Summary of Contents for EV-OPTIMIZER High Current
- Page 1 Installation manual High Current 02/2021 V1.0...
- Page 2 EV-Optimizer This document contains information only and is a non-binding offer by EV-Optimizer. EV-Optimizer has prepared the content of this document to the best use of its knowledge. We cannot provide any implicit or explicit guarantee for the completeness, accuracy, reliability, or suitability of the content, and for the products and services that are mentioned here for a particular application.
-
Page 3: Table Of Contents
Manual Content High Current Installation High Current G4-connection Main fuse or circuit breaker Troubleshooting LED indicator Correct cable specification Installation manual High Current... -
Page 4: High Current
High Current The High Current is suitable for a maximum of 20 supply stations and can only be installed with current transformers which are always included. The High Current goes up to a maximum of 1000A. Installation High Current For proper installation of the High Current it is important that you follow the next steps carefully. - Page 5 2 and plug the connector to the corresponding RS485- port in the High Current. See image 1 (A) on page 4. Make sure that the 2 wires correspond with the connected wires of the modem in the supply station.
-
Page 6: G4-Connection
G4-connection The High Current is connected to the EV-Box G4 series with other connectors. This one is made for 2 instead of 4. The wire pair is connected in the same way as the connector with 4 pins. G4 update - BusinessLine 1.2... -
Page 7: Main Fuse Or Circuit Breaker
First, determine whether the main fuse contains a fuse or a circuit breaker. Now that the High Current has been installed, you can verify if the High Current is placed in the right way. If it concerns a fuse, there should be 2 lights turned on. -
Page 8: Troubleshooting Led Indicator
The flashing speed is equal to the power consumption. If the power usage goes up, the LED indicator will flash faster. Continuing green: The EV-Optimizer is still in programming mode Put the rotary switch (in the EV-Optimizer) from 5 to 6 inside the EV-Optimizer. Correct cable specifications SF UTP Cable...
