Dru Max Vent Installation Manual

Advertisement

Available languages

Available languages

Quick Links

INSTALLATIEHANDLEIDING NL/BE
INSTALLATIONSANLEITUNG DE/AT/BE/LU/CH
MANUEL D'INSTALLATION FR/BE/LU/CH
INSTALLATION MANUAL GB/IE
MAX VENT
Bewaar dit document zorgvuldig
Bewahren Sie dieses Dokument sorgfältig auf
Conservez soigneusement cette notice
Please retain this document carefully
DRU VERWARMING B.V.
HOLLAND
957.641.01

Advertisement

loading
Need help?

Need help?

Do you have a question about the Max Vent and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dru Max Vent

  • Page 1 INSTALLATIEHANDLEIDING NL/BE INSTALLATIONSANLEITUNG DE/AT/BE/LU/CH MANUEL D’INSTALLATION FR/BE/LU/CH INSTALLATION MANUAL GB/IE MAX VENT Bewaar dit document zorgvuldig Bewahren Sie dieses Dokument sorgfältig auf Conservez soigneusement cette notice Please retain this document carefully DRU VERWARMING B.V. HOLLAND 957.641.01...
  • Page 3 De luchtstroom komt namelijk pas op • Voer de verpakking af via de reguliere weg. gang als het toestel voldoende warm is. Als de schakelaar op “I” of “II” staat, treedt het Max vent 3. Installatie systeem automatisch in werking bij het inschakelen van uw toestel.
  • Page 4 Punkte zu beachten: 2. Funktion • Überprüfen Sie das System auf Transportschäden. • Wenden Sie sich bei Bedarf an den DRU Service. • Entsorgen Sie die Verpackung auf dem üblichen Weg. Im Schaltkasten befi ndet sich der Schalter für die Bedienung Ihres Max-Vent-Systems;...
  • Page 5: Manuel D'installation

    • Connectez le câble électrique sur une alimentation 1. Introduction 230 V proche de l’appareil (voir la Fig. 3). Le système Max vent est installé sur un appareil de chauf- MODE D’EMPLOI fage d’ambiance au gaz Global 70 / Global 70 XT pour 1.
  • Page 6 The installation manual will give you the information you • Place the air grate at the front. need to install the Max vent system in such a way that it • Mount the control panel in the top of the control box will operate properly and safely.
  • Page 7: Appendix 1: Afbeeldingen/Abbildungen/Figures

    APPENDIX 1: AFBEELDINGEN/ABBILDUNGEN/FIGURES 1a Global 70 BF 1b Global 70XT BF Max Vent...
  • Page 8 APPENDIX 2: AFBEELDINGEN/ABBILDUNGEN/FIGURES Yellow/Green cable Yellow/Green cable Grey cable Main Switch Brown cable Black cable Fuse 250 mA Blue cable Brown cable Silicon cable (1mm2) Clicon NO 36˚C Brown cable Silicon cable (1mm2) 3. ELECTRICAL SCHEME MAX VENT...
