jWIN JT-P10 Owner's Manual And Operating Instructions

jWIN JT-P10
TM
FILTER CALLER ID
OWNER'S MANUAL
AND
OEPERATING
INSTRUCTIONS

LOCATION OF CONTROLS

LOCATION OF CONTROLS
1. UP Button
2. DOWN Button
3. DEL/STO Button
4. DIAL Button
5. FILTER Button
6. COPY Button
7. MODE Button
© 1998 jWIN Electronics Corp., U.S.A. jWIN Electronics Corp., U.S.A.

FEATURES:

Call Filter - Allows you to block out unwanted phone
calls; program distinctive ringing for preferred
callers.
One-touch Displayed Number Dialing - Automatically
dials the number displayed by pressing the "dial"
button
3 Language Selection - Information can be
displayed in either English, Spanish, or French
Large 3-line LCD Screen - Shows caller's name and
number
Date/Time Stamp - Records the date and time of
each call
Call Status - displays the total number of calls
received and number of new calls received.
99 Call Memory - stores up to 99 calls received
Call Review - scroll up or down to review all calls
Call Delete - erase individual or all calls from
memory
Real Time Clock
Low Battery Indicator - Indicates when battery
power is low
LED Message Waiting Indicator (for Voice Mail
service) - Indicates a message has been recorded
on your telephone voice mail service through your
telephone company.
9V DC Input Jack
Power - Operates on 1.5V x 4 batteries or DC
Adapter (not included)
This package includes:
1 Caller ID unit
1 Telephone Line Cord

IMPORTANT NOTES:

To operate this unit, you must have caller ID service set-
up with your local telephone company. Some functions
such as "caller name indication" and "message waiting
indication" will only operate if such services are included
in the user's caller I.D. program with the local telephone
company.

SET-UP

In order to operate this caller ID unit, you must set up
the unit and preset information as follows:
1. Install 4 X 1.5V batteries or insert a 9V DC adapter
(not included) into the DC jack located at the back of the
unit and plug into a standard electrical outlet
(110/120V).
2. Using the telephone line cord included with the Caller
ID, connect one end into your telephone's line jack and
the other end into the "phone" jack at the back of the
Caller ID.
3. Connect your telephone line into the "line" jack
located at the back of the Caller ID. (To connect to an
Answering Machine: connect the answering machine
between your phone and the Caller ID as shown.)
{To Connect to an answering Machine}
4. Select Language:
ENG ESP FRA
a) Press [UP], [DOWN], and [DEL/STO] at the
same time and hold for 10 seconds to initialize
the pre-setting program.
then "ENG, ESP. FRA" should appear on the
screen.
b) Press [UP] or {DOWN] to select the desired
language mode.
c) Press the [DEL/STO] button once to set the
selected language.
5. Enter your area code (Area Code Preset):
000
ENTER AREA CODE
a) Press [UP] or [DOWN] to select the first digit of
the area code.
b) Press the [DEL/STO] button once to set the
first digit.
c) Repeat steps a) and b) to select the remaining
digits.
6. Enter time and date:
00:00 PM 1/01
ENTER TIME DATE
a) Press [UP] or [DOWN] to select the correct hour
"Enter Language"
