Summary of Contents for jWIN JS-P905
-
Page 1: Home Theater
Home Theater Amplifier Audio System Amplifier Audio System Amplifier Audio System Amplifier Audio System Amplifier Audio System User Guide 82-136-00061... -
Page 2: Front Panel
Identifying your Amplifier Front Panel 1. Power button 2. Standby indicator 3. Stereo indicator 4. Surround indicator 5. DVD indicator 6. Game indicator 7. TV/VCR indicator Rear Panel 1. Tuner Input connectors 2. AUX Input connectors 3. TV/VCR Input connectors 4. -
Page 3: Remote Control
Remote Control Normal button--Default listening mode. Jazz button--Press to listen to Jazz music sound effect. Classic button--Press to listen to Classic music sound effect. POP button--Press to listen to POP music sound effect. Rock button--Press to listen to Rock music sound effect. -
Page 4: Basic Operation
Using Amplifier Before starting using the amplifier, please get ready all the audio devices that connect to the device first. Refer to the included Amplifier Connection Diagram. Basic Operation 1. Press the POWER button on the main unit, the amplifier goes to STANDBY mode. - Page 5 Using Amplifier Before starting using the amplifier, please get ready all the audio devices that connect to the device first. Refer to the included Amplifier Connection Diagram. Equalizer Setting Press the NORMAL, CLASSIC, JAZZ, ROCK, POP or DANCE buttons to select the tones you like for listening.
-
Page 6: Surround Mode
Using Amplifier Before starting using the amplifier, please get ready all the audio devices that connect to the device first. Refer to the included Amplifier Connection Diagram. Stereo Mode 1. Press the STEREO button in POWER ON mode. 2. The amplifier will playback the input source from the Front Left, Front Right and the Subwoofer speak- ers.
