, and take care of the direction. 8.Star the car engine, check whether the unit is working properly. * The unit built-in battery for dormancy use only after power disconnection, It can't keep working without power supply.
- Page 28 Place calibration cloth according to the picture instructions, adjust the reverse camera to suitable angle and fix it.
- Page 29 Mono Reverse: Click on the in camera interface to switch to Preview Set → Mono Reverse *Please input vehicle parameters according to vehicle information. If the data is inaccurate, it will affect the accuracy of the image.
- Page 30 Please choose the scope of video clipping. Follow the steps to calibrate the image. *Please do not move the reverse camera after calibration. If you move the reverse camera, please re-calibrate *The calibration cloth must be matched with the unit. Please keep the calibration cloth properly.
- Page 31 Adjust the reverse warn line: turn on the reverse warn, The area of warn line can be adjusted by pressing the warn line 2 seconds when reversing. When reversing, the panoramic image is displayed on the left and rear view image is displayed on the right. *The panoramic image is a composite image, which is only for reference when reversing.
- Page 32 in camera interface to switch to Assist Setting → Focus Setting Focus Setting：Click on the Adjust the front camera to suitable angle: Camera centered left and right, the front part of the car should not exceed 1/4 of the screen display. Please adjust the horizon and vertical lines according to the picture instructions. Locate the focus at the junction of the horizon and the center.
- Page 33 Assist Setting Instructions Lane Departure Warning depends on clear lane markings, LDW will not perform without lane markings, please note!
- Page 34 The default settings of the device conform to the usage standards, You can adjust the settings according to your needs. Or adjust different settings according to expressway or ordinary roads.
-
Page 35: Icon Interpretation
Icon Interpretation: Recording Wifi connected Wifi disconnected GPS connected GPS disconnected Lane recognition Right lane departure Left lane departure Forward collision warning warning warning Pedestrian Detection Lane recognizing Video locked Warning Safety level Early warning level Dangerous level... - Page 36 The ADAS aims to improve driving safety but can't avoid accidents completely. As the ADAS can't reach 100% identification rate due to the reasons: without GPS signal, without obvious lane lines on the road, heavy rain or fog causes the camera can't identify clearly, or other technical limitations. Please don't rely on it completely and drive carefully.
- Page 37 General Obstacles and Exclusion Unable to detect TF card: 1. Check if TF card is inserted; 2. Check if TF card is damaged. The recorder stops working: 1. Format the TF card; 2. Replace a new TF card. The screen does not light on: 1. Press the POWER button to check if it is in standby; 2. Check if the device is connected to the power.
