Kool Karz Playground KKUTV-014 Owner's Manual

Utv battery powered ride-on
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UTV
BATTERY POWERED RIDE-ON
KKUTV-014
Type without roof
Owner's Manual
with Assembly Instructions
Styles and colo(u)rs may vary.
Made in China.
The owner's manual contains important safety information as well as assembly, use and
maintenance instructions.
The Ride-on Car must be assembled by an adult who has read and understands the
instructions in this manual.
Keep the package away from children and dispose of properly before use.
Keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KKUTV-014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kool Karz Playground KKUTV-014

Summary of Contents for Kool Karz Playground KKUTV-014

  • Page 1 BATTERY POWERED RIDE-ON KKUTV-014 Type without roof Owner’s Manual with Assembly Instructions Styles and colo(u)rs may vary. Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual.
  • Page 2 About Your New Ride-On │ 1 On the purchase of your new Ride-On. This ride-on will provide your child with many miles of riding of enjoyment. To help assure you and your rider a safe ride we ask you to please read this manual carefully, and keep it for future reference.

  • Page 3: User Notice

    User Notice │ 2 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED. • Always remove protective material and poly bags and dispose before assembly.

  • Page 4: Parts Diagram

    Parts Diagram │ 3 HINT: Some parts shown are assembled on both sides of vehicle Type R/C Basic type =]]]...

  • Page 5: Parts List

    Parts List │ 4 Q’ty (pcs) PART PART NAME REMARKS without roof Vehicle body Rear wheel Front wheel Ø12 washer Lock nut Split pin Hubcap Steering column Steering wheel M5x35 machine screw Ø5 nut Front bumper Left and right Ø4x12 flat head screw Bakset base Bakset fence Shift lever assembly...
  • Page 6 Attach the Front Bumpers & Tailight Cover │ 5 Assembly tools required (not included): Long nose pliers Screwdriver 1. Insert the tabs on the front bumper into the holes on the front of the vehicle, push until you hear it “click” into place. 2.
  • Page 7 Basic type - Attach the Steering Column │ 6 HINT: The follow steps only for the basic type. Front Bottom View Turn the vehicle body downside up. 1. Slide a Ø12 washer onto the steering column from the straight end. 2.
  • Page 8 Type /RC - Attach the Steering Column │ 7 HINT: The follow steps only for the R/C type. Front Bottom View Turn the vehicle body downside up. 1. Insert the straight end of the steering column through the hole on the steering gear box, the hole on the vehicle body, and out through hole on the dash.
  • Page 9 Reset the Front axle │ 8 Front Bottom View Split pin M6X20 machine screw Ø12 washer Steering column Front axle linkage Ø6 washer Front axle plate Front axle plate Tools required (not included): Long nose pliers Ø6 lock nut Ø6 lock nut Cut off the plastic tie on the front axle with scissors.

  • Page 10: Attach The Rear Wheels

    Attach the Rear Wheels │ 9 Hole on the gear box Rear Bottom View Cut off the plastic ties on the gear boxes. Remove all the parts from the rear axle. 1. Insert the rear axle through the hole in the vehicl body, when inserting it half way, lift the another gear box so that the rear axle can go through it and protrude out.

  • Page 11: Attach The Front Wheels

    Attach the Front Wheels │ 10 Front Bottom View Remove all the parts from the front axle. 1. Slide a Ø12 washer onto the front axle. 2. Slide a front wheel onto the front alxe. 3. Slide a Ø12 washer onto the front axle. 4.

  • Page 12: Attach The Steering Wheel

    Attach the Steering Wheel │ 11 HINT: If the steering wheel of your vehicle equipped with the sound function, please follow the steps 1-4 to add the batteries (Not Included), and refer to the battery information on page 2. 1. With a screwdriver remove the screw on the battery cover located in the center of the steering wheel.
  • Page 13 Attach the Shift Level Assembly & Protecting Board │ 12 1. Lift up the shift lever assembly and remove the four Ø4x12 round head screws with a screwdriver. 2. Push the Shift Lever Assembly forward and locate it over the 4 screws mounting brackets as shown.
  • Page 14 Connect the Power Supply & Attach the Rear Bed Board │ 13 1. Plug the battery connector into the vechiel connector, push firmly. 2. Fit the tabs on the rear bed board into the slots located in the rear vehicle body, and press down until it “clicks”...
  • Page 15 Attach the Seat & Attach the Basket │ 14 1. Fit the seat back to the seat. 2. Insert two Ø4x12 flat head screws from the the bottom side of the seat, through the seat and into the seat back, and tighten. 3.
  • Page 16 Attach the Rear Rollbar │ 15 HINT: The follow steps only for the type without roof. 1. Unscrew the M5X25 machine screws and the Ø5 nuts on the left and right rear rollbar support. 2. Fit the rear rollbar support to the each side of the rear rollbar linkage. 3,4.
  • Page 17 Attach the Front Rollbar │ 16 HINT: The follow steps only for the type without roof. 1. Connect the wire connector into the connector on the vehicle body as shown. 2. Insert and click the front rollbar into the two holes in front body. 3.
  • Page 18 Use Your Ride-on │ 17 1. Power button: Turns the vehicle on and off. 2. Low speed forward/reverse shifter: Changes the direction that vehicle moves from forward to reverse. ● To move the vehicle forward, shift the lever to top position. ●...
  • Page 19 Using the High Speed │ 18 IMPORTANT ● The High Speed Protective cover must be removed by an adult. ● Before remove the HIGH SPEED protective cover: Make sure your child knows how to steer, how to start and stop the product and knows the rules for safe driving.

  • Page 20: Battery Disposal

    Charging │ 19 WARNING! • ONLY an adult is allowed charge and recharge the battery! • This product with Charging Protection: when charging, all functions will be cut off. • The POWER SWITCH must be turned in OFF position when charging. •...

  • Page 21: Troubleshooting Guide

    Troubleshooting Guide │ 20 Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other. If wires are loose around the motor are loose contact your distributor please.
  • Page 22 Maintaining │ 21 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge, cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.
