CAPACITIES AND RECOMMENDED FLUIDS

SPECIFICATIONS

ENGINE

Description

Cooling System

(1)

Engine Coolant (3.6L

Engine)

(2)

Engine Coolant (3.0L

Diesel Engine)

Engine Oil with Filter

Engine Oil (3.6L Engine)

Engine Oil Filter (3.6L

Engine)

Engine Oil (3.0L Diesel

Engine)

Engine Oil Filter (3.0L

Diesel Engine)

Fuel (approximate)

Fuel Selection (3.6L

Engine)

2016 GENERAL INFORMATION

Vehicle Quick Reference - Ram ProMaster

Type

MOPARÂ® Antifreeze/Coolant

10 Year/150, 000 Mile Formula

OAT (Organic Additive

Technology) meeting the

requirements of Material

Standard MS-90032.

MOPARÂ® Antifreeze/Coolant

10 Year/150, 000 Mile Formula

OAT (Organic Additive

Technology)

We recommend you use API

Certified SAE 5W-20 Engine

Oil, meeting the requirements

of Material Standard MS-6395

such as MOPAR, Pennzoil, and

Shell Helix. Refer to your

engine oil filler cap for correct

SAE grade.

MOPARÂ® Engine Oil Filter

Kit

Only use ACEA C3 5W-30

Synthetic Low Ash engine oil

meeting Material Standard MS-

11106 or Pennzoil Ultra Euro L

full synthetic 5W-30 motor oil.

MOPARÂ® Engine Oil Filter

Kit

87 Octane, 0-15% Ethanol.

Capacities

U.S.

10.5 Quarts

12.7 Quarts

6 Quarts

N/A

9.5 Quarts

N/A

24 Gallons

Metric

10 Liters

12 Liters

5.6 Liters

N/A

9.0 Liters

N/A

90 Liters

Table of Contents

Need help?

Do you have a question about the Ram ProMaster 2016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitchell Ram ProMaster 2016

Page 1 Back To Article 2016 GENERAL INFORMATION Vehicle Quick Reference - Ram ProMaster CAPACITIES AND RECOMMENDED FLUIDS SPECIFICATIONS SPECIFICATIONS ENGINE Capacities Description Type U.S. Metric Cooling System MOPARÂ® Antifreeze/Coolant 10 Year/150, 000 Mile Formula OAT (Organic Additive Engine Coolant (3.6L 10.5 Quarts 10 Liters Technology) meeting the Engine)
Page 2 Capacities Description Type U.S. Metric Use good quality diesel fuel from a reputable supplier in your vehicle. Federal law requires that you must fuel this vehicle with Ultra Low Sulfur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur Highway Diesel fuel (500 ppm Sulfur maximum) to avoid damage to the emissions control system.
Page 3: Spark Plugs
Capacities Description Type U.S. Metric MOPAR Diesel Exhaust Fluid (API Certified) (DEF) or equivalent that has been API 3.0L Diesel Engine Certified to the ISO 22241 5 Gallons 18.9 Liters standard. Use of fluids not API Certified to ISO 22241 may result in system damage.
Page 4: Specifications
Capacities Description Type U.S. Metric CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. CHASSIS Capacities Description Type U.S. Metric Chassis Systems We recommend you use Brake Master Cylinder MOPAR DOT 4.
Page 5: Power Distribution Center
Fig. 1: Power Distribution Center Courtesy of CHRYSLER GROUP, LLC POWER DISTRIBUTION CENTER Cavity Maxi Fuse Mini Fuse Description Electronic Stability Control (ESC) 40 Amp Orange Pump 20 Amp Yellow (3.6 Starter Relay 3.6L (3.6 Gasoline Gasoline Engine) Engine) 50 Amp Red (3.0 Glow Plug Unit (3.0 Diesel Engine) Diesel Engine) Secondary Power Distribution Center...
Page 6 Cavity Maxi Fuse Mini Fuse Description 15 Amp Blue Horn Fuel Pressure Regulator (MPROP)-DRV 15 Amp Blue (3.0 Diesel Engine) - If Equipped 20 Amp Yellow Power Outlet 7.5 Amp Brown USB Charger KL15 Shifter Transmission Module 7.5 Amp Brown (STM) (3.6), KL15 Starter Relay Coil (3.6 Gasoline Engine) KL15 Manual Transmission Automated...
Page 7 Fig. 2: Additional Fuse Box Courtesy of CHRYSLER GROUP, LLC The additional fuse box is located inside the front PDC Box. POWER DISTRIBUTION CENTER ADDITIONAL FUSES Cavity Mini Fuse Description 20 Amp Yellow Vacuum Pump (3.6 Gasoline Engine) - If Equipped Transmission Power RELE (3.6 Gasoline Engine) - 30 Amp Green If Equipped...
Page 8: Interior Fuses
Fig. 3: Interior Fuse Panel Courtesy of CHRYSLER GROUP, LLC The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver's side under the instrument panel. INTERIOR FUSES Cavity Mini Fuse Description 10 Amp Red Right Low Beam 10 Amp Red Left Low Beam...
Page 9: Right Central Pillar Fuses
Fig. 4: Right Central Pillar Fuse Panel Courtesy of CHRYSLER GROUP, LLC The right central pillar fuse panel is located on the interior side at the base of the passenger side B pillar. RIGHT CENTRAL PILLAR FUSES Cavity Mini Fuse Description 7.5 Amp Brown Seat Heater...
Page 10 Fig. 5: Hoisting And Jacking Points Courtesy of CHRYSLER GROUP, LLC 1 - FRAME CONTACT LIFT (SINGLE POST) 1 - CHASSIS LIFT (NON-AXLE DUAL POST) 1 - OUTBOARD LIFT (DUAL POST) 1 - FLOOR JACK Refer to Owner's Manual provided with vehicle for proper emergency jacking procedures. WARNING: The hoisting and jack lifting points provided are for a complete vehicle.
Page 11: Jump Starting
When properly positioned, a floor jack can be used to lift the vehicle and support the raised vehicle with jack stands. A floor jack or any lifting device, must never be used on any part of the underbody other then the described areas. CAUTION: Do not attempt to lift a vehicle with a floor jack positioned under: Aluminum differential.
Page 12 Fig. 6: Identifying Red Jumper Cable Clamp, Black Jumper Cable Clamp & Protective Cover Courtesy of CHRYSLER GROUP, LLC 1. On the disabled vehicle, remove the battery compartment lid from the passenger compartment between the seats and inspect the battery. Inspect the battery cable terminal clamps for damage.
Page 13 3. When using another vehicle as a booster source, park the booster vehicle within cable reach. Turn off all accessories, set the parking brake, place the automatic transmission in PARK or the manual transmission in NEUTRAL and turn the ignition OFF. 4.
Page 14 Fig. 7: Electrical Harness/Components Topology (Modules - Inline Connectors - Ground Locations) Courtesy of CHRYSLER GROUP, LLC INLINE CONNECTORS AND GROUND LOCATIONS For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Page 15: Maintenance Schedules
Fig. 8: Electrical Harness/Components Topology Inline Connectors & Ground Locations) Courtesy of CHRYSLER GROUP, LLC MAINTENANCE SCHEDULES DESCRIPTION MAINTENANCE SCHEDULES - NAFTA Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Based on engine operation conditions, the oil change indicator message will illuminate in the instrument cluster.
Page 16: Maintenance Chart
Fully depress the accelerator pedal slowly three times within 10 seconds. Turn the ignition switch to the "LOCK" position. NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure.
Page 17 Mileage or time 100, 110, 120, 130, 140, 150, passed (whichever comes first) Or Years: 2 Or Kilometers: 32, 112, 128, 144, 160, 176, 192, 208, 224, 240, Replace engine air Â Â Â Â Â Â Â Â Â filter.
Page 18: Maintenance Chart - Diesel Fuel Up To B5 Biodiesel
change indicator system did not reset. If necessary repeat this procedure. Once a Month Or Before a Long Trip Check engine oil level Check windshield washer fluid level Check tire inflation pressures and look for unusual wear or damage. Check the fluid levels of the coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
Page 19 Mileage or time 100, 110, 120, 130, 140, 150, passed (whichever comes first) Or Years: 1 Or Kilometers: 16, 112, 128, 144, 160, 176, 192, 208, 224, 240, Replace fuel filter and drain water Â Â Â Â Â Â Â...
Page 20 Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Based on engine operation conditions, the oil change indicator message will illuminate in the instrument cluster. This means that service is required for your vehicle.
Page 21 Mileage or time Mileage or time 100, 100, 110, 110, 120, 120, 130, 130, 140, 140, 150, 150, passed (whichever passed (whichever comes first) comes first) Or Years: 1 Or Years: 1 Or Kilometers: 16, Or Kilometers: 16, 112, 112, 128, 128, 144,...
Page 22: Standard Procedure
Mileage or time 100, 110, 120, 130, 140, 150, passed (whichever comes first) Or Years: 1 Or Kilometers: 16, 112, 128, 144, 160, 176, 192, 208, 224, 240, Change FEAD Belt every four years or 80, 000 miles (128, Â Â...
Page 23 VEHICLE READINESS NOTE: This document is for reference purposes only. The instructions are not VIN-specific, and it is not required to print or retain this document for each New Vehicle Prep performed. Description Action Using wiTECH and micro Pod II, take the vehicle out of Ship Mode by following the Exit Shipping routine within the New Vehicle Prep tab Place the ignition in the "ON"...
Page 24: Under Vehicle
UNDERHOOD Description Action Inspect the following for routing, loose attachments, connections, and clearance. Reroute and tighten as Loose Attachments, Routing and Clearance required: Brake Lines, Fuel Lines, Power Steering Hoses, Vacuum Hoses, Clutch Lines, Refrigerant Lines, Wiring, Belts. Refer to the owner's manual or the appropriate service information for proper fluid level inspection locations.
Page 25 ROAD TEST Description Action Verify all warning lights and gauges are operating All Warning Lights and Gauges / No DTCs properly, and no fault codes exist. Verify engine will only start while automatic Engine Starts Only in Park & Neutral transmission is in park or neutral.
Page 26 ROAD TEST Description Action Ensure that the electric heated rear defroster operates Defrost - Rear correctly. Turn on and feel for warmth. Check the "on/off" switch. Check the "set" operation. Check the "resume" function. Check the "accelerate" Cruise Control (if equipped) and "decelerate"...
Page 27 INTERIOR Description Action Check all steering wheel controls for proper Steering Wheel Mounted Controls operation. Cigar Lighter Check cigar lighter for proper operation. Fully open and close all power windows to ensure proper operation and sealing. Ensure that the windows Power Windows and Window Lock Switch operate properly at each door.
Page 28: Vehicle Storage
EXTERIOR Description Action Inspect the body exterior for damage, loose or missing items. During the inspection, ensure that no vehicle Inspect Body and Paint for Damage and Fit/ Finish damage occurred from the time the vehicle was received and the beginning of the New Vehicle Preparation.
Page 29: Standard Procedure - Towing
FINAL DETAIL & INSPECTION Description Action Using wiTECH and micro Pod II, take the vehicle out of Ship Mode by following the Exit Shipping routine within the New Vehicle Prep tab Place the ignition in the "ON" position. Place vehicle into Customer Mode using wiTECH Turn the headlamp switch to the "OFF/DRL"...
Page 30 Towing faster than 25 mph (40 km/h) or farther than 15 miles (24 km/h) with front wheels on the ground can cause severe transmission damage. Copyright 2020 Mitchell Repair Information Company, LLC. All Rights Reserved. Article GUID: A00770407...
