SFORZATO DSP-050EX User Manual
1. Display is format and input only.
You cannot switch between title, artist etc. It is displayed on smartphone or tablet.
You can off the display by press and hold «Рhase» (left) button.
2. New model has no default volume setting.
Volume is always pre-installed 100% when player switch-on.
After which it can be adjusted. And then the set volume value is saved during further work.
3. All setting can be changed only with front buttons.
New models DSP has no web browse menu.
The setting by front buttons is remembered.
Included Items
Please check to see if the following items are included.
１）DSP-050EX Main Body
２）AC Cable
３）External Clock Unit
４）User Manual, Safety Pamphlet
Index
1. Connection Instructions
2. PC Software Installation
3. iPhone / iPod Software Installation
4. Clock
5. Operation Instructions
6. Configuration
7. MQA – Master Quality Authenticated
8. Software Update Instructions
9. Update Log
1
Ver. 01.10.20
Advertisement
Related Manuals for SFORZATO DSP-050EX
Summary of Contents for SFORZATO DSP-050EX
- Page 1 SFORZATO DSP-050EX User Manual Ver. 01.10.20 1. Display is format and input only. You cannot switch between title, artist etc. It is displayed on smartphone or tablet. You can off the display by press and hold «Рhase» (left) button. 2. New model has no default volume setting.
- Page 2 Analog Output Maintenance Clock Input ① First, check that the AC cable for the DSP-050EX unit is unplugged. Also, check that the power switch is off. The power switch is located on the bottom of the unit. ② Connect external clock unit to the rear panel BNC connector and connect clock power cable to clock power connector.
- Page 3 For detailed connection instructions, refer to the amp manual. ④ Connect the LAN cable to the LAN port on the back of the DSP-050EX and connect the DSP-050EX to your home LAN network. If you use DELA or fidata for NAS, you can connect directly to the NAS.
-
Page 4: Other Software
NAS manual. ２)Ripping Software To play back CDs on DSP-050EX, you must load the CD data to your PC and store it on the NAS. Loading CD data to your PC is called ripping, and ripping software is used for this procedure. - Page 5 SFORZATO recommends the free app Linn Kazoo. Gapless play back is possible with this app. Additionally, you can use various other software, as long as it is control software that is OpenHome or DLNA compliant (Linn Kinsky, Fidata Music App, Bubble UPnP).
- Page 6 ⑤ By playing back music on your PC, sound will be transmitted through DSP-050EX. 5) Configuration Pressing “Select” button on the front panel and hold makes the DSP-050EX go into menu mode. In menu mode, you can change player name, update software and check software version.
- Page 7 For example, DLNARoomName= DSP-AudioRoom:MediaRenderer OpenHomeRoomName= DSP-AudioRoom Then remote control software recognize the DSP-050EX and displays with name of “ DSP-AudioRoom” Insert the USB memory which has the config.txt file to the maintenance connector on the rear panel. Navigate into menu mode of Config File. Press “Phase” button perform the change.
- Page 8 Pressing “Phase” button in this menu makes the DSP-050EX exit the menu mode and go into normal operation mode. The DSP-050EX is capable to decode MQA files. When MQA streaming is detected in place of PCM there is one of the below options shown: •...
- Page 9 ④ Turn on the DSP-050EX> ⑤ Execute the update software which you unzipped. ⑥ After PC shows the success, turn off the DSP-050EX and wait 3 seconds and turn it on again. ⑦ You can check the software version by navigating the menu mode “Version”.
