- Page 1 SCU-DVR3-4 Manual Operations Manual | SCU-DVR3-4 NOVASUB Rackmount 4 channel video recording unit Seascape Subsea BV Revision: 2 - Date: 24-01-2022 De Hoogjens 22 4254 XW Sleeuwijk The Netherlands T. +31-183-307900 info@novasub.com www.novasub.com www.seascapesubsea.com...
-
Page 2: Table Of Contents
HELP & SUPPORT ..................................... 12 WARRANTY ..................................... 13 Warranty Period....................................13 Exclusions and Limitations ................................13 This Limited Warranty is not enforceable if item: ........................... 13 Limitation of Liability ..................................13 www.novasub.com Revision: 2 - Date: 24-01-2022 2 of 13... -
Page 3: Abbreviations / Terminology
Abbreviations / Terminology Ampere hour Comms Communication Diver Depth Gauge Diver Gas Analyzer DVR3 Digital Video Recorder Microphone NovaBus Novasub proprietary data transfer port Push To Talk Volt AC Diver intercom radio www.novasub.com Revision: 2 - Date: 24-01-2022 3 of 13... -
Page 4: Introduction
Novasub rack units. DVR3 The Novasub DVR3 is the 3rd generation video recording software developed by Seascape Subsea. The software is completely redesigned from the ground up to accommodate better ease of use, new features, and better image quality. The software now includes support for touchscreens apart from keyboard and mouse. It also has a new user interface with a taskbar to control all different functions for each diver. -
Page 5: Specifications
Run time 20-45 min. Serves only as UPS backup Charging time 12 hours Size Rack Unit Width 482.6 mm Depth 185 mm Height 43.7 mm Build-In Depth 185 mm Weight 2.8 kg www.novasub.com Revision: 2 - Date: 24-01-2022 5 of 13... -
Page 6: Maintenance
Have your system serviced each 2 years by a Novasub Authorized Service Center. This service will include a general operational check, replacement of the battery, and overall upgrade of firmware. The service requires special tools and training. -
Page 7: General
Audio Out Power External Power Video & Audio connections Monitor Connection See manual: See manual: DVR3 – Video Software DVR3 – Video Software NovaBus www.novasub.com Revision: 2 - Date: 24-01-2022 7 of 13... -
Page 8: Basic Controls
Blinking Red Solid Red Rackmount units The SCU-DVR3-4 is best combined with other Novasub rackmount units. How to connect these units to each other can be seen in the schematic on the next page. www.novasub.com Revision: 2 - Date: 24-01-2022... - Page 9 SCU-DVR3-4 Manual www.novasub.com Revision: 2 - Date: 24-01-2022 9 of 13...
-
Page 10: Dvr3 - Video Software
If your system has a DVR3 it can also be found in the “Help” function. That can be opened with the question mark in the bottom of the screen. This manual can be found on www.Novasub.com. There you can find your product and the manuals will be on that page under the Downloads Folder: Find this manual here www.novasub.com... -
Page 11: Connectors
BNC plug male Function Pin layout centre pin Video + connector housing Video - Data NovaBUS DFK-MSTB 2,5/ 4-G- Type 5,08 Mating type MSTB 2,5/ 4-G-5,08 Function Pin layout RS485+ RS485- www.novasub.com Revision: 2 - Date: 24-01-2022 11 of 13... -
Page 12: Help & Support
Further details about a Warranty Statement can be found at the chapter 9 Warranty For technical support contact your local a Novasub Authorized Service Center or Seascape Subsea BV. Seascape Subsea BV is the manufacturer of all Novasub branded products. -
Page 13: Warranty
2. has been repaired using unauthorized spare parts; modified or repaired by unauthorized Service Center; 3. serial number has been removed, altered or made illegible in any way, as determined at the sole discretion of Novasub; 4. has been exposed to chemicals. Novasub does not warrant that the operation of the product will be uninterrupted or error free, or that the product will work with any hardware or software provided by a third party.
