High output ir emitter, for transmitting infrared commands to audio/video components (4 pages)
Summary of Contents for Jobsite IR-E2
Page 1
DATA SHEET For Transmitting Infrared Commands to Audio/Video Components IR-E2 DUAL IR EMITTER...
Page 2
• IR system: Works with practically all brands of IR remote controls • IR transmitting: 4’ (line of sight) • Emitters mount directly to the IR window of a component SPECIFICATIONS • Works with practically all brands of IR remote controls •...
Page 3
PREPARING FOR INSTALLATION: The IR-E2 is typically mounted to the infrared remote receiver windows of two audio/video components, using the attached self-adhesive tape. The emitters direct their infrared output toward the components, not out into the room. If the component has a tray or door that opens, you may have to route the wire from the top or the bottom of the component.
