Summary of Contents for Aetina MSB-DP24H
- Page 1 User Manual Multi-Display Splitter Box Aetina MSB-DP24H/MSB-DP28H/MSB-DP39H Version Date Description Authors 2020/12/30 Initial Release. Emily Chou...
-
Page 2: Table Of Contents
3. Hardware and Software Installation ..........................7 3.1 How to install the M3 Box ............................7 3.2 Display setting with M3 Box ..........................10 3.2.1 MSB-DP24H Setting step ..........................10 3.2.2 MSB-DP28H Setting step ..........................11 3.2.3 MSB-DP39H Setting step ..........................12 3.3 Install MView Power (Option) .......................... - Page 3 6.Certificates ................................... 21 6.1 Certifications ................................. 21 7. Appendix ..................................22 7.1 Ordering Information ............................22...
-
Page 4: General Overview
1. General Overview Aetina Multi Monitors Marvel (M3 Box) series is the simple, flexible and powerful multi- display splitter box to support a spectacular Ultra HD video wall with up to 4/8/9/12/16 displays. With plug & play design, M3 Box does not need to install any driver, providing 1:1 pixel to pixel meticulous output quality without any pixel loss. -
Page 5: I/O Interface
• Maximum Output HDMI: 1920 x 1200 • Maximum resolution over in one box: 5760 x 3600 (3 x 3 mode) 1.1.4 Cooling System • Passive for MSB-DP24H • Active Fan for MSB-DP28H and MSB-DP39H 1.1.5 Operating System Support • Windows® 10 64-bit Note: MSB-DP28H only support NVIDIA GPU Card. -
Page 6: Configuration
0 to +45 °C 0 to +45 °C 0 to +45 °C Temperature Storage Temperature -20°C – +65°C -20°C – +65°C -20°C – +65°C Operating Humidity 5~95%, 5~95%, 5~95%, No Condensation. No Condensation. No Condensation. Table 1.1 Box configuration Figure 1.1 MSB-DP24H/MSB-DP28H/MSB-DP39H... -
Page 7: Getting Started
2. Getting Started Before you begin installing your new M3 Box, please make sure your graphics card already installed the driver and you have the proper system requirements and have completed the required pre-installation tasks as outlined in this chapter. 2.1 System Recommended for graphics card •... -
Page 8: Hardware And Software Installation
3. Hardware and Software Installation 3.1 How to install the M3 Please follow the instructions from Step 1 to Step 4. 1. Connector M3 Power Supply. 2. Connector DP Cable from Graphic card to M3 DP Port 3. And make sure the connection of HDMI Cable to M3 and monitor 4. - Page 10 Figure 3.1 M3 Box displays configuration...
-
Page 11: Display Setting With M3 Box
• Turn on NV Control Panel • Enable Surround function Choose 2x1 or 1x2 • Plus 2 of MSB-DP24H which can Get 2x2 or 1x4 mode option • Press Right button of mouse to call NVDIA control panel, choose Surround •... -
Page 12: Msb-Dp28H Setting Step
3.2.2 MSB-DP28H Setting step • Turn on NV Control Panel • Enable Surround function Choose 2x1 or 1x2 • Plus 2 of MSB-DP28H which can Get 2x4 or 1x8 mode option • Press Right button of mouse to call NVDIA control panel, choose Surround •... -
Page 13: Msb-Dp39H Setting Step
3.2.3 MSB-DP39H Setting step • Turn on NV Control Panel • Enable Surround function 3x1 • Press Right button of mouse to call NVDIA control panel, choose Surround • Follow the Video Wall Layout and sort by correct position by each display, enable the Surround •... -
Page 14: Install Mview Power (Option)
Support the editable player, scheduling, local control, and remote monitoring. It is built inside the M3 Player and also supports for Aetina M3 Box. With MView Power, integrators can define display format, as well as efficiently execute advanced pictures and videos. - Page 15 Noted：Keep current version, don’t update to latest of Version. Select Please remember CACHE -> Click on ENABLED (DYNAMIC)
- Page 16 After the finished All install, press the right button on MView Power shortcut -> Content -> Compatibility -> Change all user settings -> Execute this program as the system administrator. Operation screen after installation.
-
Page 17: Functional Description
4. Functional Description 4.1 Board Architecture The M3 series form factor. Figure 4.1 MSB-DP24H Block diagram Figure 4.2 MSB-DP28H(Lift) & MSB-DP39H(Right) Block diagram... -
Page 18: I/O Resources
4.2 I/O Resources The MSB-DP24H provides four digital output channels, MSB-DP28H provides eight digital output channels and MSB-DP39H provides nine digital output channels. All the digital output channels can be active at the same time. 4.2.1 EDID caching The M3 series prevents display default configuration reset while monitor malfunction or disconnection, optimizes displaying quality and stability. -
Page 19: Mechanical Specifications
5. Mechanical Specifications Dimensions The Actual dimensions of the Box are shown below. Figure 5.1: Dimensions of MSB-DP24H (107 x 95 x 35 mm) - Page 20 Figure 5.2: Dimensions of MSB-DP28H (173 x 105 x 35 mm)
- Page 21 Figure 5.3: Dimensions of MSB-DP39H (173 x 105 x 35 mm)
-
Page 22: Compatibility Test
Compatibility test Table 5.1 is the GPU lists for the M3 Box test. Brand Items MSB-DP24H MSB-DP28H MSB-DP39H FirePROW4100 FirePROWX9100 RX5600 RX5700 RX6800 NVIDIA GTX980 NVIDIA GTX1080 NVIDIA GTX2080 NVIDIA GTX3090 NVIDIA Quadro P4000 NVIDIA Quadro P6000 INTEL HD630 Table 5.1 Compatibility test table of with GPU 6.Certificates... - Page 23 7.1 Ordering Information Table 7.1 Models available Model Number Description MSB-DP24H 4-displays, Multi-display Splitter Box, Input DP x 2 + Output HDMI x 4, 0°C to +45°C Accessories: DP to DP cable x 2 + Adapter 5V 3A DC x 1 MSB-DP28H 8-displays, Multi-display Splitter Box, Input DP x 2 + Output HDMI x 8, 0°C to +45°C...
- Page 24 BIOS flashes, firmware upgrades, or the like. Aetina assumes no obligation to update or otherwise correct or revise this information. However, Aetina reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Aetina to notify any person of such revisions or changes.
