GoVideo CCTV28 User Manual

I n t r o d u c t i o n
Test-CCTV28 was developed for the On-Site installation and maintenance of video monitoring
system. It can be used for displaying video, controlling PTZ, generating images, capturing data
of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple
for the CCTV technician to install and maintain CCTV system, improving work efficiency and get
the labor cost down.
2 . 1 F e a t u r e s
2.8" TFT-LCD, 960（H）× 240（V）resolution.
PTZ control. Pan/tilts the P/T unit, zooms in/out the lens, adjusts the focus, aperture and
sets and calls the preset position
Video displaying. Automatically adapts and displays the video format of NTSC/PAL.
LCD Brightness/Contrast/Color Saturation are adjustable.
Video Level testing, video signals measured in IRE or mV
Video Generating, The PAL/NTSC multi-system Colour Bar generator (seven-system
switchable, transmit/receive
Data analysis. Captures and
out the problem.
Cable testing. It is powerful in testing LAN cable, measuring the connecting status ，
displaying the sequence of connection and the NO. of the LAN cable.
Multi-interface and Multi-baudrate. Support RS232 ,RS485 and RS422 interface; baud rate
ranging from 150, 600 to 19200bps.
Multi-protocol. Supports more than twenty PTZ protocols. For example, PELCO-P,
PELCO-D, SAMSUNG etc.
PTZ address scanning, search up the ID of PTZ camera.
Lithium Ion Polymer Battery (3.7V DC2000mAh). The device employs advanced power
control and protection circuit. The device is high power-efficient, energy saving and
environmental protection. It can last 11 hours for normal use after charging for 4 hours.
www.allthings.com.au
Pages from GoVideo
seven-system colourful imagines)
analyzes RS485 controlling data to help the technician to find
Test-CCTV28 User Manual
