Ansorg Simpless SNM 06SNM Series Installation Manual

DON'T START OR END WITH LUMINAIRE UNIT !
Normal rail
LED unit

Mounting Luminaire unit

Slide knob to select phase
L1/L2/L3
L3
L1
62BD0757-A
07.07.2021
Installation
Manual
EAR 80418
500
229
283
Normal rail
Luminaire unit or
blank cover
Make sure male & female
connectors in right position then fix
the luminaire to trunking rail
Ansorg GmbH • Pilgerstraße 11 • D-45473 Mülheim an der Ruhr • FON +49 (0)208/4846-0 • FAX +49 (0)208/4846-1200 • info@ansorg.com • www.ansorg.com
Luminaire unit
Simpless SNM
06SNM.....-...
DE Hierzu gehören die Montagehinweise für die Simpless SHL (62BD0753).
EN This also includes the Installation Manual for the Simpless SHL (62BD0753).
LED
220-240 V
1er
50/60 Hz
1.2 kg
Feed out rail
LED unit
IP20
2er
2.0 kg
500
320
70
360°
±10°
1 /2
