Summary of Contents for jWIN JX-CD3400
- Page 1 OCATION OF CONTROLS 3 - 8 995AD3TR.P65 2004/2/10, PM 04:01 33-37...
-
Page 2: Location Of Controls
OCATION OF CONTROLS 995AD3TR.P65 2004/2/10, PM 04:01... -
Page 3: Preparation For Use
REPARATION FOR Remove the stereo carefully from the box, retaining the packaging for future use. Read these instructions carefully before use. CONNECTIONS Before switching on your stereo system, ensure that it is connected as follows: SPEAKERS Connect the speakers to the speaker sockets on the back of the music system. Connect the left speaker to the left speaker socket and the right speaker to the right speaker socket. -
Page 4: Handling Compact Discs
ANDLING OMPACT To remove a disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the edges. Fingerprints and dust should be carefully wiped off the disc's recorded surface with a soft cloth. -
Page 5: Sound Controls
OUND ONTROLS AUTOMATIC LEVEL CONTROL (ALC) This set is equipped with built-in Automatic Level Control (ALC) circuitry. This automatically adjusts the optimum recording level, without overloading, when recording. HEADPHONES Headphones should have a 3.5mm diameter stereo plug and an impedance of 8-32 ohms. When headphones are connected, the speakers are automatically disconnected. -
Page 6: Track Skip
TO STOP A CD PART WAY THROUGH Press the STOP Button. Disc play will stop, the Play indicator will go off, and the display will show the total number of tracks and the total playing time of the CD. To temporarily stop disc play (pause mode), press the PLAY/PAUSE Button. Disc play will pause at the current play position and the display will flash. -
Page 7: Programmed Disc Play
REPEAT ALL DISC REPEAT 1 DISC REPEAT 1 To cancel a repeat mode, keep pressing the REPEAT Button until the REPEAT Indicator is extinguished. ROGRAMMED It is not possible to enter programs during disc play. Press the STOP Button first, then follow the instructions below. - Page 8 ECORD RECORD PLAYER UNPACKING - Before playing any records: 45 RPM ADAPTOR TURNTABLE PICK UP ARM 33/45 SPEED SELECTOR HEAD SHELL SPINDLE FINGER LIFT PICK UP ARM REST Unlock the PICK UP ARM from the PICK UP ARM REST. Remove the stylus cover by pulling it gently forward, away from the HEAD SHELL.
-
Page 9: Listening To Tape
ISTENING TO INSERTION AND REMOVAL OF CASSETTES Press the Stop/Eject Button to open the Cassette Door. Slip your cassette tape into the cassette compartment with the exposed section of tape at the bottom and the playback side facing you. Close the Cassette Door securely before starting. When finished, press the Stop/Eject Button to open the Cassette Door, and retrieve your cassette tape. -
Page 10: Recording From Cd
RECORDING FROM CD Set the FUNCTION selector to CD position. Press the Record Button and the Play Button at the same time to start recording. Press the CD Play/Pause Button to start the disc. Press the Stop/Eject Button when finished. TAPE-TO-TAPE RECORDING (DUBBING) ORMAL PEED D U B B I N G... -
Page 11: Remote Control
EMOTE ONTROL Power On/Off Button Stop Button Play/Pause Button CD Skip Forward / Backward Button Program Button Disc Button Mute Button Volume Up/Down Button BATTERY INSTALLATION Insert 2 AAA (R03S) size batteries into the battery compartment of the remote control and replace the cover. - Page 12 ASSETTE Two common causes of trouble experienced when using cassettes are:— Tape jamming - Leading to uneven speed in playback, and Tape tangling - Where the tape wraps itself around vital parts of the mechanism. To reduce the likelihood of these problems occurring, the following precautions should be observed.
-
Page 13: Maintenance And Care
AINTENANCE AND Electronic products of this kind should never be subjected to extreme temperatures or high humidity. For instance, this set should not be placed in bathing areas or around stoves and radiators. If necessary, clean the unit with a piece of cloth dampened with water only. (Be sure the AC Power Cord is disconnected from the Mains).
Need help?
Do you have a question about the JX-CD3400 and is the answer not in the manual?
Questions and answers
What type/number of stylus/needle and where to buy for the JWIN JX-CD3400?
The compatible stylus for the jWIN JX-CD3400 is a 0.7 mil diamond conical tip needle. It supports 16, 33, or 45 RPM records, but is not suitable for 78 RPM. It requires a tracking pressure of 3.0 to 5.0 grams.
This answer is automatically generated
