20 Ton Air / Hydraulic
Bottle Jack – Super Heavy Duty
Operating Instructions
WARNING:
Important: read these instructions and all warnings prior to
using this equipment. Understand all operating procedures,
safety warnings and maintenance requirements. Failure to
do so could cause an accident resulting in serious or fatal
injury and/or personal property damage.
www.strongarminc.com
www.strongarminc.com
PROD NO. 030158
MOD NO. 385SHD
M13-SA030158
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Strongarm 385SHD
Summary of Contents for Strongarm 385SHD
- Page 1 PROD NO. 030158 MOD NO. 385SHD 20 Ton Air / Hydraulic Bottle Jack – Super Heavy Duty Operating Instructions WARNING: Important: read these instructions and all warnings prior to using this equipment. Understand all operating procedures, safety warnings and maintenance requirements. Failure to do so could cause an accident resulting in serious or fatal injury and/or personal property damage.
- Page 2 It is recommended that this equipment be inspected annually by a qualified repair facility. Defective parts, decals, safety labels or signs should be replaced with Strongarm specified parts. WARNING! •...
- Page 3 OPERATING INSTRuCTIONS 1. Operating Instructions WARNING! Ensure that you read, understand and apply the safety instructions and warnings before use. WARNING! Ensure that you have familiarized yourself thoroughly with the product and the hazards associated with its improper use. 1.1 Before first use of this product, pour a teaspoon of good quality air tool lubricant into the hose quick coupler-male, then connect it to air source and turn on the air valve and work for 3 seconds to evenly distribute lubricant.
-
Page 4: Troubleshooting
MAINTENANCE 2. Maintenance 2.1 Clean the outside of the jack with dry, clean and soft cloth and periodically lubricate the joints, extension screw and all moving parts with a light oil as needed. DO NOT APPLY LUBRICANT TO SADDLE. 2.2 When not in use, store the jack in a dry location with ram and extension screw fully lowered. 2.3 Purge the hydraulic system to eliminate any air in the system if jack efficiency drops or jack doesn’t work: 2.3.1 If manual operation performs poorly, use the slotted end of the handle to turn the... - Page 5 20 Ton Air / Hydraulic Bottle Jack PROD NO. 030158 MOD NO. 385SHD Super Heavy Duty NO. PART NUMBER DESCRIPTION PCN-385SHD-01 Base PCN-385SHD-02 Ball PCN-385SHD-03 Seal PCN-385SHD-04 Release Valve PCN-385SHD-05 Ball Cup PCN-385SHD-06 Spring PCN-385SHD-07 Spring PCN-385SHD-08 Screw PCN-385SHD-09 Nylon Ring...
