THANKS FOR CHOSEN KOHLER
Food waste disposers provide an environmentally
responsible alternative to transporting food waste to
landfills, and they can help reduce greenhouse gas
emissions. at capable wastewater treatment stations, food
waste can be converted to biosolids and used as fertilizer.
The gracious living kitchen lifestyle by Kohler is a clean,
convenient and environmentally responsible method of
ridding your kitchen food wastes. At the touch of switch,
food waste is dealt with hygienically and instantly - rather
that leaving it in a bin to encourage smells, bacteria and
insects, in turn makes the domestic cooking and dining
area to be more pleasant environment for family
gatherings.
KOHLER innovative kitchen appliance,
Kohler made the lead-edge finest food waste disposer is
a very reliable kitchen appliance. It is fitted easily and
discreetly under your sink, the unique design of the
product allows you to easily and freely clean up organic
food waste produced in the kitchen before and after
meals. The disposal is very easy to use. You just need to
turn on the water, turn on the disposer and then place the
food waste inside. then the disposer will effortlessly grind
food waste into tiny particles that are automatically
flushed away down the kitchen drain to enter the waste
treatment system.
KOHLER CHINA INVESTMENT CO., LTD NO. 158, JIANG CHANG SAN ROAD,
科勒 (中国) 投资有限公司 上海市静安区江场三路 158 号 邮编:200436
1460955-T01-A
JING'AN DISTRICT, SHANGHAI, PRC POST CODE: 200436
FOOD WASTE DISPOSER
废弃食物处理器(厨余处理机)
INSTALLATION GUIDE &
USE INSTRUCTIONS
K-28886T-PW-NA/K-28887T-PW-NA/K-28888T-PW-NA
K-P28886T-PW-NA/K-P28887T-PW-NA
感谢购买科勒产品
家用废弃食物处理器作为常规将废弃食物垃圾运送到垃
圾填埋场进行处理之外提供了一种更环保的替代方案。
它有助于减少温室气体排放量。在有能力的废弃排水处
理站,废弃食物残渣垃圾可以转化为生物固体,并作为
肥料。
科勒提倡的厨房优雅生活方式是更清洁,更便利以及更
环保地处理厨房废弃食物。只需按下开关,厨余垃圾便
会得到快速而卫生地处理,而不会留在垃圾桶中发出臭
味,滋生细菌,招引蚊虫,从而让您的厨房以及餐厅可
以成为更加欢快的烹饪区域和聚会场所。
科勒创新厨房电器,
科勒为您制造的更精细的废弃食物处理器是一台十分可靠
的厨电产品。可以方便、整洁地安装在厨盆之下,该产
品独特的设计使您能够轻松自如地清除饭前、饭后厨房中
所产生的有机食物垃圾。处理器使用十分简便,您只需打
开水龙头,启动处理器,再倒入食物垃圾。处理器就会将
食物垃圾轻松地粉碎成小颗粒,通过厨房下水道自动冲
走,进入污水处理系统。不会产生任何问题。
© Copyright Kohler China Investment Co., Ltd. 2020
© 版权为科勒(中国)投资有限公司所有 2020
安装说明书

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K-28886T-PW-NA and is the answer not in the manual?

Questions and answers

Summary of Contents for Kohler K-28886T-PW-NA

  • Page 1 KOHLER CHINA INVESTMENT CO., LTD NO. 158, JIANG CHANG SAN ROAD, JING’AN DISTRICT, SHANGHAI, PRC POST CODE: 200436 科勒 (中国) 投资有限公司 上海市静安区江场三路 158 号 邮编:200436 1460955-T01-A ©...
  • Page 2: Table Of Contents

    目录 TABLE OF CONTENTS 1. 安全指南 ..............1. SAFETY GUIDE ............2. 处理器的图示说明 ............2. ILLUSTRATION OF DISPOSAL UNIT ......3. 组件的安装 ..............3. INSTALLATION OF MOUNTING ........4. 检查电源 ............... 4. CHECK THE POWER SUPPLY ........5. 洗碗机的连接 ..............5.
  • Page 3: Safety Guide

    Note: Please be sure to read the safety instructions concerning fire, electric shock or personal injury before installing the disposal! 科勒热线电话:800 820 2628/400 820 2628 KOHLER Hot line:800 820 2628/400 820 2628 声明:在安装和使用本废弃食物处理器前,请务必阅读本手册, Declaration: Before installing and using the food waste 并遵循手册中的建议,以避免操作中可能出现的故障,如果您有...
  • Page 4: Illustration Of Disposal Unit

    在使用电器产品的时候,必须注意下列事项: Be sure to note the following items when using the electrical appliance: 安装使用本产品时,需要在安装台面下距离本产品0.5米处预 • When installing the product, you must reserve a wall outlet • 留有与本产品匹配的墙面插座。(详见P6) that is suitable for the product, 0.5m away from the product and under the installation platform if not using a matching air switch.
  • Page 5: Installation Of Mounting

    3. 组件的安装 3. INSTALLATION OF MOUNTING 产品组成结构图: Diagram of product structure: Parts List/零件清单 A. Stopper /盖子 Sink A1. Removable Spash Guard /防溅罩子 水槽 B. Sink Flange /不锈钢法兰 C*. Rubber Washer /法兰橡胶平垫 C1. Fiber Gasket /纤维垫圈 D. Backup Flange /支撑环 E. Screws (x3) /螺丝 F.
  • Page 6 B. 在卡箍一端下方用平头螺丝刀将其从水槽法兰上拆下。(参 B. Use a flat blade screwdriver under one end of the snap ring to 看图3B)。 remove it from the sink flange. (see Figure 3B). 下方 C. 将其他零件从水槽法兰上拆开,再取下纤维垫圈 C. Remove the mounting ring, backup flange and fiber gasket. (参看图3C)。 (see Figure 3C).
  • Page 7 G. 从水槽下面装上纤维垫圈、支撑环和装配环到水槽法兰,用螺 G. Re-assemble the Fiber Gasket, Backup Flange and Mount- 丝固定。注意:螺丝无需装紧。(参看图3G) ing Ring and Screws. DO NOT overtighten. (see Figure 3G). 下方 H. 将卡箍装入法兰的卡槽内。(参看图3H) H. Pull the Snap Ring open and press firmly into the groove on the flange. (see Figure 3H). 下方...
  • Page 8: Check The Power Supply

    4. 检查和准备电源 4. CHECK THE POWER SUPPLY 注意: 安装使用废弃食物处理器,需要您在厨房改造中 Note: To install the food waste disposal, you must 预留电源插座及开关。在安装前,请不要将电源连接到处 reserve a power outlet and switch when remodeling the 理器上。请将电源关闭或拿掉保险丝。 kitchen. Before installation, please do not connect the power supply to the disposal. Please shut off the power or remove the fuse.
  • Page 9: Fixation Of Drain Elbow

    6. 排水弯管的固定 6. FIXATION OF DRAIN ELBOW A. 将排水弯管接到处理器上(见图6A)拧紧螺丝。确认所有的 A. Connect the drain elbow to the disposal (see Figure 6A) and 管件已接连牢固。 tighten the screw. Confirm all the pipe fittings are connected firmly. Lower Mounting Ring Cushion Mount 装配环 橡胶件 下方...
  • Page 10 第三步: Step III: 将处理器的排水弯管与排水管进行连接。 Connect the drain elbow of the disposer with the sewer pipe. 典型安装示例: Examples of Installation: Offset Sink Single Sink (双槽安装示意图) (单槽安装示意图) Wireless Switch Wireless Switch 无线开关 无线开关 Adaptor Socket Adaptor Socket 模块插座 模块插座 接220 V市电 接220 V市电 Drain line Drain line Power cord...
  • Page 11: Wireless Switch Paring

    8.2 开关的使用 8.2 Use of switch 完成上述安装过程后,整个废弃食物处理器的工作系统已经可以 After the installation process above is finished, the whole food 正常使用,按下无线开关按钮,处理器启动;再按下无线开关按 waste disposal system can be used normally. Please press the 钮,处理器关闭。 switch to turn on/off the disposal. 备注:插座按键也具备开关功能,按压按键可控制处理器的开启 Note: the button of adaptor-socket also has switch function. 与关闭。...
  • Page 12: Trouble Shooting

    提示: Reminder: 为了排水系统畅通,请您在使用洗碗机之前确认处理器内无 • In order to maintain a smooth drainage system, please • 食物垃圾。 confirm that there is no food waste in the disposal before using the dishwasher. 在不使用处理器的时候,请将盖子组件盖好,以防止厨具或 • When the disposal is not in use, please cover the sink plug •...
  • Page 13: Cleanup And Maintenance

    如果“热保护器复位按钮”未弹出,请检查处理器的连接电源线, If the "Thermal protection reset button" is not popped up, please 或电源开关、保险闸门、电源断合器等。如果电源线的连线和电器 check the connecting power line or power switch, emergency 部分都完好,有可能是处理器内部的问题,需要与分销商联系修理 capacity gate or power breaker of the disposal. If the 或更换。 connection of the power line and the electric appliance are both normal, it may be a problem inside the disposal.
  • Page 14: Technical Specifications

    13. 技术参数 13. TECHNICAL SPECIFICATIONS Product Model 28886T-PW-NA 28887T-PW-NA 28888T-PW-NA 产品型号 P28886T-PW-NA P28887T-PW-NA Power Supply 电源 220 V /50 Hz 220 V /50 Hz 220 V /50 Hz Motor Power/电机功率 500 W 660 W 770 W RPM/转速 1800 rpm 1900 rpm 2000 rpm Unit Dimension/尺寸...
  • Page 15: Circuit Schematic Diagram

    14. 电路原理图 CIRCUIT SCHEMATIC DIAGRAM 黄 黑 蓝 黑 红 转换器 过载过温保护器 整流桥堆 直流电机 白 白 15. 产品中有害物质含量的说明 HAZARDOUS SUBSTANCE DESCRIPTION Hazardous Substance 有毒有害物质或元素 Part Name 部件名称 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 ○ ○...
  • Page 16 Manufactured by Kohler Co., 1460955-T01 LKK3153...
