Specifications
Model
POE150/POE200
Output Voltage
54VDC
PoE Power
30W max
Standard
802.3af/at
Pin Polarity
1/2 (-), 3/6 (+)
Data Rates
10/100/1000Mbps
AC Input Voltage: 100 to 240 VAC
Input Power
AC Input Current: 0.5A 100-240 VAC
Requirements
AC Frequency: 50 to 60 Hz
Dimensions
121mm x 50mm x 36mm
System Indicator: AC Power
Indicators
User Indicator: Channel Power
Connectors
Shielded RJ-45, EIA 568A and 568B
Over current protection
Over load protection
Protection
Over voltage protection
Anti-interference protection
Operating Temperature: 0 to 40℃
Environmental
Operating Humidity:Maximum 85%
Conditions
Storage Temperature:-40 to 60℃
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The
original EU declaration of conformity may be found at
http://www.cudy.com/
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.Copyright©2020 Shenzhen
Cudy Technology Co., Ltd. All rights reserved.
Quick Installation Guide
Model: POE150/POE200
810600073
Advertisement
Table of Contents
Related Manuals for Cudy POE150
Summary of Contents for Cudy POE150
- Page 1 EU declaration of conformity PoE Power 30W max Connectors Shielded RJ-45, EIA 568A and 568B Cudy hereby declares that the device is in compliance with the Quick Installation Guide essential requirements and other relevant provisions of directives Standard 802.3af/at Over current protection 2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The...
- Page 2 Hardware Connection Physical Appearance LED and Interface Explanation AC Socket Green PoE injector got 100-240V power input Power Socket Data/PoE The terminal equipment connected to PoE Injector P+DATA port is powered Powered Device (PD) AC Socket Connect with AC cable DATA P+DATA Ethernet Device...
